Summary of Contents for Curtec Click Pack
- Page 1 Manual Click Pack March 2019...
- Page 2 Washing The washing instructions below apply to the cleaning of all CurTec packaging products that are made of polyethylene and polypropylene: Best results will be achieved with a washing installation that is equipped with spray nozzles or a so-called Ultra-Sonic installation.
- Page 3 3. Turn the lid firmly 90 degrees clockwise until it reaches the end of the screw thread. Turn the lid in one move and at the same time press it down lightly. The lid will click when it passes the locking button. The container is now closed. Click Pack manual 1607...
- Page 4 6. The container is now sealed. For Click Packs with product code 44XX you can also use a sealing strip. CurTec advises to use Unisto Compact Seals but you can of course use any other strip you prefer. Just make sure that they have a tail with a minimum length of 225 mm and a maximum diameter of 2 mm.
- Page 5 8. The container is now sealed. Contrary to sealing with a pin, which is only possible on a handgrip with a loop, you can use a sealing strip on all four handgrips. Click Pack manual 1607...
- Page 6 2. The container can be opened. To remove the lid hold it firmly with both hands opposite each other and press the button with one finger. 3. Turn the lid firmly 90° in an counter-clockwise direction with both hands while applying a downward pressure. Click Pack manual 1607...
- Page 7 30°C before the container can be closed. The drum can be closed according to instruction 1. Lifting A Click Pack can be easily lifted and moved both mechanically and manually. Use the handgrips on the container or the (optional) handle.
- Page 8 Since CurTec has no influence on the use of its packaging by end users, they advise to test each transport mode. It remains the responsibility of end users to verify whether a package and content comply with relevant transport regulations.
- Page 9 Attention! The weights mentioned in the table have been established after simulation and can only serve as indications. CurTec recommends users to perform tests at all times. The table allows you to calculate the number of containers that can be stacked: Reduce the stacking weight mentioned with the relevant share of the weight of intermediate layers and devide by the weight of the container with content.
- Page 10 When a stack is higher than 2.5 metres, the floor angle cannot exceed 0.5%. When changing transport mode, from storage to shipping or vice versa, the lowest containers of a stack must always be placed highest in a new stack. Click Pack manual 1607...
- Page 11 B Rail transport C Road transport D Air transport Attention! The weights mentioned in the table have been established after simulation and can only serve as indications. CurTec recommends users to perform tests at all times. Click Pack manual 1607...
- Page 12 The containers must be stowed professionally and fixed in such a way that makes moving impossible. For the use of pallets, see instruction 6 (Palletisation). For stacking containers in a warehouse, see instruction 4 (Static load). Click Pack manual 1607...
- Page 13 A pallet should have an almost closed surface fitted with planks that are no more than 5 cm/ 2 inches apart. CurTec advises not to exceed a total stacking height of 2 metres. In case a pallet is placed on top of another pallet, an intermediate layer is required to enable an equal spread of the pressure.
- Page 14 Pallet schemes CurTec advises you to respect the following quantities per layer: Art. no. 4406 1200 x 800 mm 1200 x 1000 mm 48 x 40 inches Art. no. 4410 ▪ 4415 ▪ 4420 1200 x 800 mm 1200 x 1000 mm...
- Page 15 Art. no. 4515 ▪ 4520 ▪ 4525 1200 x 800 mm 1200 x 1000 mm 48 x 40 mm Click Pack manual 2018-6...
- Page 16 CurTec manufactures packaging material for a wide range of purposes. This declaration is restricted to the packaging material as it leaves the production facility. CurTec has neither control over final end use of the product nor over processing conditions. It is...
