Page 1: Mobile Printer
PORTI-PC40 MODEL (Mobile Printer) WOOSIM SYSTEMS Inc. #501, Daerung Technotown 3th, 448, Gasan-Dong, GeumChun-Ku, Seoul, Korea Tel : +82-2-2107-3700 Fax : +82-2-2107-3707 URL: http://www.woosim.com All specifications are subjected to change without notice... - Page 2 Porti-PC40 Mobile printer operator’s manual. Copyright 2007 by Woosim Systems Inc. All rights reserved. The information contained in this manual is the property of Woosim System Inc. and may not be reproduced in whole or in part without the prior written permission of Woosim System Inc.
- Page 3 Introduction The Porti-PC40 is the ideal solution for Mobile banking system , Retail, point of sales, Credit card Transaction, other traveling and mobile computing etc. The general features of Porti-PC40 printer are as follows: Pocket size(105 x 80.4 x 45.7mm) Light weight(286g) for true mobility.
- Page 4 Please follow the precautions below to enjoy and maintain the full performance of the printer. Using the Printer Be careful not to drop or bump the printer on a hard surface. Do not install the printer in direct sunlight or such areas. Suitable environment for the use of the printer is as follows : Operating temperature : -10°C to 40°C Relative humidity : 10% to 90% (no condensation)
- Page 5 CONTENTS 1. Outline .............................6 1.1. Model classifications ......................6 1.2. Product Part Number System....................6 1.3. Specifications........................7 2. Setting up the printer ........................8 2.1. Printer & Accessories......................8 2.2. Printer Features........................9 2.3. Dimensions .........................10 2.4. Replacing the paper roll......................11 2.5. Power supply ........................12 3.
- Page 6 PORTI–PC40 Model name Interface None: RS-232C or TTL Power None : DC 12~24V Model name Interface Spec. Wired Wireless RS-232C Bluetooth SC30 IrDA HPIR RS-482 None Parallel None Example) 1. Porti-S40 Serial/Bluetooth Part No. S40/A1 2. Porti-SC30 Bluetooth Only Part No. SC30/Z1...
-
Page 7: Dimensions
Item Description Direct thermal line printing Printing method 42cpl Characters per line Eng. : 9*24dots, 12*24dots Kor. : 16*24dots, [24*24dots] Character size 203dpi, 8dots/mm Resolution 2-inch (48mm, 384dots) Print width 50mm / sec Printing speed 105 x 80.4 x 45.7 mm Dimensions 286g Weight... - Page 8 When unpacking your printer box make sure it contains the printer and all accessories. If any accessories are missing or damage, please contact your dealer for assistance. Roll Paper PORTI-PC40...
- Page 11 Note : Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer cannot detect the paper end correctly. 1. Make sure that the printer is not receiving data; otherwise, data may be lost. 2.
-
Page 12: Power Supply
The following specifications are requested for Power supply. Input : DC 12-24V / Max 3A Avoid using power supply which its power capacity of power current is extremely high... -
Page 13: Interface
The Porti-PC40 printer has an RS-232C interface is connected by means of a 9p D-sub. In the following table, the signals present on the connector are listed: Pin No. Name Direction Function Output Transmit Data Input Receive Data Ground INPUT 12V~24V/3A <D-Sub 9p Female >... - Page 14 RS-232C Technical Specifications : 9600 Baud DATA TRANSFER RATE : 8 Data Bits WORD LENGTH 1 Stop Bit SIGNAL LEVELS : Mark or Logical 1 = -3 to -15 VDC Space or Logical 0 = +3 to +15VDC : XON / XOFF HANDSHAKING...
-
Page 15: The Self Test
Button - FEED Button : When the printer is on, paper can be feed manually by pressing and holding the FEED button for more than one second. Panel Lamp Printer is ON and ready to receive data. - POWER : Indicates a fault condition or a printer error. - Page 16 Type : Thermal Paper Paper width : 57mm Paper thickness : 60±5 Outer diameter : Ø40mm or less Recording side : Outside of roll Cautions 1. Do not paste the paper to the core. And the roll paper which has Near end mark printing on its near end is recommended.
