Burster Digiforce 9307 Series Manual

Universal Process-Controller

For monitoring press-fit and joining operations,
torque and process curves, plus spring and switch
testing, including resistance measurement,
signal testing and leak detection
DIGIFORCE
®
Series 9307
±10 V
Poti
Piezo
EnDat
INCR
Ω
SSI

Application

The DIGIFORCE 9307 monitors processes in which precisely
®
defined functional relationships between two or more mea-
sured quantities need to be demonstrated. These measured
quantities are recorded synchronously during the manufac-
turing process or subsequent functional testing to produce a
measurement curve, which is then assessed using graphical
and mathematical evaluation techniques. After internal evalua-
tion, the measurement curve and computed evaluation results
are visualized on the color display and are also output at the
external control interfaces. The processes in the controller are
optimized by a powerful real-time operating system to achieve
an extremely fast evaluation cycle: it typically takes just 15 ms
to deliver the global OK or NOK evaluation result, which can
then be analyzed by the higher-level controller.
In addition to the traditional evaluation windows with defined
entry and exit sides, the DIGIFORCE
olds, trapeziums of type X or Y and envelopes as graphical
evaluation elements. Individual evaluation results from the
graphical tools can then be combined by mathematical opera-
tions to provide even more analysis flexibility for a huge range
of signal curves.
DIGIFORCE has a wide range of process control applications,
®
including monitoring processes such as joining, riveting or
caulking, or checking torque curves, for instance for hinges or
high-quality rotary controls. Even complex signal/time curves
(e.g. pressure curves, leaks etc.) can be monitored using the
large choice of evaluation techniques.
Simultaneous recording of up to two Y variables (Y
respect to a common X variable allows many applications to
Technical changes reserved. All data sheets at www.burster.com
9307 also offers thresh-
®
and Y ) with
1 2
Code:
Delivery:
Warranty:
Comprehensive process monitoring delivered by
n
innovative evaluation elements window, thresholds,
trapeziums, envelopes and mathematical operations
High measurement accuracy 0.05 % possible at
n
10 KHz sampling rate
Flexible Process Integration thanks to a range of
n
Fieldbus Interfaces
Simultaneous monitoring of two synchronous
n
processes
Ultra-fast evaluation and data transfer for dynamic
n
measurements
Ethernet, USB, RS232 as standard
n
Up to 128 measurement programs for a large variety
n
of parts
Transfer of process, component and worker data
n
Intelligent signal sampling using a combination of
n
∆t, ∆X, ∆Y
Automatic sensor recognition from burster TEDS
n
DigiControl PC software with powerful data-logging
n
function for process data
use one DIGIFORCE ® controller to monitor two synchronous
processes.
Alternatively, this feature can be used to evaluate an appli-
cation with three process variables, for instance the force/
displacement curve and associated current consumption of
a lifting electromagnet. While DIGIFORCE
automated production areas, it is equally at home in the
manual workstation, for instance to monitor force/displace-
ment when using hand presses for assembly or for random
spot-checking in goods inwards.
burster praezisionsmesstechnik gmbh & co kg Germany
Talstr. 1-5 Gernsbach 76593 Phone +49-7224-6450
. .
9307 EN
ex stock/2 weeks
24 months
is used in many
®
