BHT-400BB-CE
BHT-400BWB-CE
This guide has been
prepared expressly for the
hands-on user.
Always keep it nearby for
speedy reference.
Operator's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BHT-470BWB-CE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Denso BHT-470BWB-CE

Summary of Contents for Denso BHT-470BWB-CE

  • Page 1 BHT-400BB-CE BHT-400BWB-CE Operator’s Guide This guide has been prepared expressly for the hands-on user. Always keep it nearby for speedy reference.
  • Page 2 ? If it is judged by DENSO WAVE INCORPORATED that malfunction of the product is due to the product having been dropped or subjected to impact, repairs will be made at a reasonable charge even within the warranty period.
  • Page 3 Instructions for using the handy terminal (BHT-400BB- CE/400BWB- CE) and optical communication unit (CU-400). BHT-400-CE API Reference Manual (This manual can be downloaded from our Web site given below.) Description for developing application programs for the handy terminal in Microsoft eMbedded Visual C++ 4.0. DENSO WAVE INCORPORATED http://www.denso- wave.com/...

  • Page 4: Table Of Contents

    Contents SAFETY PRECAUTIONS ....................5 Components and Functions....................10 Operating the Touch Screen....................14 Windows Desktop on the LCD................... 14 Reading Bar Codes ......................15 ® Using Radio Link and Bluetooth Wireless Communication Link.......... 17 Using Infrared Link......................18 Loading the Battery Cartridge.................... 19 Calibrating the Touch Screen....................

  • Page 5: Safety Precautions

    SAFETY PRECAUTIONS Be sure to observe all these safety precautions. Strict observance of these warning and caution indications are a MUST for preventing accidents which could result in bodily injury and substantial property damage. Make sure you fully understand all definitions of these terms and related symbols given below, before you proceed on to the text itself.
  • Page 6 Handling the battery cartridge ? Only use the dedicated charger for charging the rechargeable battery cartridge. Using a different type of charger could cause battery-rupture or leakage of battery fluid and result in a fire, bodily injury, or serious damage to property. ? Never disassemble or heat the rechargeable b attery cartridge, nor put it into fire or water;...
  • Page 7 Handling the BHT ? The BHT uses a laser light for indicating the scanning range. The intensity of the laser light might be too low to inflict bodily injury. However, do not look into the laser beam or view directly with optical instruments.
  • Page 8 Handling the rechargeable cartridge ? Never charge a wet or damp rechargeable battery cartridge. Doing so could cause the batteries to break, generate heat, rupture or burn. Handling the BHT ? If smoke, abnormal odors or noises come from the BHT, immediately turn off the power, pull out the battery cartridge, and contact your nearest dealer.
  • Page 9 LCD. ? Limited Warranty on Software Products In no event will DENSO WAV E INCORPORATED be liable for direct, indirect, special, incidental, or consequential damages (including imaginary profits or damages resulting from interruption of operation or loss of business information) resulting from any defect in the software or its documentation or resulting from inability to apply the software or its documentation.

  • Page 10: Components And Functions

    Components and Functions *Provided on the BHT-400BWB-CE Touch screen LCD Built-in antenna* (liquid crystal display) （ for Wireless LAN ） Do not cov er this Shows the characters and graphic patterns. You may directly tap the screen with the stylus for data entry. antenna section with metal-evaporated tape or by hand.
  • Page 11 31-key pad Magic keys (M1 to M4) Other functions, such as SF key and ENT key functions, can be assigned to Magic Keys (M1 to M4). For details, refer to the BHT-400B-CE/400BW -CE User’s Manual. Trigger switch Trigger switch (M3 key) (M4 key) Scan key Also functions as a...
  • Page 12 50-key pad (Phone -type key layout) Magic keys (M1 to M4) Other functions, such as SF key and ENT key functions, can be assigned to Magic Keys (M1 to M4). For details, refer to the BHT-400B-CE/400BW -CE User’s Manual. Scan key Also functions as BS (Backspace) key a trigger switch to...
  • Page 13 50-key pad (Calculator-type key layout) Magic keys (M1 to M4) Other functions, such as SF key and ENT key functions, can be assigned to Magic Keys (M1 to M4). For details, refer to the BHT-400B-CE/400BW -CE User’s Manual. Scan key Also functions as BS (Backspace) key a trigger switch to...

  • Page 14: Operating The Touch Screen

    Operating the Touch Screen You can perform tasks by tapping the elements on the touch screen LCD with the stylus that comes with the BHT. Action Description Refers to touching the LCD once. (Functionally equivalent to "click" with a mouse on a PC. Double-tap Refers to quickly touching the LCD twice.

  • Page 15: Reading Bar Codes

    Reading Bar Codes Turn the BHT on, bring the bar-code reading window to the bar code to be scanned, and press the trigger switch. Pressing the trigger switch halfway emits a laser light to indicate the scanning range and pressing it fully turns on the illumination LED to scan the bar code.
  • Page 16 ? If the BHT fails to read due to specular effects or other factors, change the scanning angle of the reading window or the distance from codes as shown at right, and try it again. (Specular effects occur when the reflection of the light from the bar code becomes excessively strong.

  • Page 17: Using Radio Link And Bluetooth Wireless Communication Link

    ® Using Radio Link and Bluetooth Wireless Communication Link The BHT-400BB- CE/400BWB- CE supports spread spectrum communication. • If there are too many communications errors, first make sure that the BHT-400BB- CE/400BWB- CE points directly at an access point because the 2.4-GHz band requires a more or less straight line path.

  • Page 18: Using Infrared Link

    Using Infrared Link ?? CU- 400 Make sure that the BHT is securely in the CU-400. Shield the IrDA interface from direct sunlight, ambient intense lighting (inverter-driven fluorescent lighting, in particular), and other potential sources of infrared radiation. Sourc es to watch out for include remote control units for television sets and the like.

  • Page 19: Loading The Battery Cartridge

    Loading the Battery Cartridge Before the first use of the BHT, be sure to load the battery cartridge as shown below. The battery cartridge is not loaded in the BHT when shipped from the factory. (1) Turn the BHT upside down. (2) Slide the release buttons in the direction shown below and remove the battery cartridge cover.
  • Page 20 • The BHT integrates a rechargeable backup power source which backs up the memory and calendar clock in the BHT when no battery cartridge is loaded or the voltage level of the battery cartridge drops below the specified level. The backup power source is automatically charged by the battery cartridge.

  • Page 21: Calibrating The Touch Screen

    Calibrating the Touch Screen At the first use of the BHT, you need to calibrate the touch screen and set up the calendar clock. Press the power key to turn on the BHT. The calibration screen appears, so follow the on-screen instructions. If nothing appears, first perform a "cold boot"...

  • Page 22: Bht Turning-Off Notes

    BHT Turning-off Notes If you press the power key to turn off the BHT, the BHT displays the following message and starts preparation for shutdown. When the above message is displayed, do not remove the battery cartridge. If you do so, the data stored in the BHT may be lost.

  • Page 23: Battery Replacement Notes

    • Use only DENSO WAVE-authorized battery cartridges and chargers. • Never dispose of battery cartridges into a fire. They should be recycled properly. Do not throw them in a trash.

  • Page 24: Warm And Cold Booting

    Warm and Cold Booting ?? Warm-booting the BHT In any of the following cases, warm-boot the BHT: • The BHT makes no response to entry from the touch screen or keys. • The programs in the BHT malfunction due to any problems. Warm-booting the BHT will not erase data stored in the RAM, but it will erase data being edited and not be saved.
  • Page 25 ?? Cold-booting the BHT If a problem persists even after warm-booting the BHT, cold-boot the BHT. Cold-booting the BHT will erase all data stored in the RAM. It is recommended that important data b e saved into the FLASH folder or uploaded to the host computer.

  • Page 26: About Status Indicators

    About Status Indicators Battery voltage level Shows the current battery voltage level. Displays when the voltage level is high. Displays when the voltage level is low. The displayed battery level shows the terminal voltage of the battery cartridge, not how much power is left. The battery voltage level varies depending upon the operation of the BHT, so the displayed level also may vary.
  • Page 27 ActiveSync Displays when the BHT is communicating with the PC via Microsoft ActiveSync. Alphabet input state Displays when the alphabet input function is activated. (Pressing the ALP key switches between the numeric entry and alphabet entry modes.) The ALP window appears when the alphabet input function is activated. Pressing any numeric key displays the alphabet letter assigned to that key in this ALP window.

  • Page 28: Setting The Backlight

    Setting the Backlight Pressing the right-hand trigger switch (M4 key) with the SF key held down activates or deactivates the backlight function. Backlight Off or Dim (The backlight function is Disable when you turn the BHT power on.) Press the right-hand trigger switch while holding down SF.

  • Page 29: Adjusting The Beeper Volume, Switching The Beeper & Vibrator, Calibrating The Touch Screen, And Setting The Backlight

    Adjusting the Beeper Volume, Switching the Beeper & Vibrator, Calibrating the Touch Screen, and Setting the Backlight You can adjust the beeper volume, switch the beeper and vibrator on and off, calibrate the touch screen, and set the backlight according to the procedure below. Double-tap BHTSHELL on the desktop to call up the System Menu.
  • Page 30 Choose "3:Device." The Device setting menu appears as shown at left.
  • Page 31 Adjusting the beeper and switching the beeper and vibrator Choosing "2:Beeper/Vibration" Device setting menu calls up the screen shown at left. On this menu, you can adjust the beeper volume and switch the beeper and vibrator. Choosing the Volume tab calls up the screen shown at left.
  • Page 32 Calibrating the touch screen Choosing "3:Display" on the Device setting menu calls up the screen shown at left. Choosing "1:Calibration" on the Display setting menu calls up the screen shown at left. Follow the instructions on the screen. Refer to the "Calibrating the Touch Screen."...
  • Page 33 Setting the backlight Choosing "5:Backlight" on the Device setting menu calls up the screen shown at left. - Backlight function Enable or disable the backlight function. If it is enabled, the backlight comes on when you press any key or tap the touch screen. - Backlight On-duration Set the ON- duration of the backlight that comes on when you press any key or tap the touch screen.

  • Page 34: Error Messages

    Error Messages If some error occurs when the power is turned on or during program execution, one of the following error messages will appear on the LCD. System Program error ? Problem A System Program error has occurred. ? Solution Contact your system administrator.
  • Page 35 Shutdown due to low battery ? Problem When the power is turned on or off or during execution of programs, the battery output level has lowered to the extent the BHT can no longer operate. If lower battery is detected, the BHT beeps five times (for 0.1 second per beep) and then turns itself off.

  • Page 36: Proper Care Of The Bht

    Proper Care of the BHT Wipe the BHT's charge terminals and battery cartridge terminals with a cotton swab or the like periodically. Clean the BHT housing with a dry, soft cloth. Before cleaning, be sure to turn the BHT off. ? Never use benzene, alcohol, or other organic solvents.

  • Page 37: Handling Notes

    Handling Notes ? An early upload of gathered data is recommended, since the data stored in the RAM might be affected by the so-called "soft error" or other environmental phenomena. ? Do not use the BHT in the vicinity of radio equipment. The BHT may malfunction. ? Avoid storing the battery cartridge in a hot place.
  • Page 38 US and Canada Regulations BHT-400BWB- CE(BHT-420BWB- CE/470BWB- CE) complies with Part 15 of FCC rules and RSS- Gen of IC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 39: Declaration Of Conformity (For European Union)

    Directive 99/5/EC (R&TTE) Manufacturer or Authorized representative : DENSO WAVE INCORPORATED Address : 1 - 1 S h o w a - c h o , K a r i y a - shi, Aichi - k e n , 4 4 8 - 8 6 6 1 , J a p a n...
  • Page 40 Directive 99/5/EC (R&TTE) Manufacturer or Authorized representative : DENSO WAVE INCORPORATED Address : 1 - 1 S h o w a - c h o , K a r i y a - shi, Aichi - k e n , 4 4 8 - 8 6 6 1 , J a p a n We declare on our sole responsibility, that the following product : : Radio frequency module ，...
  • Page 41 LABELING: BHT-400BB BHT-400BWB BHT-400BWB （ For European Union ） （ For USA and Canada ）...

  • Page 42: Customer Registration

    "QBnet" Contents Information searching ● Download service ● Inquiry with email ● ※ These are subject to change without notice How to Register Through Internet at the following address http://www.denso-wave.com/en/adcd/support/ After going into Internet, please access the above- mentioned URL address.
  • Page 43 4-2-12, Toranomon, Minato-ku, Tokyo, Japan 105-0001 http://www.denso- wave.com/ 496487 -5231...
