READ THESE INSTRUCTIONS CAREFULLY. THEY WILL
PRESSURIZED FOR FIRING OIL, GAS
DESIGNED AND TESTED ACCORDING TO THE A.S.M.E.
BOILER AND PRESSURE VESSEL CODE, SECTION IV
FOR MAXIMUM ALLOWABLE WORKING PRESSURE.
Do not use automotive anti-freeze in boiler waterways. If necessary to use anti-
freeze, be sure to employ a preparation designed for hydronic heating systems
such as ethylene or propylene glycol.
Water treatment is not recommended. This boiler uses gaskets to seal the ports
of adjoining sections. These gaskets are made of a fluorocarbon elastomer
(designation FKM) marketed under the brand name Viton. Consult a water
treatment professional before adding any chemical to the boiler water. Any
water treatment or anti-freeze added to the system must be compatible with the
Viton gaskets.
THE SECTIONS OF THIS BOILER MUST BE ASSEMBLED
TO THE PROPER TORQUE. READ INSTRUCTIONS
THESE INSTRUCTIONS TO BE LEFT WITH THE BOILER FOR REFERENCE PURPOSES
INSTALLER
SAVE TIME IN ASSEMBLING BOILER
19A SERIES BOILER
INSTALLATION
INSTRUCTIONS
STEAM OR WATER HEATING
OR COMBINATION GAS/OIL
STEAM - 15 PSIG, WATER - 80 PSIG
CANADA: STEAM - 15 PSIG, WATER - 50 PSIG
CAUTION
WESTCAST, INC.
260 NORTH ELM STREET WESTFIELD, MA 01085
TEL. (413) 562-9631 FAX (413) 562-3799
19IOM-5

Advertisement

Table of Contents
loading

Related Manuals for Smith Cast Iron Boilers 19A SERIES

Summary of Contents for Smith Cast Iron Boilers 19A SERIES

  • Page 1 STEAM - 15 PSIG, WATER - 80 PSIG CANADA: STEAM - 15 PSIG, WATER - 50 PSIG Do not use automotive anti-freeze in boiler waterways. If necessary to use anti- freeze, be sure to employ a preparation designed for hydronic heating systems such as ethylene or propylene glycol.

  • Page 2: Installation Instructions

    60333 Heater Cover Plate Gasket 3611 Cleanout Cover Plate 3565 Burner Mounting Plate, Carlin - 6 3566 Burner Mounting Plate, Powerflame - 7 19A SERIES BOILER INSTALLATION INSTRUCTIONS Item Comp. Description — " Opening " Opening Description 3640 Burner Mounting Plate, Powerflame - 9 "...

  • Page 3: Table Of Contents

    STEAM PIPING WATER PIPING GENERAL 19A Series boilers are wet-base, extended surface, vertical flue design with integral cast flue gas collector for pressurized firing with oil, gas or combination power burners. Upper and lower port hydronic seals are of a special material resistant to...

  • Page 4: Combustion And Ventilation Air

    2" legs on the floor and measuring 25-21/32 inches outside dimension. Be sure to align the center of the boiler with the center line of the pad. If no pad is provided, shim and grout under the angles to make them level and provide support along the full length.

  • Page 5: Hydrostatic Test

    SEALING SECTIONS FIGURE 3 HYDROSTATIC TEST Plug tappings, fill boiler with water and vent air from top of boiler. Check for leaks. Leakage at seals may be due to misalignment of hydronic seals. Loosen draw rods, reposition seals and retest as above.

  • Page 6: Water Piping

    6 gives pumping rate and supply & return sizing for standard installations. TABLE 6 BOILER SIZE RETURN CONN. Based on 20 F system temperature drop. NOTE Boiler supplied with 4" water supply tapping and 3" return tapping. 19A SERIES BOILER INSTALLATION INSTRUCTIONS SYSTEM SUPPLY CONNECTIONS CONDENSATE MIN.
  • Page 7 11-13 & FIGURE 8.) 19A SERIES BOILER The sealing rope should be placed in the groove on the boiler side of the plate using adhesive to hold it in place. The WATER insulation block has a burner opening and a cutout for the SUPPLY observation opening.
  • Page 8 13. CLEANOUT COVERS Be sure the rope seals are in place around the groove in the cleanout cover plate. Install the plates on the boiler sections carefully to insure proper sealing all around, using the 5/16" x 2" special anchor bolt and 5/16" hex head nuts. After periodic flue cleaning, replace nuts at 10 lbs.

  • Page 9: Smokehood

    A.S.M.E. Section VI. 4. Fire the boiler for at least one hour at a low rate to circulated the cleaning compound through the boiler. 5. Blow off surface of boiler water through skimmer connection or through safety valve opening by feeding clean water into the boiler through a bottom fill connection.

  • Page 10: Control Locations

    “D” - 3/4" TAP, OPER. TEMP. CONN. THERALTIMER 3/4" TAP STD.MAN. RESET HIGH LIMIT 3/4" TAP OPT. CLEANOUTS OPTIONAL INSPECTION TAPPINGS 3" RETURN TAP FRONT VIEW 19A SERIES BOILER INSTALLATION INSTRUCTIONS 3" “A” JACKET 4" TAP NORMAL STEAM WATER LINE 1" TAP “C” “D” “C”...
  • Page 11 Carbon Monoxide (CO) is a gas which is odorless, colorless and tasteless but is very toxic. If your Smith boiler is not working properly, or is not vented properly, dangerous levels of CO may accumu- late. CO is lighter than air and thus may travel throughout the building. BRIEF EXPOSURE TO HIGH CONCENTRATIONS OF CO, OR PROLONGED EXPOSURE TO LESSER AMOUNTS OF CO MAY RE- SULT IN CARBON MONOXIDE POISONING.
  • Page 12 WESTCAST, INC. 260 NORTH ELM STREET WESTFIELD, MA 01085 TEL. (413) 562-9631 FAX (413) 562-3799...
