Oscimed PSV Instructions Of Use

Instructions of use for cast cutter saw

1 Technical description

The electrical power supply
Supplied from a socket by a cable which passes through a transformer reducing voltage
to 24 VDC, it is optimal for the security. The device complied with the latest version of
medical standards EN 60601.
The electro-mechanical drive
The oscillating movement of the blade is made by a DC motor and a mechanical device,
which is made from high quality materials, with low wear and without maintenance. The
motor and the high lifespan sensor switch are driven by a microprocessor card.
The electromechanical device is mount trough anti-noise rubbers on the body of the
cutter to avoid vibrations in the hand and noise. The switch, situated closed to the user's
hand, is a contactless long life time sensor.
The cutting blades
The blades have a synthetic coupling center. A special lock nut makes it easy to install or
change the blade without any tool.
Technical data
Main voltage
Power input
Length of the saw
Effective diameter
Weight without the electrical power supply box
Motor rotation speed
Blade oscillating angle
Length of power supply cable
Length of 24 VDC cable
European standard 93/42 CEE
Protection against water and dust projections
OSCIMED PSV
85-264 VAC/50-60 Hz
130 Watt
255 mm
50 mm
890 g
14'500 t/mn
6.2°
1.10 m
3.00 m
EN 60601 classe 1
IP 52
