D600 User Manual
Trademark Acknowledgments
• SATIR is trademark of SATIR Europe (Ireland) LTD.
• Microsoft, Windows and Windows logo is either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
• Other names and products not mentioned above may be registered trademarks or trademarks of their
respective companies.
Copyright © 2019 SATIR LTD. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Satir D600

Summary of Contents for Satir D600

  • Page 1 D600 User Manual Trademark Acknowledgments • SATIR is trademark of SATIR Europe (Ireland) LTD. • Microsoft, Windows and Windows logo is either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. • Other names and products not mentioned above may be registered trademarks or trademarks of their respective companies.
  • Page 2 About this IR Camera User Guide Symbols Used This mark denotes issues that may affect the IR camera’s operation. This mark denotes additional topics that complement the basic operation procedures.  What do the icons listed in the Camera User Guide mean? Information displayed on the LCD Display (p.14)
  • Page 3 Thumb Index Introduction of camera components. Preparing the IR Camera Describes basic functions, learning how to turn Basic function on/off the IR camera and work with the control panel and LCD monitor. Describes working with the camera, from each Shooting analysis settings to using the camera’s various analysis tools.

  • Page 4: Table Of Contents

    Table of Contents Read This First....................... 5 Front View....................9 Back /Bottom View................. 10 Prepare the IR Camera..................11 Charge the Device...................11 Turn the Power On / Off.................12 Understand the Information on the Display........14 Set the date and time................16 Local Settings..................18 Language setting................
  • Page 5 Freeze/Activate an image............. 54 Emissivity table................55 Fulfill the Analysis Function..............57 Set object/global settings.............57 Reset the default settings............59 Analysis tools.................. 60 Alarm temperature................69 Comparing temperature..............70 Remove analysis tools..............72 Save the Image..................73 Attach Voice Memos Images............... 75 Snapshot and Edit the image.............. 77 Record/Replay the Video..............

  • Page 6: Read This First

    IR camera is operating and being operated correctly. Please note that SATIR, its subsidiaries and affiliates, and its distributors are not liable for any consequential damages arising from any malfunction of an IR camera or accessory that results in the failure of an image to be recorded or to be recorded in a format that is machine readable.
  • Page 7 Warnings Avoid damaging eyesight Warning: Do not trigger the laser pointer in human or animal eyes. Exposure to the laser produced by the laser pointer may damage eyesight. Do not disassemble Do not attempt to disassemble or alter any part of the equipment that is not expressly described this guide.
  • Page 8 Do not handle the power cord if your hands are wet Handling it with wet hands may lead to electrical shock. When unplugging the cord, ensure that you hold the solid portion of the plug. Pulling on the flexible portion of the cord may damage or expose the wire and insulation, creating the potential for fires and electrical shocks.
  • Page 9 IR camera. Remove the memory card, (if applicable) and unplug power source, from the IR camera and wait until moisture evaporates completely before resuming use. Right Reserved SATIR reserves the right to change the functions and configurations of our products without prior notice.

  • Page 10: Front View

    Component Guide Front View LCD Display Illuminator Visual camera IR lens Laser Range Finder (LRF) User-Defined trigger...

  • Page 11: Back /Bottom View

    Component Guide Back /Bottom View OK Key Power Button Power indicator Focus Mode Freeze/Activate Auto adjust Cancel Video output USB Port...

  • Page 12: Prepare The Ir Camera

    Prepare the IR Camera Charge the Device Charge the Device Device has built in battery, when Low battery status symbols display on User Interface, Please see different battery status symbols below, as well as steps to charge the device. Battery Status Symbols The following icons indicate the battery status on the LCD display.

  • Page 13: Turn The Power On / Off

    Prepare the IR Camera Turn the Power On / Off Turn the Power On / Off The control panel back light is illuminated while the camera is powered To hold the camera correctly in your hand, grip the handle while keeping the device upright, with your thumb placed above the control panel and your index finger on the...
  • Page 14 Turn off the camera. Hold the power button for 3 seconds. • Select "OK" on the shutdown prompt window. Once the Control Panel is no longer illuminated the device is powered off.

  • Page 15: Understand The Information On The Display

    Please see the details for Main User Interface below: Main User Interface Explanation： Battery Status Icon Temperature unit；Emissivity；Distance；Time Span(Touch/Select to Modify) Color scale Level(Touch/Select to Modify) SATIR trademark(Touch/Select to open the main menu) Quick launcher (Touch/Select to open the shortcut menu)
  • Page 16 About the system settings Language Select the language of the menus and messages Update Update operating system Set the system date and time display ,set time Date & Time zone and screensavers Select the video output mode / Activate LED Control Torch / Activate Laser Range Finder / Set USB Mode / Set the multifunction key...

  • Page 17: Set The Date And Time

    Prepare the IR Camera Set the date and time Set the date and time You need to set the Data / Time when the IR camera is turned on for the first time. Press the [C] key or Touch/Select the icon.
  • Page 18 Use touchscreen, select [Set Date] option: • Slide up and down the date item to modify the date; • After modifying select [OK] to save, changes or select [Cancel] to abandon changes. Use touchscreen, select [Set Time] option: • Slide up and down the time item to modify the time;...

  • Page 19: Local Settings

    Prepare the IR Camera Local Settings In this menu item, you can set style of the built-in menu system. Language setting Press the [C] key or touch/select the icon. Press the UP or DOWN arrow on the omni on the selector to highlight the [Settings] menu and press OK key to...
  • Page 20 Local setup: • Using the touchscreen, slide up and down to select a language; • After modifying select [OK] to save, changes or select [Cancel] to abandon changes.

  • Page 21: Unit Setting

    Prepare the IR Camera Local Settings Unit setting Press the [C] key or touch/select the icon. Press the UP or DOWN arrow on the omni selector to highlight [Settings], then press the OK key to enter. Alternatively, touch/select the [Setting] Icon to open the menu.

  • Page 22: Tv-Out Mode

    Prepare the IR Camera Local Settings TV-OUT mode Press the [C] key or touch/select the icon. Press the UP or DOWN arrow on the omni selector to highlight [Settings], then press the OK key to enter. Alternatively, touch/select the [Setting] Icon to open the menu.
  • Page 23 Use the arrow buttons, or the touchscreen to select NTSC or PAL mode. About Control TV-OUT Slide to select the NTSC or PAL mode Mode Click to open when using CCD in darkness Laser Click to open the laser to aim at the object Slide to select the UDisk or Trans.

  • Page 24: Quick Launcher

    Prepare the IR Camera Local Settings Quick Launcher Press the [C] key or touch/select the icon. Press the DOWN or UP arrow on the omni selector to highlight [Settings], then press the OK key to enter. Alternatively, touch/select the [Setting] Icon to open the menu.
  • Page 25 On the main User Interface, touch/select the Quick Launcher icon . The shortcut menu will appear on right area of the User Interface.

  • Page 26: Basic Functions

    Basic Functions Use the LCD Display Use the LCD Display If you wish to use the LCD display for shooting, playing back thermal images and adjusting menu settings, follow the instructions below. Open the LCD Display in the direction of the arrow. Aim the IR camera at a subject.

  • Page 27: Select Menus And Settings

    Basic Functions Select Menus and Settings To enter the Main Menu, press [C] or touch the [SATIR] logo on the Main User Interface. To navigate the menus, use the directional keys to highlight the desired sub-menu icon and press [OK] to enter the menu.
  • Page 28 Main menu Analysis(Spot / Area / Line tool and ISO) Images(Image mode / Palette / Adjust ) Media(Snapshot / Edit / Voice record / Video record / Replay) File(Review files and thermal images) Settings(Analysis setting / System setting / Image setting / Bluetooth / System info)

  • Page 29: Reset The Settings To Default

    Basic Functions Reset the Settings to Default You can reset the menu and button operation settings to default. Press the [C] key or touch/select the icon. Press the DOWN or UP arrow on the omni selector to highlight [Settings], then press the OK key to enter.

  • Page 30: Shoot

    Shoot IR Camera Adjustment Focus Aim the IR camera at the subject. A: Press [F] key, [F] key will turn blue which means device is in Focus mode. B: Press UP or DOWN arrow to manual focus or press the LEFT arrow to auto focus Alternatively, while in Focus Mode, touch/select the point on...
  • Page 31 DIGITAL ZOOM To use the Digital Zoom feature, ensure the camera is not in Focus Mode, and hold down the [←] button and press [↑] or [↓] to zoom in and out respectively. "Zoom: xxx%" will appear in the middle of the left side the User Interface.

  • Page 32: Display Mode

    Shoot IR Camera Adjustment Display Mode Thermal, Visual and DuoVision image display This IR camera records visual images with its built-in digital camera. You can capture a visual image as a reference to the thermal image. Press [C] button, or touch/select the logo.
  • Page 33 Use the arrow buttons or the touchscreen, navigate to desired image mode: IR, CCD, Merge, Merge Plus or Image Only. Alternatively, use the Quick Launcher menu and touch/select the top button, by default his is [IR], to switch between the different modes. To close the Quick Launcher menu press [C] or touch a different area of the User Interface.
  • Page 34 Shoot IR Camera Adjustment In DuoVision and DuoVisionPlus modes, you can merge the IR image and the visible image to create a more detailed image were text/signs is legible. In this mode, the IR information is displayed in the user defined pseudo color for easy analysis.
  • Page 35 In either merge mode, the user can select the [Pos] function, this allows the user to align the IR and Visible images so they correspond correctly. To do this select [Pos] and using the touch screen move the image until both are aligned on the target.

  • Page 36: Image Adjustment

    Shoot IR Camera Adjustment Image adjustment You can adjust the Level (brightness) and Span (contrast) of the image captured by IR camera, manually or automatically. Auto adjustment Press [C] button, or touch/select the logo. Use arrow buttons to highlight [Image] and press [OK] to enter the menu.
  • Page 37 Use the arrow buttons or touch screen, set the Adjust Mode to [Auto], [Manual] or [Fixed] and hit [Apply]. The IR camera will automatically adjust the brightness and/or contrast and calibrate when you press the [A] key.
  • Page 38 Shoot IR Camera Adjustment Manual Adjustment Set device adjust mode to Manual. How to set please refer to P35-36 The user can touch/select the values Level above or below the color bar to manually adjust the Level or Span values. Please see the figure to the right.
  • Page 39 Shoot IR Camera Adjustment Fixed Adjustment Set device adjust mode to Fixed. How to set please refer to P35-36. In this mode, you can find an F on the left of Level values. In this mode, the brightness and contrast will keep the same when you press the [A] key.

  • Page 40: Palette

    Shoot IR Camera Adjustment Palette Press the [C] key or touch/select the icon. Use arrow buttons to highlight [Image] and press [OK] to enter the menu. Alternatively, touch/select the [Image] menu icon to enter the menu. Use the omni-selector to highlight the [Palette], and press [OK] to enter the...
  • Page 41 Use the arrow buttons or touch screen to select the palette mode and then tap [Close] to save the setting. There are 6 color palettes available: Iron, Iron inverted, Rainbow, Feather, Grey and Grey inverted.

  • Page 42: Auto Shutter

    Shoot IR Camera Adjustment Auto Shutter Press the [C] key or touch/select the icon. Press the DOWN or UP arrow on the omni selector to highlight [Settings], then press the OK key to enter. Alternatively, touch/select the [Setting] Icon to open the menu.
  • Page 43 Use the omni selector or touch screen to set the shutter interval to the desired value and press [OK] or touch/select [Close] to save the setting.

  • Page 44: Multifunction Key

    Shoot IR Camera Adjustment You can set the multifunction key with different functions such as shutter , freeze and snapshot through the system. Multifunction key Press the [C] key or touch/select the icon. Press the DOWN or UP arrow on the omni selector to highlight [Settings], then press the OK key to enter.
  • Page 45 About the function of multifunction key The machine will shutter one time by pressing the Shutter multifunction key. You can activate / freeze a thermal image by Freeze pressing the multifunction key. Snapshot Save the image by pressing the multifunction key. Laser Open laser by pressing the multifunction key.

  • Page 46: Turn The Led And Laser On/Off

    Shoot IR Camera Adjustment Turn the LED and Laser on/off Warning: Do not trigger the laser in human or animal eyes. Exposure to the light produced by the laser may damage eyesight. Press the [C] key or touch/select the icon. Press the DOWN or UP arrow on the omni selector to highlight...
  • Page 47 Use the omni-selector or touch screen, the user can toggle on/off the LED Torch and the Laser Range Finder. Touch the on/off toggle switch, or highlight the desired function and press [OK] to toggle on/off.

  • Page 48: Laser Dist

    Shoot IR Camera Adjustment Laser Dist Warning: Do not trigger the laser in human or animal eyes. Exposure to the light produced by the laser may damage eyesight. Press the [C] key or touch/select the icon. Press the DOWN or UP arrow on the omni selector to highlight [Settings], then...
  • Page 49 Use the omni-selector or touch screen, toggle on the Laser Range Finder. Select [Multi-function Key] option, select [LaserDist] function using the keypad or touchscreen, then tap [Done] to save the setting. Press [C] Key to or use touchscreen to go back to the main user interface.

  • Page 50: Usb Mode

    Shoot IR Camera Adjustment USB Mode Press the [C] key or click the icon. Press the DOWN or UP arrow on the omni selector to highlight [Settings], then press the OK key to enter. Alternatively, touch/select the [Setting] Icon to open the menu.
  • Page 51 Use keypad or touch screen to select [UDisk] or [Trans.] mode and then c tap [Done] to save the setting.

  • Page 52: Bluetooth

    Shoot IR Camera Adjustment Bluetooth Press the [C] key or touch/select the icon. Press the DOWN or UP arrow on the omni selector to highlight [Settings], then press the OK key to enter. Alternatively, touch/select the [Setting] Icon to open the menu.

  • Page 53: Measurement Range

    Shoot IR Camera Adjustment Measurement range Press the [C] key or touch/select the icon. Press the DOWN or UP arrow on the omni selector to highlight [Settings], then press the OK key to enter. Alternatively, touch/select the [Setting] Icon to open the menu.
  • Page 54 Touch/select the number representing the desired range and click [OK] to save the settings. Then press the [C] key to go back to the main interface. The camera offers two Temp. Range：-20~150℃,140~600℃.

  • Page 55: Freeze/Activate An Image

    Shoot IR Camera Adjustment Freeze/Activate an image You can activate / freeze a thermal image by pressing the [S] key on the keypad. Press the [S] key to freeze the image. You can see Freeze in the bottom left corner of the user interface. Press the [S] key again to unfreeze/activate the image.

  • Page 56: Emissivity Table

    Shoot IR Camera Adjustment Emissivity table Press the [C] key or touch/select the icon. Press the DOWN or UP arrow on the omni selector to highlight [Settings], then press the OK key to enter. Alternatively, touch/select the [Setting] Icon to open the menu.
  • Page 57 Use the omni-selector to navigate the table until the desired target material emissivity is found. Press the [C] key to exit the table. Alternatively, navigate the table by using the touchscreen.

  • Page 58: Fulfill The Analysis Function

    Shooting Fulfill the Analysis Function Set object/global settings Press the [C] key or touch/select the icon. Press the DOWN or UP arrow on the omni selector to highlight [Settings], then press the OK key to enter. Alternatively, touch/select the [Setting] Icon to open the menu.
  • Page 59 Tap [Save] to save the settings. About the analysis parameters Selects the object of which you want to set Object the parameters Different material has different emissivity. Emissivity Use different emissivity to measure different material Different object has different distance to the Distance IR camera.

  • Page 60: Reset The Default Settings

    Shoot Fulfill the Analysis Function Reset the default settings Press the [C] key or touch/select the icon. Press the DOWN or UP arrow on the omni selector to highlight [Settings], then press the OK key to enter. Alternatively, touch/select the [Setting] Icon to open the menu.

  • Page 61: Analysis Tools

    Shoot Fulfill the Analysis Function Analysis tools This topic briefly explains how to set the analysis tools on the thermal image. Spot analysis Press the [C] key or touch/select the icon. Press the UP or DOWN arrow on the omni selector to select the [OK] [Analyze] then press key.
  • Page 62 Set the spot analysis: • Press the arrow keys and choose a spot, then press the ok key or double tap Spot tool. • Press the UP or DOWN arrow on the omni selector to select what you want to be changed ,then press the LEFT or RIGHT arrow on the omni selector to change it.
  • Page 63 Shoot Fulfill the Analysis Function Area analysis Press the [C] key or touch/select the icon. Press the UP or DOWN arrow on the omni selector to select the [OK] [Analyze] then press key. Alternatively, touch/select the [Analyze] Icon to open the menu. Press the UP or DOWN arrow on the omni selector to select the [OK]...
  • Page 64 Move the area: • Select the area you want to move by tapping the area. • There are two methods to move the tool: Method 1：Press the UP, DOWN, LEFT, RIGHT arrow on the omni selector to move the area. Method 2：Use the touchscreen to select the area you want to move and drag it to desired point.
  • Page 65 About changing the shape of the analysis area. Original Original Final Original Final LEFT and UP RIGHT and UP LEFT and DOWN RIGHT and DOWN Original Original Final Final Original...
  • Page 66 Shoot Fulfill the Analysis Function Line analysis Press the [C] key or touch/select the icon. Press the UP or DOWN arrow on the omni selector to select the [OK] [Analyze] then press key. Alternatively, touch/select the [Analyze] Icon to open the menu. Press the UP or DOWN arrow on the omni selector to select the [OK]...
  • Page 67 Move the line: • Select the line you want to move by tapping the line. • There are two methods to move the tool: Method1：Press the UP&DOWN arrow keys to move the line; press the LEFT&RIGHT arrow keys on the omni selector to move the triangle.
  • Page 68 Shoot Fulfill the Analysis Function Isotherm analysis Press the [C] key or touch/select the icon. Press the UP or DOWN arrow on the omni selector to select the [OK] [Analyze] then press key. Alternatively, touch/select the [Analyze] Icon to open the menu.
  • Page 69 Set isotherm range: • Start from Step 1 to set or select isotherm analysis. • Method 1：Press UP or DOWN arrow to select upper limit or lower limit. Press LEFT or RIGHT arrow to adjust the number. Method 2：Tap +/- beside the number to adjust the values.

  • Page 70: Alarm Temperature

    Shoot Fulfill the Analysis Function Alarm temperature Press the [C] key or touch/select the icon. Add a analyze spot tool, then press the [OK] key again or double tap spot to call the setting window of the spot. Press UP or DOWN arrow on the omni selector to highlight [Alarm Temp] or [Alarm Mode], press LEFT or RIGHT...

  • Page 71: Comparing Temperature

    Shoot Fulfill the Analysis Function Comparing temperature Press the [C] key or touch/select the icon. Add an area analysis tools. Press the [C] key. Press UP&DOWN arrow to highlight [Settings] and press the [OK] key to enter. Press the UP&DOWN arrow on the omni selector to highlight the [Analysis]...
  • Page 72 Tap the switch upper right corner of the interface. Tap to select the target and base, touch/select [+/-] to set the value of reference temperature. Press the [C] key twice to back to the main interface. Press the [C] key again to hide the menu. You can see the values of difference beside ‘Comp:’...

  • Page 73: Remove Analysis Tools

    Shoot Fulfill the Analysis Function Remove analysis tools This topic briefly explains how to remove all analysis tools you place on the screen. Touch/select the icon on the screen. How to call Quick Launcher, please refer to p23. In the pop-up menu bar on the right side touch/select [Clear] key to clear all the analysis tools.

  • Page 74: Save The Image

    Shoot Save the Image This topic briefly explains how to save your Image. Press the [C] key or touch/select the icon. Press the UP or DOWN arrow on the omni selector to highlight the [Media] menu, then press the OK key to enter.
  • Page 75 Alternatively, you can touch/select the icon on the screen. In the pop-up menu bar on the right side, touch/select [snapshot] key to save the image. Tips: You’d better freeze your Image before saving it. How to freeze your Image, you can refer to P54.

  • Page 76: Attach Voice Memos Images

    Shoot Attach Voice Memos Images You can introduce an image with voice recording. Voice record Install the Bluetooth headset. Press the UP or DOWN arrow on the omni selector to highlight the [Media] menu, then press the OK key to enter. Alternatively, touch/select the [Media] Icon to open the menu.
  • Page 77 In the pop-up menu bar， touch/select the icon. When change into , it means the voice is being recorded. Touch/select the icon again, stop the voice recording. Tap the [save] key to save the voice. Tap the [Play] to play the voice you just recorded.

  • Page 78: Snapshot And Edit The Image

    Shoot Snapshot and Edit the image Snapshot/Edit Press the [C] key or touch/select the icon. Press the UP or DOWN arrow on the omni selector to highlight the [Media] menu, then press the OK key to enter. Alternatively, touch/select the [Media] Icon to open the menu.
  • Page 79 Press the UP or DOWN arrow on the omni selector to highlight the [Edit], then press the [OK] key to enter. Alternatively, touch/select the [Edit] Icon to open the menu. In this menu, you can edit the image like adding the text or voice note.

  • Page 80: Record/Replay The Video

    Shoot Record/Replay the Video Record/Replay the Video Press the [C] key or touch/select the icon. Press the UP or DOWN arrow on the omni selector to highlight the [Media] menu, then press the OK key to enter. Alternatively, touch/select the [Media] Icon to open the menu.
  • Page 81 Press the UP or DOWN arrow on the omni selector to highlight [Replay] and press the [OK] key to replay the recorded video. Alternatively, touch/select the [Reply] Icon again to replay the video. Press the [C] key to exit after replaying. About the Replay toolbar Play or pause the playing Play：...

  • Page 82: Playback And Erase

    Playback and Erase Open Images You can view and analyze the recorded images on the LCD monitor. Open Images Press the [C] key or touch/select the icon. Press the UP or DOWN arrow on the omni selector to highlight the [Media] menu, then press the OK key to enter.
  • Page 83 You can analyze and attach voice memo to a recorded image when you open it. Photo edit sub menu description Analysis（Analysis tools can be used to analyze the heat images） Delete（Delete the currently selected picture） Slideshow（All current picture slideshow） Full screen(Full screen display picture) Text Note（Add text notes for the current picture）...

  • Page 84: File Manager

    Playback and Erase File Manager File manager Press the [C] key or touch/select the icon. Press the UP or DOWN arrow on the omni selector to highlight the [File], then press the OK key to enter. Alternatively, touch/select the [File] Icon to open the menu.
  • Page 85 About the File manager Home（Enter the home directory） Previous（Back to the parent directory） Remove（Remove the file or directory） Rename（Rename the file or folder） New（Build a directory） Copy（Copy the file） Paste（Paste the file） Refresh(Refresh the file list) Save Folder(Setting the saving path) Close(Close file manager)
  • Page 86 Selecting the file path Press the [C] key or touch/select the icon. Press the UP or DOWN arrow on the omni selector to highlight the [File], then press the OK key to enter. Alternatively, touch/select the [File] Icon to open the menu. Press the UP or DOWN arrow on the omni selector to highlight the folder you want...

  • Page 87: Connection And Download

    Connection and Download Download the images Download the images Open the USB / Video cover on the button of device. Use USB cable connect device to computer then modify device USB Mode to UDisk. Copy images and videos to your computer.

  • Page 88: Connect To A Video-Compatible Monitor

    Connection and Download Connect to a video-compatible monitor Connect to a video-compatible monitor A video-compatible monitor connected via the video cable (supplied) can be used to view and analyze images you shoot. Attach video cable to the video out terminal on bottom of camera.

  • Page 89: Connect To A Computer

    Connection and Download Connect to a computer Connection Connect the USB cable to the computer’s USB port and the multi-functional dock’s terminal. • You do not need to turn off the computer or camera when making this connection. • Please refer to your computer manual for information regarding the location of the USB port...

  • Page 90: Real-Time Transfer

    Connection and Download Real-time transfer Real-time transfer You can analyze and save the thermal video in computer directly via the USB by the optional real-time software. Power on the camera. Connect the camera and computer via USB cable. The operating system will recognize the camera automatically.
  • Page 91 Connection and Download Real-time transfer Troubles shooting When you have any problems in the process of connecting the IR camera to a computer to use optional real-time software, check this first. First, Check the Following 1. Does your computer comply with these requirements? Ensure the system has a built-in USB port.

  • Page 92: Use The Bluetooth Headset

    Connection and Download Use the Bluetooth headset Use the Bluetooth headset Follow the steps to install the Bluetooth headset for the first time. Set the camera as below：[Setting]— [System]—[Bluetooth]. Long press the Bluetooth headset power button for about 10 seconds to power indicator flash the red and blue lights to seek connecting state for the Bluetooth headset.
  • Page 93 Troubles Shooting Problem Cause Solution Camera will Power is not turned on. • Turn on the camera. See not operate Turning the Power On / Off (p.12). Insufficient battery voltage. • Fully charge the battery. Camera will Internal memory is full. •...

  • Page 94: Appendix

    Appendix How to setup for optional Lens There are optional lenses for D600 available, from telephoto lens to wide-angle lens. If you install the optional lens, the camera will automatic match corresponding camera image mode, through the magnetic core on the lens and the internal sensor in the camera. During this period, the image will be automatically adjusted several times for clear display.

  • Page 95: Attach Optional Lens

    Appendix Attach Optional Lens Attach Optional Lens Open the lens cover. Align the magnetic columns and the lens slots. Green to green, blue to blue and red to red. Please see the picture on the right. Notice： The three round holes on the lens must be in the lower right corner as shown on the right, otherwise the lens cannot be...
  • Page 96 After the lens is installed, D600 will automatically identify lens parameters, so there is no need to set in D600. For example, when you install the 12° lens, the menu will change as shown in the picture.

  • Page 97: Remove Optional Lens

    Appendix Remove Optional Lens Remove Optional Lens Rotate the lens according to the direction of the arrow on the right to remove the lens. Pull out the lens.

  • Page 98: Camera Care And Maintenance

    Appendix Camera Care and Maintenance Use the following procedures to clean the camera body, lens, LCD monitor and other parts. Wipe the body clean with soft cloth or eyeglass Camera Body lens wiper. First use a lens blower to remove dust and dirt, then remove any remaining dirt by wiping the lens lightly with soft cloth.

  • Page 99: Emissivity Table

    Appendix Emissivity table Emissivity Material Temperature（°C） approximation Metal Aluminum Polished aluminum 0.09 Commercial aluminum 0.09 foil Electrolytic 25～600 0.55 chromeplate alumina Mild alumina 25 ~ 600 0.10 ~ 0.20 Strong alumina 25 ~ 600 0.30 ~ 0.40 Brass Brass mirror (highly 0.03 polished) Brass oxide...
  • Page 100 Appendix Emissivity table (continue) Emissivity Material Temperature（°C） approximation Iron Polished cast iron 0.21 Processed cast iron 0.44 Polished tempered 40 ~ 250 0.28 Iron Polished steel ingot 770 ~ 1040 0.52 ~ 0.56 Raw welded steel 945 ~ 1100 0.52 ~ 0.61 Surface ferric oxide 0.69 Completely rusty...
  • Page 101 Appendix Emissivity table (continue) Emissivity Material Temperature（°C） approximation Lead Pure lead (Non- 125～225 0.06～0.08 oxidization) Mildly oxidized 25 ~300 0.20 ~ 0.45 Magnesium Magnesia 275 ~ 825 0.55 ~ 0.20 Magnesia 900 ~ 1670 0.20 0 ~ 100 0.90 ~ 0.12 Nickel Electroplate polishing 0.05...
  • Page 102 Appendix Emissivity table (continue) Emissivity Material Temperature（°C） approximation Stainless steel 18-8 0.16 304(8Cr,18Ni) 215 ~ 490 0.44 ~ 0.36 310(25Cr,20Ni) 215 ~ 520 0.99 ~ 0.97 Commercial tin plate 0.07 Strong oxidization 0 ~ 200 0.60 Zinc Oxidizing at 400°C 0.01 galvanized shining 0.23...
  • Page 103 Appendix Emissivity table (continue) Emissivity Material Temperature（°C） approximation Carbon piece 0.85 Isolation piece 0.91～0.94 Sheet metal 0.88 ~ 0.90 Glass pipe 0.90 Loop type 0.87 Porcelain enamel 0.90 products Porcelain enamel 0.83～0.95 designs Solid materials 0.80 ~ 0.93 Ceramics (vase type) 0.90 Film 0.90 ~ 0.93...
  • Page 104 Appendix Emissivity table (continue) Emissivity Material Temperature（°C） approximation Electric materials Epoxy glass plate 0.86 Epoxy 0.80 hydroxybenzene plate Gilded sheet copper 0.30 Solder-coated copper 0.35 Tin-coated lead wire 0.28 Brass wires 0.87 ~ 0.88 Block talcum terminal 0.87...

  • Page 105: Specification

    Specification All data is based on SATIR’s testing standard. Subject to change without notice. Type D600 Image performance FOV/Min. focus distance 24° x18°/0.35m Spatial resolution 0.65 mrad Thermal sensitivity 0.05℃@30℃ Detector type UFPA Resolution 640x480 Spectral range 8-14um Focus Motor/Auto...
  • Page 106 Image storage Type 16GB TF card IR Image：.JPG(thermal/Visual) Image format CCD Image：.JPG Video format .MPEG Annotation Voice, note annotation Power system Battery type Built-in rechargeable lithium-ion battery Charge interface Type-C Battery operating time 8 hours Power manage Auto shut off / Sleep mode Environment specification Operating temperature range -20°C to +50°C...
  • Page 107 Additional features Illuminator Laser pointer Video record Ports USB port , Analog video output Bluetooth Available optional lenses 7°, 12°, 48°...
  • Page 108 Please download quick user guide, user manual and SatIrReport Software from SATIR website if you need. Download Link: www.satir.com Manufacturer information Manufacturer：SATIR Europe(Ireland) Co.,Ltd. Factory address：Marleys Business Park, Marleys Lane, Drogheda, Co.Louth, A92 PX6P, Ireland URL：www.satir.com E-mail：enquiry@satir.com service@satir.com Technical enquiry Tel：00353 (0) 41 9844371...
