POOL SETUP (continued)
You may have purchased this pool with the Intex Krystal Clear™ fi lter pump. The pump has its
own separate set of installation instructions. First assemble your pool unit and then set up the fi lter
pump.
Estimated assembly time 10~30 minutes. (Note the assembly time is only approximate and
individual assembly experience may vary.)
1. Liner preparation
• Find a fl at, level location that is free and clear of stones, branches or other sharp objects that may
puncture the pool liner or cause injury.
• Open the carton containing the liner, etc., very carefully as this carton can be used to store the pool during
the winter months or when not in use.
• Take out the ground cloth (3) and spread it over the cleared area.
Then take out the liner (1) and spread it out over the ground cloth,
with the drain valve directed towards the draining area. Place the
drain valve away from the house.
IMPORTANT: Always set up the pool unit with at least 2
persons. Do not drag the liner across the ground as this can
cause liner damage and pool leakage (see drawing 2).
• During the setup of the pool liner, point the hose connections or
openings in the direction of the electrical power source. The
outer edge of the pool should be within reach of the pump's
electrical connection.
• Lay out the pool. Spread out the plain blue sides and make the
pool fl oor as smooth as possible (see drawing 2).
2. Ring infl ation
• Flip the top ring out and check that it is fully outside of the wall
lining and facing up. Infl ate the ring with a manual air pump (see
drawing 3). Keep the top ring centered in the middle of the pool,
while doing this.
IMPORTANT: Prevent bursting by not using a high-pressure
pump, such as an air compressor. Do not over infl ate.
Preferably use an Intex manual infl ation hand pump
(not included).
Proper infl ation of the top ring.
The ambient temperatures of air and water have an effect on the internal pressure of the top ring. To
maintain a correct internal pressure, it is best to leave some room for expansion as the sun heats the
air inside the ring. During very hot weather, you must check to see whether it is necessary to release
some air. This is to avoid any possible damage to the ring.
In no event shall Intex, their authorized agents or employees be liable for damages (such as pin
holes) to the infl atable top ring caused by negligence, ordinary wear and tear, abuse and
carelessness, or external forces.
3. Hose connectors
• The following applies to pool liners with hose connectors (16" (488 cm) & below pools). If the pool was
purchased without a fi lter pump, insert two black plugs (2) into the black fi lter pump outlets. Do this
from the inside of the pool so that water will not run out when fi lling it.
• If the pool was purchased with a fi lter pump, read the Krystal Clear™ Filter Pump Manual fi rst and then
proceed to next installation step.
S AVE THESE INSTRUCTIONS
