Fire Fighting IR Camera
HRYXJ-A
User's manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HRYXJ-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Satir HRYXJ-A

Summary of Contents for Satir HRYXJ-A

  • Page 1 Fire Fighting IR Camera HRYXJ-A User’s manual...

  • Page 2: Table Of Contents

    HRYXJ - A Op erational Manual Contents 1 Brief introduction…………….….……......…….…2 1.1 Brief introduction…………………………….………………2 1.2 Packing………………….………………………...…………2 2 Component guide………..………………………..…………..3 3 Basic function………………………………………..…….…….4 3.1 How to operate…………………………………….…………..4 3.1.1Power on ………………………………………………………4 3.1.2 Operation………………………………………………………4 3.2 Indicators on the screen…….…………………….…………..5 4 Battery pack and charger………………………...……….…….6 4.1 Battery Pack.……………………………………………..…...6 4.2 Battery charger…..………………………………...………….6 4.3 Appendix…………………………….…………..….………….7...

  • Page 3: Brief Introduction

    1 Brief introduction 1.1 Brief introduction ： HRYXJ-A was manufactured by Guangzhou SAT Infrared Technology Co., LTD. It is a smaller size, easier operating and stronger functioned infrared camera. HRYXJ-A combines the technologies of advanced detector, IR image processing and computer.

  • Page 4: Component Guide

    HRYXJ - A Op erational Manual 2. Component guide IR lens Battery Viewfinder Power indicator Power switch Video output ] key ] key [S] Key ＋ －...

  • Page 5: Basic Function

    HRYXJ - A Op erational Manual 3. Basic function How to operate ． 3.1.1 Power on Press the power button to turn on the camera. 3.1.2 Operation “+”: manual adjust; (In alarm setting mode, increase the temperature). “-”: change the temperature measurement range; (In alarm setting mode, decrease the temperature).

  • Page 6: Indicators On The Screen

    HRYXJ - A Op erational Manual Indicators on the screen ． Temperature Battery Status Palette L: low temperature measurement range H: high temperature measurement range...

  • Page 7: Battery Pack And Charger

    HRYXJ - A Op erational Manual 4 Battery pack and charger 4.1 Battert pack This is a NiMH battery. It can be recharged at any time. However, since the maximum number of charge circle is approximately 500 (battery life), you are recommended to only charge the battery pack after having discharge it completely to prolong battery life.

  • Page 8: Appendix

    HRYXJ - A Op erational Manual Disc harge LED Power LED Charge LED Discharge button Charging mode button 4.3 Appendix  Heat will build up in the charging process.  The charger shuts down when the battery is full. But it is recommended to remove the battery after charged.

  • Page 9: Active Battery

    HRYXJ - A Op erational Manual  Use only the recommended power accessories. Use of power source not expressly recommended for this camera may lead to overheating, distortion of the camera, fire, electrical shock or other hazards.  Before you discard a battery, cover the terminal with tape or other insulators to prevent direct contact with other objects.
  • Page 10 HRYXJ - A Op erational Manual  Press and hold the Active key about 10 seconds. Then the battery will be active and the Charger LED flashes.  When press and hold the Active key longer than 30 seconds, and the Charger LED doesn’t flash. It is possible that the battery is broken.

  • Page 11: Care And Maintenance

    HRYXJ - A Op erational Manual 5 Care and maintenance 5.1 Care and maintenance 5.1.1 Lens First use a lens blower brush to remove dust and dirt, then remove any remaining dirt by wiping the lens lightly with soft cloth or eyeglass lens wiper. 5.1.2 Viewfinder Use a lens blower to remove dust and dirt.

  • Page 12: Trouble Shooting

    HRYXJ - A Op erational Manual 6 Trouble shooting Problem Cause Solution • Turn on the camera. Power is not turned on • Fully charge the Insufficient battery Camera will not voltage battery. operate Poor contact • Wipe the terminals between camera and with a clean, dry cloth.

  • Page 13: Specifications

    HRYXJ - A Op erational Manual 7 Specification Image performance Thermal FOV/ min. focus distance 56°×42° Spatial resolution 2.5mrad NETD @ 50/60 Hz 100mK Detector type Focal Plane Array (FPA), uncooled microbolometer Resolution 384×288 Spectral range 8～14um Image presentation Viewfinder High resolution viewfinder Video output PAL or NTSC composite video...
  • Page 14 UL94-V0 Operating temperature 80°C 30mins 120°C 10mins 260°C 5mins Physical characteristic 1250g Weight （ inc. battery ） Size (L*W*H) 175 mm ×119mm ×125mm Statement Thank you for using HRYXJ-A IR camera. We are so grateful for your support and trust.

  • Page 15: Statement

    This product is manufactured by GUANGZHOU SAT INFRARED TECHNOLOGY CO., LTD..(SATIR) We guarantee that each HRYXJ-A IR camera complies with the corporate standards of GUANGZHOU SAT INFRARED TECHNOLOGY CO., LTD.. We provide one-year warranty calculating from the date of delivery for any materials or process defects under proper storage, operation and service.
  • Page 16 HRYXJ-A Operational Manual...
