- Page 1 KyWay™ Terminal Quick Start Guide Document number: 700-00009-001-revB 03 July 2018...
-
Page 2: Table Of Contents
4 Indoor unit components and cables 5 Tools required 6 Request commissioning 7 Prepare the outdoor unit (ODU) 8 Connect the cables 9 Power on the KyWay™ terminal 10 Access the ASM 11 Access the modem 12 Documentation 13 CE declaration of conformity... -
Page 3: Introduction
KyWay™ Terminal Quick Start Guide 1 Introduction Thank you for choosing the Kymeta KyWay™ terminal and welcome to the new era of satellite connectivity. To ensure the KyWay terminal is installed for maximum performance in each deployed platform, only Kymeta-certified installers should install and commission the unit. -
Page 4: Package Contents
Box 1: KyWay terminal ODU (1) Pre-assembled ODU (ODU mounting plate (attached RF chain - BUC, diplexer, LNB) installed on ASM) (6) Cable ties (1) KyWay™ Terminal Quick Start Guide (1) Kymeta Safety and Handling Guide (1) KyWay™ Terminal Limited Warranty Box 2: ODU interface cable (1) ODU interface cable (three lengths available: 3.66 m, 7.62 m, 15.24 m) -
Page 5: Indoor Unit Components And Cables
Note: Drawings are not to scale ✎ The mTenna I/O vents are on top of the box, so always place the mTenna I/O on the top rack. Standard rack spacing allows sufficient ventilation. © 2018 Kymeta Corporation and its affiliates. 03 July 2018... -
Page 6: Tools Required
18:00 Pacific Time (UTC-8)) to schedule your commissioning window. Have the following information ready for your commissioning: ASM serial number Modem serial number Purchase date Confirmation of the service plan choice © 2018 Kymeta Corporation and its affiliates. 03 July 2018... -
Page 7: Prepare The Outdoor Unit (Odu)
1. Make sure you have a clear, clean, flat surface for assembling the Kymeta KyWay terminal. 2. Open the KyWay terminal ODU box. With two people, lift the ODU out of the case. Lift by the plastic bezel only. Do not lift the ODU by any RF component (LNB, diplexer, or BUC) as this may damage sensitive components and potentially void your warranty. -
Page 8: Connect The Cables
9. (optional) Connect the customer Ethernet cable to the modem (port 5-8 for DHCP). 10. Connect one power cable to the mTenna I/O and another one to the modem. ✎ Use cable ties to clean up loose cables. © 2018 Kymeta Corporation and its affiliates. 03 July 2018... -
Page 9: Power On The Kyway™ Terminal
4. In the Authentication Required window, provide the following credentials: username: admin, password: 2Cfg^Ant. ✎ Refer to the KyWay Terminal Troubleshooting Guide, section "Cannot access the web-based UI" if you cannot access the mTenna ASM web-based user interface. The ASM automatically reboots every 7 days (software version 1.1.0.3240) or 24 hours (software version 1.0.0.2295 and 1.0.0.2210). -
Page 10: Ce Declaration Of Conformity
15 Contact information 12277 134th Ct NE, Redmond, WA 98052, USA | +1 (425) 896-3700 www.kymetacorp.com twitter.com/KymetaCorp | facebook.com/kymetacorp | instagram.com/kymeta | linkedin.com/company/kymeta- corporation © 2018 Kymeta Corporation and its affiliates. -
Page 11: Revision History
ASM" to cover software version 1.1.0.3240. 17 Legal disclaimer © 2018 Kymeta Corporation and its affiliates. KYMETA, CONNECTED BY KYMETA, MTENNA, KYWAY, KĀLO image, and KĀLO are trademarks of Kymeta Corporation, with registrations or pending applications for these marks in Brazil, the European Union, Japan, Norway, Singapore, South Korea, and the United States.
