Wavecom Q26 Elite Wireless CPU Product Manual page 16

Pin
Signal Name
#
27 GPIO37
28 GPIO38
29 GPIO39
30 RXD2
31 TXD2
32 CTS2
33 RTS2
34 MIC2N
35 HPH_OUT_L_P
36 MIC2P
37 HPH_OUT_R_N
38 LINE_IN_R_N
39 SPKR_OUT_P
40 LINE_IN_L_P
41 SPKR_OUT_N
42 EBI2_LB_N
43 GPIO40
44 SCL
45 GPIO41
46 SDA
47 GPIO42
48 GPIO43
49 GPIO44
50 GPIO7
51 GPIO51
52 VPAD-USB
© Confidential
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior
written agreement.
WI_DEV_Q26EL_UGD_002-002
Pin
Voltage I/O*
Type
BS-
VCC_2V8 I/O
PD2
BS-
VCC_2V8 I/O
PD2
BS-
VCC_2V8 I/O
PD2
VCC_1V8 O DO6
VCC_1V8 I DI
VCC_1V8 O DO2
VCC_1V8 I DI
Analog I AI
Analog O AO
Analog I AI
Analog O AO
Analog I AI
Analog O AO
Analog I AI
Analog O AO
VCC_1V8 O DO10
BS-
VCC_2V8 I/O
PD2
VCC_2V8 O B2
BS-
VCC_2V8 I/O
PD2
VCC_2V8 I/O B2
BS-
VCC_2V8 I/O
PD2
BS-
VCC_2V8 I/O
PD2
BS-
VCC_2V8 I/O
PD2
VCC_1V8* I/O
BS-
VCC_1V8 I/O
NP6
VPAD-
I AI
USB
Q26 Elite User Manual
Description
Auxiliary RS232 Receive
Auxiliary RS232 Transmit
Auxiliary RS232 Clear
Send
Auxiliary RS232 Request To
Send
Micro 2 Input Negative
Speaker 1 Output Positive,
32 Ohm Output
Micro 2 Input Positive
Speaker 1 Output Negative,
32 Ohm Output
Micro 1 Input Negative
Speaker 2 Output Positive, 8
Ohm Output
Micro 1 Input Positive
Speaker 2 Output Negative,
8 Ohm Output
Lower Byte select
I²C Clock
I²C Data
USB Power supply input
To
