- Page 2 General Care and Safety Guide Thank you for choosing a Goldair Ecopanel Heater. This Goldair appliance has been designed and manufactured to high standards of engineering and with proper use and care, as described in this booklet, will give you years of useful service. Please read these instructions carefully and keep for future reference.
- Page 3 Do not run the power cord behind the heater. This will determine where you mount the heater in relation to where the power socket is located. NOTE: Your Goldair EcoPanel Heater should be installed with at least 300mm clearance...
- Page 4 THIS WAY UP NOTE: Your Goldair EcoPanel Heater should be installed with at least 300mm clearance from the floor and any other surrounding parts including other appliances, side walls, ceilings, shelves and soft furnishings. Mark the positions of the four holes to be Install the panel heater onto the four rail fittings drilled on the wall.
-
Page 5: Operating Your Appliance
WARNING: In order to avoid overheating or risk of fire, do not cover the heater. WARNING: Never leave this appliance unattended when in use. Your Goldair Panel Heater will provide background warmth. This Panel Heater is designed to take the chill off the room. -
Page 6: Temperature Setting
Operating your Appliance continued Press the ON/OFF button on the display panel once and the "ON" indicator will display on the LCD screen. The heater is in the power-on state. If the ambient temperature is below 25℃, the heater will heat. If the ambient temperature is above 25℃, you will need to set the temperature to a higher temperature before the heater will start to heat. - Page 7 Download Goldair Heater mobile APP • Open the APP Store or Google Play on your mobile phone. • Open “Search” and enter “Goldair Heater" • Click “GET” and begin to download and install. Once downloaded to your phone open the APP Tap REGISTER near the bottom of the screen.
- Page 8 WiFi – Downloading and Setting up APP • Enter the verification code from your text message • Create a password. • Then tap confirm. If you haven’t received a verification code via text message. Tap the resend button and when the verification code is received follow above steps.
- Page 9 Pairing APP to Heater On your phone tap “ADD DEVICE” to connect to the heater. Press the “SET” button on the control panel of the heater for 5 seconds until the WIFI indicator on the LCD screen starts flashing quickly. Flashing Tap ‘Next Step”...
- Page 10 Pairing APP to Heater Choose/confirm which WiFi to connect to. Note: your phone may pick up other WiFi signals (e.g. neighbours) so you will need to choose. XXXXXX Enter your WiFi password The phone will then connect to the heater. Ensure you have a good strong signal from your WiFi router.
- Page 11 Tap “Confirm” to complete the addition. DEVICE SHARING CANCELLATION Open the “GOLDAIR APP” and tap the 3 dots in the top right of the screen. Tap “Add Sharing” and delete the phone numbers of shared members to cancel the device sharing.
- Page 12 Open the “GOLDAIR" APP to select the heater (when using one mobile phone to control multiple heaters, you need to select the heater to be operated).
-
Page 13: Child Lock
Operating your Heater from the APP AUTO ON TIMER When the heater is OFF you can set it to turn ON after a number of hours (1-24 hours) has elapsed. • In the APP, tap the heater to be operated and enter the operation interface. - Page 14 Adding Additional Heaters From the “Devices” page of the APP press “Add Device” and follow the steps below to pair the new heater. Choose/confirm which WiFi to connect to. Note: your phone may pick up other WiFi signals (eg. neighbours) so you will need to choose. XXXXXX Enter your WiFi password...
- Page 15 Adding Additional Heaters The phone will then connect to the heater. Ensure you have a good strong signal from your WiFi router. Note: The WiFi indicator on the heater screen may disappear during this pairing process. Once complete the screen showing the device has been successfully added will appear.
-
Page 16: Other Information
Operating your Heater from the APP OTHER INFORMATION Open the “GOLDAIR APP” and tap the 3 dots in the top right of the screen. Device Info This shows the heater WiFi ID and the IP address. Feedback This gives you the ability to give feedback on the APP that may be useful... -
Page 17: Troubleshooting
Troubleshooting Please refer to the Goldair website http://www.goldair.co.nz/product-catalogue/heating/eco-panel-heaters/electronic-wi- fi-control-eco-panel-heater-geph205 Or call free phone 0800 232 633 (NZ Only) -
Page 18: Care And Cleaning
Model No: GEPH215 Supply: 240VAC 50Hz Wattage: 425W SUPPORT AND TECHNICAL ADVICE Goldair – New Zealand Goldair – Australia Monday – Friday 8am-5pm Monday – Friday 8am-5pm Phone +64 (0)9 917 4000 Phone +61 (0)3 9365 5100 Phone 0800 232 633 Phone 1300 465 324 info@cdb.co.nz... -
Page 19: Three Year Warranty
In non-domestic use Goldair limits the voluntary warranty to three months. Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during the warranty period.
