- Page 1 BT3080 User Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE 1. General description Page 1 2. Typical applications Page 1 3. General Specifications Page 2 4. User Interface Page 3 5. Electrical specifications Page 6 6. Acoustics specifications Page 8 CONFIDENTIAL MATERIAL... -
Page 3: General Description
GENERAL DESCRIPTION BT-3080 Bluetooth universal headphone supports 4 Bluetooth profiles and they are: BT-3080 supports headset and hand-free profiles to work as a wireless headset with mobile phones or VOIP to manage phone call. BT-3080 supports advanced audio distribution profile (A2DP) to work as a wireless headphone with MP3 phones, MP3 players or computers. -
Page 4: General Specifications
General Specifications Bluetooth Standard: Bluetooth V2.0 Qualified Range: Up to 10 meters (66 feet) in open space Listen Time: Continuous music play time (A2DP) up to 10 hours Talk Time: Continuous talk time (hand-free, headset) up to 12 hours Stand-by Time: Up to 250 hours Speaker: 27 mm Neodymium... -
Page 5: User Interface
USER INTERFACE Figure 4.1 Left Ear User Interface Play/Pause/Call Multiple Function Button Bluetooth Status Blue LED Next/Previous button Microphone Boom Figure 4.2 Right Ear User Interface On/Off switch Mini USB port for charging and firmware upgrade Charging indicator LED CONFIDENTIAL MATERIAL... - Page 6 Charging Indicator O (Orange) Left ear Red LED: Mute/ Low battery/ Pairing R (Red) Blue LED: Power on/ Mono or Stereo active B (Blue) TABLE 4.2 BT-3080 LED STATUS LED on LED Repetition State LED Mapping (ms) Cycle Time (ms)
- Page 7 Vol- Mute – microphone 2s Hold Vol+ and Vol- Initiate last dialed call 1s Hold Next Initiate last received call 1s Hold TABLE 4.4 BT-3080 REMOTE CONTROL MMI Function Action Button Play Press once Pause Press once Stop Press twice...
-
Page 8: Electrical Specifications
Page-6- 5. ELECTRICAL SPECIFICATIONS TABLE 5.1 BT3080 POWER CONSUMPTION Mode Average Unit Standby Inquire scan, 1.28 sec. interval Page scan, 1.28 sec. interval ACL connection, sniff mode, 40 ms interval SCO connection (Mono) Streaming music @ 44.1KHz sample rate (Stereo) TABLE 5.2 BT3080 BATTERY LIFE MODE LIFE... - Page 9 Page-7- TABLE 5.3 BT3080 RF Specifications Description Min. Max. Unit Frequency specification Frequency range 2402 2480 Modulation characteristics Δf1 (ave) Δf2 (max) Δf1 (ave)/ Δf2 (ave) Initial carrier frequency accuracy Carrier frequency drift One slot packet Five slot packet Max drift rate (KHz/ 50us) Transmit specification Tx power (for Class 2) Tx power (for Class 1)
-
Page 10: Acoustics Specifications
Page-8- 6. ACOUSTICS SPECIFICATIONS SPEAKER TYPE Size 27 mm Neodymium SPEAKER FREQUENCY RESPONSE Telephony 300 Hz to 4 kHz (CVSD u-Law) Stereo Audio 20 Hz to 20 kHz (16 bit 48kHz SBC Coding) Distortion <3% This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
