Satir CK350-W User Manual

Monitoring ir camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Monitoring IR Camera
CK350-W
User's manual
Trademark Acknowledgments
• SATIR is a trademark of SATIR Ltd.
• Other names and products not mentioned above may be registered g
trademarks or trademarks of their respective companies.
Copyright © 2017 SATIR Ltd. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CK350-W and is the answer not in the manual?

Questions and answers

Related Manuals for Satir CK350-W

Summary of Contents for Satir CK350-W

  • Page 1 CK350-W User’s manual Trademark Acknowledgments • SATIR is a trademark of SATIR Ltd. • Other names and products not mentioned above may be registered g trademarks or trademarks of their respective companies. Copyright © 2017 SATIR Ltd. All rights reserved.
  • Page 2 Copyright statement: This copyright of this manual belongs to GuangZhou SAT infrared corporation (SATIR), without permission, any organization or individual shall not copy, reproduce all or part of the contents. SAT reserves the right to change the functions and configurations of our products without prior notice Any questions please contact us or our legitimate dealers.

  • Page 3: Table Of Contents

    Read first Introductions Parts introduction Equipment installations Devices connection Remote landing WEB setting Software Setup Troubles Shooting Appendix Performance parameters...

  • Page 4: Read First

    1.1.1 Warning 1、 Before the installation and using of infrared thermal imaging intelligent monitoring system CK350-W, please read the user manual carefully, and properly keep for future use. 2、 Should abide by the user manuals for all warnings; comply with all instructions.
  • Page 5 9、 when cleaning the thermal imager, first disconnect the power supply, wipe with a damp cloth. Do not use substances containing alcohol, benzene, thinners or other flammable substances to clean or maintain the IR camera The use of these substances may lead to fire. Do not handle the power cord if your hands are wet 10、...

  • Page 6: Warranty And Technical Support

    5、 Thermal imager installed outdoors, should take effective waterproof, damp proof, dust proof measures such as: Immersion, head of the waterproof connector must be tightened. 1.2 In order to avoid failure Read on to learn about preventing malfunction of IR camera : Avoid Condensation Related Problems Moving the IR camera rapidly between hot and cold temperatures may cause condensation (water droplets) on its external and internal surfaces.

  • Page 7: Introductions

    2 Introductions Application The intelligent monitoring system (CK350-W), which consists of all-weather IR monitoring cameras and corresponding network of computers. With advanced data compression and network transmission technology, common functions such as camera settings, over-temperature alarm, auto-video recording and much more can be adjusted remotely via a standard Ethernet network cable.

  • Page 8: Front View

    Appearance and interface Front View: Thermal camera Bottom View: P ower input and RJ45 interface Mounting...

  • Page 9: Equipment Installations

    4 Equipment installations Installation of monitoring systems confirmations before installation Based on the transportation safety considerations, thermal imager is mainly divided into infrared monitor and platform part two, divided into two boxes. Before installation please pay attention to the following matters. 4.1.1 Parts confirmation Open the packaging box, confirm the following parts, if lack, please contact the supplier.
  • Page 10 4.2 Installation personnel requirements The user has been completely read the entire manual. With the basic knowledge and skills of low-voltage wiring and low-voltage electronic circuit wiring . Has the qualification certificates of the CCTV system installation and maintenance work. And has the qualification certificate of related work (such as aerial work, etc.) ※...
  • Page 11 4.4 Installation Tools Flat-blade screwdriver Hex Wrench（3mm） Wrench（8〞） Phillips screwdriver（小） 4.5 Cable Select the cable according to distance : 4.5.1. Network Cable ANSI/EIA/TIA-568A/BandISO/D used to run10M/100Mbps Ethernet over unshielded Category 5 or Category 5 twisted pair cable. 4.5.2. AC24V Power cord Use the power cable enough to withstand the load, following data are available.
  • Page 12 Note: According to the power of the system and other accessories, it is recommended that users use at least 100W power AC24V power cord , wiring harness when installing select on table content to deepen part of the requirements for power cord advise clients to construction , please refer to the table .
  • Page 13 Use shielded twist pair, must be effectively connected to GND, When using bare wire diameter 0.56mm shielded twisted pair , the following baud rate and transmission distance data for reference: 2.400，about 1,800m 4,800，about 1,200m 9,600，about 800m 4.6 start installation 4.6.1 PTZ installation instructions Note: 1.
  • Page 14 The size of base plate Note：Unit mm 4.6.3 Variable-speed PTZ and fixed supports after installing the detector, use M8X45, φ8 flat pad,φ8 spring washers and M8 nut head to fix PTZ and bracket 。 Note：Unit mm...
  • Page 15 4.6.4 Connect wiring 1. System connection, connection ports as shown in figure 2. To protect the lightning, the pan-tilt should be connected to ground. Please follow the next steps to connect pan-tilt to ground. 1. Unscrew the two M3X8 cross screws and take out the connected board.
  • Page 16 Connected Board oard 2. Use two outlet port protection to avoid water or moisture 3. Connect the external cable...
  • Page 17 Connected Board Definition: Definition Definition Ground Alarm AC24V RS485 Ground AC24V Video core RS485B Video Ground RS485A Note： 1. When connect PTZ power line (AC24V) to power line inside the distribution box, must welding, and wrapped with waterproof tape. After connecting the wiring harness please detect the short circuit.

  • Page 18: Devices Connection

    5 Devices connection Connect thermal imager 1. Please use the two with a standard RJ45 crystal connector cable, the thermal image monitoring system network interface connected to the router or switch. Then will the router is connected to the computer network.

  • Page 19: Remote Landing

    6 Remote landing Connect PC You can use the IE browser to directly access the thermal imager . If your computer has installed monitoring software , you can also use it to access the thermal imager . 6.1 WEB services 6.1.1 Preparation The original IP address of the camera is 192.168.1.2, Subnet mask 为...
  • Page 20 2. In the Internet options dialog box, choose the “security” label, and then in the security level for this zone click the “custom level” bottom, then the security settings box is open.
  • Page 21 3. In the security settings box, in the “ActiveX controls and plug-ins” options ,set the following options as “enable”: Automatic prompting for ActiveX controls, Download signed ActiveX controls, Download unsigned ActiveX controls, Initialize and script ActiveX controls not marked as safe, Run ActiveX controls and plug-ins And the other options retain the default value.
  • Page 22 2.After installed the ActiveX controls, the login page appears as shown below : Login screen 4. Input the log on items as below: Items Content language Chinese or English User Name Input the User Name, the default value is Admin Password Input the Password, the default value is Admin Port...

  • Page 23: Web Setting

    7 WEB setting WEB server settings Note: 1、 Different types of thermal camera will get different thermal video. 2、 Microsoft IE version 6.0 or above PTZ control 1. Click the [Device] item after log on.
  • Page 24 2. The items of [Device] is below: Items Content Protocol The protocol of controlling PTZ, the default is Pelco-P Status The status of PTZ, the default is 9600 Address The address of PTZ, the default is 2 SetView Set the angle of PTZ pointing CallView Rotate PTZ to the angle of SetView Speed...

  • Page 25: Advanced Settings

    7.2 Display settings Note: Please don’t change the settings not mentioned, in order to avoid unintended consequences, resulting in the damage of thermal imager. Set the display through the right part of the interface Brightness Contrast Saturation (not used yet) Tone (not used yet) Adjust the display mode under the images Single screen Four screen Nine screen Sixteen screen Full-screen...
  • Page 26 Here you can set the video block area, the display frame rate and stream.
  • Page 27 7.3.2 Video parameter Click on the right part of the interface to set video parameter. Here you can change detail settings, such as the frame rate, rate of resolution.
  • Page 28 7.3.3 OSD Click [OSD] on the right part of the interface to set Character overlap. Here, you can set the characters, such as adding the channel name, time, date, additional characters, can also change the character superimposing position.
  • Page 29 7.3.4 Alarm settings Click [Alarm settings]-[Port Alarm] on the right part of the interface to set this parameter. Only need to change the items like the picture when encountering the following conditions: a．Thermal imager network module reset. b．Thermal imager does not alarm .
  • Page 30 7.3.5 Network parameters 1、 Wire setting Click [Wire Setting] on the right part of the interface to set this parameter. Here you can set gateway IP address, DNS, WEB port according to the reality.
  • Page 31 2、 DDNS setting Click [DDNS Setting] on the right part of the interface to set this parameter. Here you can set DDNS DDNS (Dynamic DNS) is a method/protocol/network service that provides the capability for a networked device, such as a router or computer system using the Internet Protocol Suite, to notify a Domain Name System (DNS) name server to change, in real time, the active DNS configuration of its configured hostnames, addresses or other information.
  • Page 32 3、 POE setting Click [PPPOE] on the right part of the interface to set this parameter. Here you can set the PPPOE account number, password according to the reality. Generally used when ADSL broadband access is needed. The Point-to-Point Protocol over Ethernet (PPPoE) is a network protocol for encapsulating Point-to-Point Protocol (PPP) frames inside Ethernet frames.
  • Page 33 7.3.6 Advanced Options 1、 Version information Click [Version Information] on the right part of the interface to set this parameter. Here, you can see imager network module, serial number, firmware version. 2、 System information Click [System Information] on the right part of the interface to set this parameter.
  • Page 34 3、 Access platform Click [Access platform]on the right part of the interface to set this parameter. The existing platform is compatible with the ONVIF protocol, can be start according to actual need.
  • Page 35 4、 User Management Click [User Management] on the right part of the interface to set this parameter. The setting for this project is as follows: Items Content User List Select user User’s name User Name Old pwd Old password New Pwd New password Password Confirm Confirm new password...
  • Page 36 5、 Connect info Click [Connect Info] on the right part of the interface to set this parameter. Here you can see the current thermal imager connection information.
  • Page 37 6、 Upgrade Click [Upgrade] on the right part of the interface to set this parameter. Here you can upgrade the firmware of imager network module Upgrade process: 1、 When upgrading the kernel , click the [Browse] button on the top , choose the .bin file , then click [ Upgrade] button and wait for the prompts to complete the upgrade .

  • Page 38: Software Setup

    8 Software Setup Client Installation 8.2 Software Setup 1. Double click the program file icon, then customize the Setup or use the default setup.，...
  • Page 39 Click [ Next ] button to start the installation :...

  • Page 40: Software Operation

    8.3 Software Operation Specific software instructions see the supplied manual. Shortcut Key： F1: Open the software instructions. F2: Open server search software. F3: Show the software version.

  • Page 41: Troubles Shooting

    Troubles Shooting Trouble Possible reasons Solution After electrical Power wires Please re - check the wiring connection , failure PTZ not self-test , no infrared power system images Please replace the power supply was damaged PTZ not self-test , the PTZ board failure overhaul infrared image is...
  • Page 42 PTZ can self- test, but no infrared image , Lack of power Please check whether the input voltage or image input could meet the requirements instable PTZ can PTZ parameters Please keep the PTZ parameters to the self-test, was modified default settings , that is, the address can't be bits is 2 , the baud rate...
  • Page 43 Not set the over- Re - set the over temperature alarm temperature value alarm value Error alarm Re- set alarm setting in accordance settings with 7.3.4 Circuit board overhaul failure...
  • Page 44 Specification All data are based on the test standards of the SAT. Those data are subject to change without notice . Model CK350-W FOV/Min Focus distance 24°×18°/50cm Detector type Resolution 384×288 Spatial resolution 1.09mrad Spectral range 8～14um NETD 60mK@30°C Focus Motorized（software control）...
  • Page 45 Product specifications and designs are subject to change without notice. There may be minor differences between this manual and the actual screen...
