Specifications

(Unless otherwise indicated, specifications are for 1 year in ±% of
reading @ 23°C)
General
Accuracy:
Quik-Chek 4 & 20 mA ±(0.03% of Setting + 1 LSD)
Milliamp & % Ranges ±(0.05% of Reading + 1 LSD)
Read DC Volts ±(0.05% of Span + 1 LSD)
Warm Up Time: 10 seconds to specified accuracy, 2 minutes to
maximum accuracy
Temperature Effect:
Milliamp Ranges: ±0.008% of Reading/°C
Read DC Volts: ±0.012% of Span/°C
Batteries Three "9V", (1604) batteries (Alkaline supplied and
recommended)
Battery Life:
Source and Power Transmitter: Nominal 33 hours at 12
mA, 20 hours at 20 mA with 250 Ohm load
Read mA, DC V & 2-Wire Simulate: Nominal 100 hours
Low Battery Indication: "BAT" indication will first appear on the
display when approximately 4 hours remain to source 12 mA into
250 Ohms. This is typical use for a full shift.
Overvoltage Protection: Protected to 135V AC/DC for 30 seconds
without fuses
Operating Temperature Range: -5 to +140 °F (-20 to +60°C)
Storage Temperature Range: -22 to +160°F (-30 to +70°C)
Relative Humidity: 10 to 90%, non-condensing for 24 hours from 0
to 35°C
Overall Size: 121.9 x 66.0 x 35.8 mm (4.8 x 2.6 x 1.41 inches)
Weight: 0.22 kg (7.8 oz)
Warranty
Altek products are warranted to be free from defects
in material and workmanship (excluding fuses,
batteries and leads) for a period of three years from
the date of shipment. Warranty repairs can be
obtained by returning the equipment prepaid to our
factory. Products will be replaced, repaired, or
adjusted at our option. Altek gives no other
warranties, including any implied warranty of fitness
for a particular purpose. Also, Altek shall not be liable
for any special, indirect, incidental or consequential
damages or losses arising from the sale or use of its
products.
Milliamp source
Ranges:
0.00 to 24.00 mA; -25.0 to 125.0 % of 4 to 20 mA
Accuracy:
Quik-Chek 4mA ±(0.03% of 4mA + 0.01 mA) = 0.011mA
Quik-Chek 20mA ±(0.03% of 20mA + 0.01 mA) = 0.016mA
0 to 24mA ±(0.05% of Reading + 1 LSD)
Typical Drive Capability: 1200 Ohms @ 20.00 mA with fresh
batteries, 800 Ohms @ 20.00 mA with low batteries
Compliance: nominal 27VDC @ 20 mA with fresh batteries
Power & measure 2-wire transmitters
Ranges and Accuracy: Same as for Milliamp Source
Output Current: up to 24.00 mA
Typical Drive Capability:1200 Ohms @ 20.00 mA with fresh
batteries, 800 Ohms @ 20.00 mA with low batteries
Compliance: nominal 27VDC @ 20 mA with fresh batteries
2-wire transmitter simulator
Ranges and Accuracy: Same as for Milliamp Source
Loop Voltage Limits: Minimum, 2 VDC; Maximum 100 VDC
Overload Protection: Current limited to 25 mA nominal
Milliamp read
Ranges: 0.00 to 52.00 mA; -25.0 to 300.0 % of 4 to 20 mA
Accuracy: Same as for Milliamp Source
Voltage Burden: 0.9V at 4 mA, 1.2V at 20 mA, 1.9V at 50 mA
excitation current
Read DC Volts
Range:-99.99 to +99.99V DC
Input Impedance: >2 Meg Ohms
PN 1887748 Rev A April 2002
©2002 Altek Industries, Inc. Specifications subject to change without notice.
All rights reserved. Printed in U.S.A.
