SMSC FlexPWR LAN8710 Specification Sheet

Mii/rmii 10/100 ethernet transceiver with hp auto-mdix and flexpwr technology in a small footprint
Table of Contents

Advertisement

Quick Links

PRODUCT FEATURES

Highlights
Single-Chip Ethernet Physical Layer Transceiver
(PHY)
Comprehensive flexPWR
— Flexible Power Management Architecture
— Power savings of up to 40% compared to competition
— LVCMOS Variable I/O voltage range: +1.6V to +3.6V
— Integrated 1.2V regulator with disable feature
HP Auto-MDIX support
Small footprint 32 pin QFN lead-free RoHS compliant
package (5 x 5 x 0.9mm height)
Target Applications
Set-Top Boxes
Networked Printers and Servers
Test Instrumentation
LAN on Motherboard
Embedded Telecom Applications
Video Record/Playback Systems
Cable Modems/Routers
DSL Modems/Routers
Digital Video Recorders
IP and Video Phones
Wireless Access Points
Digital Televisions
Digital Media Adaptors/Servers
Gaming Consoles
POE Applications
SMSC LAN8710/LAN8710i
MII/RMII 10/100 Ethernet
Transceiver with HP Auto-MDIX
and flexPWR
Small Footprint
®
Technology
DATASHEET
LAN8710/LAN8710i
®
Technology in a
Key Benefits
High-Performance 10/100 Ethernet Transceiver
— Compliant with IEEE802.3/802.3u (Fast Ethernet)
— Compliant with ISO 802-3/IEEE 802.3 (10BASE-T)
— Loop-back modes
— Auto-negotiation
— Automatic polarity detection and correction
— Link status change wake-up detection
— Vendor specific register functions
— Supports both MII and the reduced pin count RMII
interfaces
Power and I/Os
— Various low power modes
— Integrated power-on reset circuit
— Two status LED outputs
— Latch-Up Performance Exceeds 150mA per EIA/JESD
78, Class II
— May be used with a single 3.3V supply
Packaging
— 32-pin QFN (5x5 mm) Lead-Free RoHS Compliant
package with MII and RMII
Environmental
— Extended Commercial Temperature Range (0°C to
+85°C)
— Industrial Temperature Range (-40°C to +85°C) version
available (LAN8710i)
Datasheet
Revision 1.0 (04-15-09)
