Operation and Setup

How to Confirm Charging Current

It is very important to know the maximum charging current of the battery as excessive
current could influence the life span of battery and/or cause damages. In addition, excessive
current can cause heating and/or explosion of the battery during the charging process.
The charging and discharging capacity of battery is usually marked with C value. Multiplying
the charging C value and battery capacity equals to the maximum charging current
supported by the battery. For example, for a 1000 mAh battery with a charging capacity of
5C, the maximum charging current would be 1000*5=5000mA; therefore, the maximum
charging current is 5A.
For a lithium battery, if it is impossible to confirm the supported charging C value, please set
the charging current below 1C for the sake of its (lithium battery) safety.
The reference relation between C value and charging time: charging time ≥60 minutes/
charging C value (it therefore needs around 60~70 minutes to complete charging with 1C).
Due to differences in battery conversion efficiency, the period to complete the charging
might be extended.

Operative Skills

Connect the charger to the power supply
and wait for the system to complete the self
testing. Connect the battery to the charger
under standby interface, and short press the
shuttle key to select the switching channel
freely，after
channel，short press the shuttle key to
make the task setting menu to pop up.
When the task is executing，short press the
shuttle key to make the task setting menu to
pop up，will adjust the task current.
Long press channel switc, to quick stop
current operation or to enter setting menu
for corresponding channel.
04
select the corresponding
D6 Duo Pro AC/DC Dual Channel Smart Charger
Channel Speed
Switch Shuttle Key
