SolarPath SPSF SERIES User Manual

•

Troubleshooting:

Symptoms Troubleshooting steps
Check that the lamp can be manually
activated.
Check if the solar panel is blocked
from the sunlight by houses, trees and
other obstacles.
No light at night
Check if there is any artificial light
source(s) shining on the solar panel
during the night.
Examine status of each component
based on the repair guide.
Check if the solar panel is blocked
from the sunlight by houses, trees and
other obstacles.
A serious shortage Check if the surface of the solar panel
2
of working time is dusty or covered.
Examine if the battery pack is
damaged as per the repair guide
instructions.
Lighting does not
follow the normal
3
operating mode of
turning on and off
Check if the air temperature close to
human body temperature.
Lights fail to turn
4 on properly when
Check if the installation height is too
humans approach
high.
Process
Refer to "Activation and Installation" section
on this user guide and run activation tests.
Clear obstructions or change installation
location.
Remove the artificial light source(s) of
interference or change the installation
location.
Replace the damaged component(s).
Clear obstructions or change installation
location.
Clean the surface of solar panels as
detailed above.
Replace damaged battery.
Replace damaged battery.
When the air temperature is close to human
temperature, motion detection may slow
down. It will return to normal after the air
temperature changes.
It is out of motion detection range when
installation height exceeds Sm. It is
recommended to reduce the height or use
other operating modes.
Replace damaged motion sensor or
controllers.
SPSF SERIES
All in One Smart Solar Street Light
User Manual
Thank you for choosing the SPSFt Series Solar Street Light. For any q uestions, please email us at
roy.w@solarpathusa.com.
Please refer to the actual products if the provided diagrams show slight differences.
