- Page 1 OPT SCR200 Installation Manual Version No: 1.0.3 Model: OPT Mark 2 SCR200 Date: 7 December 2018...
- Page 2 Identification section. care. ▪ Only parts supplied by or approved by Compac may ▪ Compac Industries Limited accepts no liability for be used and no unauthorised modifications to the direct, indirect, incidental, special, or hardware of software may be made.
- Page 3 Compac for archived manuals if required. Validity Compac Industries Limited reserves the right to revise or change product specifications at any time. This publication describes the state of the product at the time of publication and may not reflect the product at all times in the past or in the future.
- Page 4 Document Control Document Information Manual Title OPT SCR200 Installation Manual Current Revision Author(s) R Liu Original Publication Date 06/03/2018 Authorised By W Zheng File Name OPT SCR200 Installation Manual Revision History Version Date Author(s) Revision Notes 1.0.0 06 Mar 2018...
-
Page 5: Table Of Contents
Contents Footprints ......................1 Components ......................2 Tools Checklist ..................... 3 Precautions ......................4 Mechanical Installation ..................5 Mounting the OPT on a Post ................. 6 Electrical Installation ................... 7 Cable Requirements ....................7 Electrical Testing ....................9 Tank Gauging Setup .................... 11 System and Transaction Tests ................ -
Page 6: Footprints
Footprints Base Footprint External Dimensions... -
Page 7: Components
Components Suction Vent Optional IP Phone Speaker Payment Express SKP200 PIN pad Payment Express Privacy Shield SCR200 Secure Card Reader Optional IP Phone Mic and Button Custom VKP8III Receipt Printer Camlock Vent Optional 3G Router Optional 4G Router Net Switch MX Box UPS Board Dot Matrix Display... -
Page 8: Tools Checklist
Tools Checklist Having all the correct tools will make installation, upgrade and repair procedures easy and minimise the risk of damage to components. Before you arrive on site, make sure you have a minimum of all the tools listed here: NOTE: Make sure your cell phone and laptop are fully charged. -
Page 9: Precautions
1.5 metres from any LPG dispensers. ▪ The OPT should be mounted so that the base of the cabinet is at least 1.2 metres above the ground. If mounted on the post supplied by Compac it will be 1.2 metres high. -
Page 10: Mechanical Installation
Mechanical Installation Prior to Installation Read the relevant parts of this manual and make sure you have the following information: ▪ All necessary approvals to work on the site ▪ The OPT factory set up sheet ▪ The site audit document ▪... -
Page 11: Mounting The Opt On A Post
M6 machine screws for the extra security models. NOTE: Use only the Compac supplied 4 bolt mounting plate to secure the OPT to the post. NOTE: Security Torx or Security Keyed head screws must be used on the cover plate of the post to prevent unauthorised access to the wiring. -
Page 12: Electrical Installation
Electrical Installation Cable Requirements Power Cable 3 Core Steel Wire Armour Cable 2.5mm². 230 Volts, 10A, 50 Hz. Connect the incoming mains as follows: ▪ Live - Connect to the Left bottom screw down terminal of the mains switch. ▪ Neutral - Connect to the Right bottom screw down terminal of the mains switch. ▪... - Page 13 Phone Line/Network For ADSL connected units the phone cable should be run through ducting that provides suitable protection and flexibility. There is a phone line surge protector mounted on the DIN rail. 4G Aerial/Antennae Installation For wireless connected units where the aerial is mounted remotely from the cabinet, the aerial cable should be run through ducting that provides suitable protection and flexibility.
-
Page 14: Electrical Testing
▪ Check the Router or ADSL modem is turned on and the power LED is lit. ▪ Check the green power led on the right side of the Compac Box is on. If not, check the switch on the left-hand side of the box is turned on. - Page 15 UPS Board LEDs Diagnostic LEDs FMS Board LEDs...
-
Page 16: Tank Gauging Setup
Veeder Root 9600 8 Bit The Compac settings for each model of tank gauge are usually either set at the factory or sent via CompacOnline. System and Transaction Tests When you are happy that the OPT is powered up and communicating, contact the Help Desk. -
Page 17: Installation Checklist
Installation Checklist Before leaving site, ensure the installation checklist is completed. If any of the following tests fail, please contact Helpdesk. Mechanical Check that the unit has been securely bolted down. Check all panels are securely fastened. Check that all cable entries to OPT are through glands. Wiring Check that power has been connected to the main breaker in the OPT. - Page 18 Transaction Tests Check that all pumps can be selected when starting a transaction on the PIN pad. Check that the correct $, L and fuel grade are printed on the receipt and that a receipt is issued after each transaction when the card is re-swiped. Check that the transactions that appear on CompacOnline match up to the receipt information that is printed on site.
