- Page 1 User Manual for SA505 Bluetooth Stereo Headphones SA505 Bluetooth Stereo Headphone User's Guide...
- Page 2 CAUTION: Avoid using SA505 headphone with the volume turned up for a long time. Doing so can damage your hearing. It is advisable to keep the volume at a moderate level at all times. Copyright © 2005, TECOM Co., Ltd All rights reserved.
-
Page 3: Table Of Contents
2.2、 Pairing with devices..................6 2.3、 Connecting BT3070 headphone with multiple devices ......11 2.4、 Charging headphone ................. 11 III. Play Music with SA505 Headphone ..............13 IV. Make/Answer Calls with SA505 Headphone ........... 15 V. The LED Indicator Mean..................17... -
Page 4: About Sa505 Stereo Headphone
Volume Up Play/ Pause/ Stop/ Pairing Button Blue/ Red Status LED Indicator Retractable Microphone Forward Backward Volume Down < Right side > Orange LED Charging Indicator Power On/ Off Floating Slider Mini USB Charging Socket SA505 Bluetooth Stereo Headphone User's Guide... -
Page 5: General Features
1.2、 General Features SA505 is equipped with a retractable microphone and Phone Call: supports Bluetooth hand-free profile for wireless phone call. Music Streaming: SA505 supports Bluetooth A2DP (Advanced Audio Distribution Profile). User can enjoy omni-direction high quality wireless music play up to 15 meters away. -
Page 6: Setup Sa505 Headphone
Put the Power On/Off Floating Slider to OFF side for turning the headphone off. 2.2、 Pairing with devices Before using SA505 headphone you must pair up with Dongle or/and mobile phone or other bluetooth enabled devices. Put the headphone into pairing mode... - Page 7 Dongle will find the BT3070 headphone, right click to find out its related services. It will require the PIN code, please confirm with PIN = 0000 (4 zero’s). In case of unsuccessful pairing please repeat above steps. SA505 Bluetooth Stereo Headphone User's Guide...
- Page 8 Nokia 6230 for example: Steps Actions Illustration Click “Menu” button first. Select “Settings”. Select “Connectivity” SA505 Bluetooth Stereo Headphone User's Guide...
- Page 9 Select “Bluetooth” Select “Paired devices” Please click “New” to search for the BT3070 headphone. SA505 Bluetooth Stereo Headphone User's Guide...
- Page 10 Click “Connect” to connect with the BT3070 headphone. When connected, mobile phone’s operating tone will automatically be transferred to your headphone.(Depend on mobile’s type, some of mobiles may be fail to hear operate tone from BT3070 after connected.) SA505 Bluetooth Stereo Headphone User's Guide...
-
Page 11: Connecting Bt3070 Headphone With Multiple Devices
In case of unsuccessful pairing/connecting please repeat above steps. 2.3、 Connecting SA505 headphone with multiple devices You are able to connect SA505 headphone with audio source and mobile phone simultaneously. Please refer to your music-player/phone manual for details regarding pairing/connecting bluetooth enabled devices. - Page 12 AC adaptor to charge. When the LED indicator turns to solid orange, headphone is charging. When the LED indicator goes off, the headphone is fully charged. The headphone may take 2.5 hours to fully charge. SA505 Bluetooth Stereo Headphone User's Guide...
-
Page 13: Play Music With Sa505 Headphone
III. Play Music with SA505 Headphone To play music or other audio file, ensure that SA505 headphone is connected with another device (PC, MP3-player etc.). The left side of SA505 headphone is used for remote control the stereo music. Functions... - Page 14 Microphone to end an music active call. Reconnect Tap the Play button once A short tone reconnect stereo service with paired audio source. (Dongle etc.) * When achieve maximum volume, a warning tone will be heard. SA505 Bluetooth Stereo Headphone User's Guide...
-
Page 15: Make/Answer Calls With Sa505 Headphone
IV. Make/Answer Calls with SA505 Headphone To make/answer a call with SA505 headphone, please make sure headphone has connected to the mobile phone. Actions Remote control Tone Illustration commands Make a call with Before making a call from A short tone... - Page 16 Retractable Microphone. Cancel an Press and hold the Play A short tone outgoing call button 1 second during dialing cancel outgoing call. ** When achieve maximum volume, a warning tone will be heard. SA505 Bluetooth Stereo Headphone User's Guide...
-
Page 17: The Led Indicator Mean
Regularly consecutive flashing 3 times every 10 seconds – Low battery warning Flashing blue and red light Flashing every 0.6 second – In pairing/ Incoming call/ alternately Outgoing call Solid orange light Charging (light switch off when fully charge) SA505 Bluetooth Stereo Headphone User's Guide...
