Simplicity 2368 Illustrate Parts List page 3

Tiller Adaptor Kit
REF NO. PART NO.
1 1917372
2 1917356
3 105359
4 1707593
5 1707599
6 105346
7 1704716
8 1923141
9 960171
10 1666106
11 1919326
12 176012
13 1707564
14 1657562
15 1669999
16 1708352
17 157427
18 1960474
19 1706342
20 1721133
21 1706511
22 1924940
23 1921971
24 1920415
25 1916965
26 1706510
27 1707265
28 1706512
29 1708961
30 1960251
31 1921210
32 1960116
33 1960033
34 1706344
35 1921333
36 1706362
37 1960160
38 1611789
39 171186
40 912808
41 *
42 1708180
43 159159
44 1916950
45 1706508
46 1657712
47 1700059
48 1923701
49 960403
50 1928721
51 1706343
52 1708298
53 1923362
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1691979 Tiller Adaptor Kit Sovereign to Landlord
1693497 Tiller Adaptor Kit Sovereign to Landlord
TP 400-2368-01-AT-SMA
QTY.
1 NUT-HEX, 5/16-18
1 LOCKWASHER,5/16
1 SUPPORT, Rear Belt Guard
1 SPRING, Torsion
1 ANCHOR, Spring
2 SPACER
2 SPACER
1 CAPSCREW, Hex Head, 5/16-18 x 2-3/4
1 WASHER, Nylon
1 BUSHING
1 WASHER
2 RETAINER PIN
1 COVER, Belt
1 ROD
1 SPACER
1 GUARD, Spring
1 KEY
1 SCREW,Set Square Head, Cup Point, 3/8-16 x 1/2, G8
1 PULLEY, 9inch OD
1 PULLEY, Idler, 2-3/4 OD
2 PULLEY, Idler, 1-7/8 OD
10 WASHER
2 CAPSCREW,Hex Head, 3/8-16 x 1-3/4
1 CAPSCREWHex Head, 3/8-16 x 1-1/4
6 LOCKWASHER, 3/8
1 PULLEY, Idler, 4 OD
1 ANCHOR, Jackshaft
1 V-BELT
1 SHAFT & SUPPORT ASSEMBLY
4 NUT, Hex Center Lock Jam, 3/8-16
2 CAPSCREW, Hex Head, 3/8-16 x 1
1 PIN, Yoke, Drilled
1 CLIP, Hair Pin
1 CLEVIS & BAR ASSEMBLY, Anchor
1 CAPSCREW, Hex Head, 5/16-18 x 1
1 PULLEY & SHAFT ASSEMBLY
4 WASHER
2 SEAL, Oil
2 BEARING
1 FITTING, LUBE
1 CLEVIS ASSEMBLY, (See Ref No. 42)
1 CLEVIS & HOUSING ASSEMBLY, w/ Bearings (Includes Ref. Nos. 39 & 40)
1 SPRING, Extension
5 NUT, Hex, 3/8-16
1 ARM & HUB ASSEMBLY
1 PULLEY, Idler, 3-5/8 OD
1 V-BELT
1 CAPSCREW, Hex Head, 3/8-16 x 2
1 KEY, WOODRUFF, #61
1 SCREW, Set, Square Head Cup Point, 5/16-18 x 1/2, G8
1 PULLEY & HUB ASSEMBLY
1 PIN, Round Head, Drilled
1 NUT, Hex Centerlock, 5/16-18
DESCRIPTION
3
