Oscimed PSV Instructions

Instructions of use for cast cutter saw
1 Technical description
1.1 The electrical power supply
Supplied from a socket by a cable which passes through a transformer reducing voltage
to 24 VDC, it is optimal for the security. The device complied with the latest version of
medical standards EN 60601.
1.2 The electro-mechanical drive
The oscillating movement of the blade is made by a DC motor and a mechanical device,
which is made from high quality materials, with low wear and without maintenance. The
motor and the high lifespan sensor switch are driven by a microprocessor card.
The electromechanical device is mount trough anti-noise rubbers on the body of the
cutter to avoid vibrations in the hand and noise. The switch, situated closed to the user's
hand, is a contactless long life time sensor.
1.3 The cutting blades
The blades have a synthetic coupling center. A special lock nut makes it easy to install or
change the blade without any tool.
1.4 Technical data
Main voltage
Electricity network frequency
Power
Cycle of use
Length of the saw
Diameter
Weight
Speed of the motor / frequency
Oscillating angle of blade
Stroke at the end of the blade diameter 65mm
Length of power supply cable
Length of 24 VDC cable
Noise level
European directive 2007/47/CE
Protection
Storage, carriage and use condition.
Version : V1.3
OSCIMED PSV
85-264 VAC
50-60 Hz
200 VA
45 minutes on / 15 minutes off.
255 mm
50 mm
890 gr
14'500 rpm
6.2°
3.50 mm
1.10 m
3.00 m
63 dBA
EN 60601 classe 1
IP 20
Temperature: 0 - 35° C
Humidity: 0 - 90%
Pressure : 900 - 1080 hpa
Page 1/4
