Oscimed PSV Instructions For Use

Instructions for maintenance for cast cutter saw
Remark: see also the spare parts list.
1

Be sure to observe scrupulously the safety instructions

- Always take the plug off before doing whichever intervention on the device, or when
the device remains unattended or within reach of children or persons who are not
responsible for their actions.
- The maintenance and repairs must be provided by specialized persons; the possibly
damaged parts will be replaced by original spare parts.
- Every modification of the device in comparison with its original version is strictly
forbidden.
- Check that the socket in compliance with the plug of the device.
- Check that the indicated voltage on the motor block is in compliance with the used
power source.
- Never let the device running unattended.
- Do not pull neither lift the device when using the electric cable.

2 Technical description

2.1

The electrical power supply

Supplied from a socket by a cable which passes through a transformer reducing voltage
to 24 VDC, it is optimal for the security. The device complied with the latest version of
medical standards EN 60601.
2.2

The electro-mechanical drive

The oscillating movement of the blade is made by a DC motor and a mechanical device,
which is made from high quality materials, with low wear and without maintenance. The
motor and the high lifespan sensor switch are driven by a microprocessor card.
The electromechanical device is mount trough anti-noise rubbers on the body of the
cutter to avoid vibrations in the hand and noise. The switch, situated closed to the user's
hand, is a contactless long life time sensor.
2.3

The cutting blades

The blades have a synthetic coupling center. A special lock nut makes it easy to install or
change the blade without any tool.
Version : V1.0
OSCIMED PSV
Page 1/5
