Smith Cast Iron Boilers GVIOM-5R Installation & Operating Instructions Manual

Natural or propane gas boiler
Hide thumbs
Table of Contents

Advertisement

Quick Links

NATURAL OR PROPANE GAS BOILER
INSTALLATION & OPERATING
DESIGNED AND TESTED ACCORDING TO A.S.M.E. BOILER AND PRESSURE
VESSEL CODE, SECTION IV FOR MAXIMUM ALLOWABLE WORKING PRESSURE OF
NOTE TO INSTALLING CONTRACTOR: READ THESE INSTRUCTIONS CAREFULLY.
THEY WILL SAVE YOU TIME IN ASSEMBLING BOILER PROPERLY.
WARNING: Installation and service must be performed by a qualified installer, service
agency or the gas supplier in accordance with all local and national codes. Failure to
comply with this warning can result in a fire or explosion causing property damage,
personal injury or loss of life!
WARNING: If the information in this manual is not followed
exactly, a fire or explosion may result causing property damge,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors and liquids
in the vicinity of this or any other appliance.
• Do not try to light any appliance.
• Do not touch any electrical switch. Do not use any phone in your
building.
• Immediately call your gas supplier from a neighbor's phone. Follow
the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified in
service agency or the gas supplier.
INSTALLER, THESE INSTRUCTIONS TO BE AFFIXED ADJACENT TO THE BOILER.
CONSUMER, RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE PURPOSES.
In Canada: 5211 Creekbank Road, Mississauga, Ont. L4W 1R3 (905) 625-2991 Fax (905) 625-6610
GV100W
INSTRUCTIONS
50 PSI, 345 kPa WATER
What to do if you smell gas:
WESTCAST, INC.
260 NORTH ELM STREET WESTFIELD, MA 01085
TEL. (413) 562-9631 FAX (413) 562-3799
GVIOM-5R
staller,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GVIOM-5R and is the answer not in the manual?

Questions and answers

Related Manuals for Smith Cast Iron Boilers GVIOM-5R

Summary of Contents for Smith Cast Iron Boilers GVIOM-5R

  • Page 1 Installation and service must be performed by a qualified in service agency or the gas supplier. INSTALLER, THESE INSTRUCTIONS TO BE AFFIXED ADJACENT TO THE BOILER. CONSUMER, RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE PURPOSES. In Canada: 5211 Creekbank Road, Mississauga, Ont. L4W 1R3 (905) 625-2991 Fax (905) 625-6610...

  • Page 2: Table Of Contents

    50 psi, 345 kPa in accor- dance with the A.S.M.E. Boiler and Pressure Vessel Code, Section IV for cast iron boilers. Each boiler has been equipped with a 30 psi pressure relief valve. This manual covers the application, installation, operation and maintenance of a GV100W low pressure hot water boiler.

  • Page 3: Boiler Ratings & Capacities

    Also ensure that the boiler has been set up for the type of gas available at the installation site. Other important considerations are the availability of an adequate electrical supply, fresh air for combustion and a suitable chimney or vent system location.

  • Page 4: Combustible Floor Option

    Tightly thread a 1 1/4" elbow onto the close nipple in the supply pipe so the opening faces the front of the boiler. Thread a 4' length of 11/4" pipe into the elbow and carefully lift the front of the boiler. Slide a 3"...

  • Page 5: Dimensions & Component Location

    13 1/4" 13 1/2" 27 5/8" SIDE VIEW Notes: 1. Components located behind front panel 2. Vertical dimensions must be adjusted when using a base pan or concrete foundation under the boiler TABLE 1 Boiler Dimensions Boiler Size Dimension (# Sections) ⁄...

  • Page 6: Combustion Air

    SPECIAL BASE the proper venting of the remaining appliances connected to it. At the time of removal of an existing boiler, the following steps shall be followed with each appliance remaining connected to the common venting system placed in operation, one at a time, while the other appliances remaining connected to the common venting system are not in operation.

  • Page 7: Chimney Venting

    • the boiler must not be connected to a flue used for a fireplace, wood stove or other solid fuel device. If possible the boiler and a gas fired hot water heater should be connected to the same chimney flue.

  • Page 8: Vertical Venting

    INSTALLATION & OPERATING INSTRUCTIONS Vent Connections to Chimneys Use Type B1 or single wall metal vent pipe from the boiler to the chimney. If used, a 4 in to 5 in, 102 mm to 127 mm increaser must be fastened directly to the boiler vent collar with sheet metal screws no longer than 1/2 in, 13 mm .

  • Page 9: Horizontal Venting

    For best results, horizontal vent systems should be as short and straight as possible. The 4" adapter must be attached directly to the boiler outlet. A vertical vent run at least 18 inches high must be installed before any horizontal run begins. If the boiler is installed using a 3"...
  • Page 10 Pump Away Bypass For systems that use a single circulator to pump away from the boiler, the bypass should be installed on the discharge side of the circulator, see FIG. NO. 7. Full temperature water supplies the baseboard distribution system as before. Half of the circulator’s volume moves through the bypass, blending and...
  • Page 11 Appropriate valves must be used to prevent the 100% chilled water from entering the boiler. See FIG. NO. 10 for the 120° F proper piping layout.

  • Page 12: Gas Supply Piping

    Do not connect the boiler to the gas supply or a fire or an explosion may occur! If for any reason the boiler is not for the type of gas available at the installation site, call the nearest Smith Cast Iron Boiler distributor to resolve the problem.

  • Page 13: Electrical Wiring

    CSA C22.1 Canadian Electrical Code Part I if installed in Canada. Install a separate 120 volt 15 amp circuit for the boiler. A shut-off switch should be located at the boiler. The boilermust be grounded in accordance with the authority having jurisdiction, or if none, the latest edition of the National Electrical Code, ANSI/NFPA-70.
  • Page 14 Page 14 FIG. NO. 13 Fenwal/Honeywell Hot Surface Ignition...
  • Page 15 R8285A POWERS (3) V8043 ZONE VALVES, OR ONLY (2) V8043'S IF AMBIENT TEMPERATURE EXCEEDS 77F. USE AND ADDITIONAL TRANSFORMER FOR EVERY ADDITIONAL 3 OR LESS VALVES. FIG. NO. 17 Multi-Zone Diagram R8285D POWER SUPPLY GV100W BOILER GV100W BOILER FIG. NO. 16 Multi-Zone Diagram T87F ZONE 3 V8043F END SWITCH TH-TR...

  • Page 16: For Your Safety Read Before Operating

    2. Turn off all electric power to the appliance if service is to be performed. 3. Remove control access panel. GV100W BOILER • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. If you cannot reach your gas supplier, call the fire department.

  • Page 17: Pour Votre Sécurité Lisez Avant De Mettre En Marche

    1. Mette le thermostat à la température la plus basse. 2. Si un entretien doit être effectué, coupez l'alimentation électrique de l'appareil. 3. Lever le panneau de parte du réchauffer. GV100W BOILER • Appelez immédiatement votre fournisseur de gaz depuis un voisin. Suives les instructions du fournisseur.

  • Page 18: Boiler Set-Up

    Open the valves in the return and supply piping. Failure to take these precautions will prevent the boiler from operation properly. Fill the boiler and all of the radiation with water. Make sure that the system is completely purged of air.

  • Page 19: Checking & Adjustment

    If the boiler is equipped with a low water cutoff device make sure that the main burners will NOT light when the boiler has no water in it. To check, turn the boiler off, close the valves in the water supply and return lines and drain the boiler. If the boiler’s main burners light shut the boiler off immediately and...

  • Page 20: Boiler Maintenance

    Reconnect the inducer wires and the vent system. 10. Follow the Burner Installation procedure above. 11. Once the sealant has cured, fire the boiler to make sure that it operates properly. Vent System At least once a year the entire vent system must be thoroughly inspected for any signs of blockage, corrosion or leaks.

  • Page 21: Instructions To The Installer

    The aquastat high limit controls the maximum water temperature in the boiler. It is adjustable from 140°F, 60°C , to 220°F, 104°C . If the water temperature reaches the set temperature before the demand for heat has been met, the aquastat high limit should shut the burners off.
  • Page 22 Page 22 INSTALLATION & OPERATING INSTRUCTIONS Ref # Name of Part Top, Rear, Inner Front and Front Panels Left Side Panel Right Side Panel Noncombustilbe Floor Pan GV100W BOILER GV100 SERIES REPAIR PARTS Part No. 55763 55764 55765 55766 55767...
  • Page 23 Pressure Relief Valve (30 psi) Temp & Pressure Gauge HSI - FENWALL IGNITION SYSTEM Ignition Module (35-655922-001) Ignitor Gas Valve (36E01-308) NG Gas Valve (VR8305M-3506) LP — Inducer Relay (In Junction Box) GV100W BOILER Part No. 55513 55514 55515 55516 55517 55512 69879...
  • Page 24 Carbon monoxide (CO) is a gas which is odorless, colorless and tasteless but is very toxic. If your Smith boiler is not working properly, or is not vented properly, dangerous levels of CO may accumulate. CO is lighter than air and thus may travel throughout the building. Brief exposure to high concentrations of CO, or prolonged exposure to lesser amounts of CO, may result in carbon monoxide poisoning.
