Woosim Systems Inc. PORTI-P340 Operator's Manual

3inch panel printer rev 4.0
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PORTI-P340
MODEL
(3inch Panel Printer)
Rev 4.0
All specifications are subjected to change without notice
http://www.woosim.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PORTI-P340 and is the answer not in the manual?

Questions and answers

Related Manuals for Woosim Systems Inc. PORTI-P340

Summary of Contents for Woosim Systems Inc. PORTI-P340

  • Page 1 PORTI-P340 MODEL (3inch Panel Printer) Rev 4.0 All specifications are subjected to change without notice http://www.woosim.com...
  • Page 2 P340 Rev. 4.0  Copyright PORTI-P340 3inch Panel Printer Operator’s Manual. Copyright ⓒ2017 by Woosim Systems Inc. All rights reserved. The information contained in this manual is the property of Woosim Systems Inc. And may not be reproduced in whole or in part without the prior written permission of Woosim System Inc.
  • Page 3 P340 Rev. 4.0  Introduction The PORTI-P340 is an extremely simple and functional panel printer. It is the ideal solution for applications which require the immediate printing of data on a paper, whether they be of an industrial, professional or laboratory nature.
  • Page 4 P340 Rev. 4.0  Operating Precautions Please follow the precautions below to enjoy and maintain the full performance of the printer. Using the Printer  ● Be careful not to drop or bump the printer on a hard surface. ● Do not install the printer in direct sunlight or such areas.
  • Page 5 P340 Rev. 4.0  Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 6: Table Of Contents

    P340 Rev. 4.0 CONTENTS 1. Outline ................................. 7 1.1. Model classifications ............................. 7 1.2. Product Part Number System........................7 1.3. Specifications ..............................8 2. Setting up the printer ............................9 2.1. Printer & Accessories ............................ 9 2.2. Printer Features .............................10 2.2.1.

  • Page 7: Outline

    P340 Rev. 4.0 1.1. Model classifications PORTI–P340 Model name Interface None : UART Power None : DC 7.5V~8.5V 1.2. Product Part Number System Model name Interface Spec. Wired Wireless RS-232C Bluetooth SC30 IrDA None RS-485 Parallel None Example) 1. Porti-S40 Serial/Bluetooth Part No.

  • Page 8: Specifications

    P340 Rev. 4.0 1.3. Specifications Item Specification Printing method Direct thermal line printing - Font A, B, C : 48 / 64 / 72cpl Characters per line - KOR, CHN, JPN : 24cpl - Font Size A: 12X24 / Font Size B : 9X24 / Font Size C : 8X16 Character size - KOR : 24X24(16X24) / CHN, JPN : 24X24...

  • Page 9: Setting Up The Printer

    P340 Rev. 4.0 2.1. Printer & Accessories When unpacking your printer box make sure it contains the printer and all accessories. If any accessories are missing or damage, please contact your dealer for assistance. Thermal roll paper Porti-P340 http://www.woosim.com 2018-07-11...

  • Page 10: Printer Features

    P340 Rev. 4.0 2.2. Printer Features [unit : mm] http://www.woosim.com 2018-07-11...

  • Page 11: Panel Installation

    P340 Rev. 4.0 2.3. Panel Installation Uses the bracket(option) and the printer once more will be able to fix to the panel. http://www.woosim.com 2018-07-11...

  • Page 12: Replacing The Paper Roll

    P340 Rev. 4.0 2.4. Replacing the paper roll Note : Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer can not detect the paper end correctly. 1.

  • Page 13: Setting Operation Mode

    P340 Rev. 4.0 2.5. Setting operation mode Change the mode and option using the MODE Code.  MODE button : use for changing OPTION status. (Error Lamp)  FEED button : use for changing MODE status. (Power Lamp) [Example] The defaults of the printer are : UART / 9600 bps / 8 data bit / No parity / 1 stop bit / Density low If a user wants to modify the defaults with Protocol UART / 57600 bps / 7 data bit / Odd parity / 2 stop bit / Density high...

  • Page 14: Power Supply

    P340 Rev. 4.0 If all the mode have set, press the MODE Button and the FEED Button at the same time after then release the buttons at the same time. The printer will print out the mode status which has modified. (Protocol UART / 57600 bps / 7 data bit / Odd parity / 2 stop bit / Density high) If the status is not correct, please try it again according to the procedure.

  • Page 15: Interface

    P340 Rev. 4.0 3.1. UART(RS-232C or TTL) The Porti-P340 printer has a UART(RS-232C or TTL) interface and power connector is connected by 6 pin female connector. In the following table, the signals present on the connector are listed: Pin no.

  • Page 16: Using The Printer

    P340 Rev. 4.0 4.1. Control panel  Button - FEED : When the printer is on, paper can be feed manually by pressing and holding the FEED button for more than one second. - MODE : MODE Button is for use to change communication mode. Do not operate the mode button without instructions.

  • Page 17: Consumable Parts

    P340 Rev. 4.0 5.1. Recommended paper Type : Thermal Paper Paper width : 80mm Paper thickness : 60±5㎛ Outer diameter : Ø38mm or less Recording side : Outside of roll Cautions . Do not paste the paper to the core. And the roll paper which has near end mark printing on its near end is recommended.

  • Page 18: Revision History

    P340 Rev. 4.0 Date Version Comments RX Version renewal Jun. 08. 2017 *Change page layout (B5→A4) * Delete address http://www.woosim.com 2018-07-11...
