2.1.4 Current Consumption

•
2mA (in Sleep Mode)
•
Up to 600mA - TX full power

2.1.5 RF Interfaces

The Q26 Elite operates in Band Class 0 and 1 modes for CDMA 1xRTT
operation. The table below defines the performance characteristics of the
radio.
Max TX RF Output Power
RX Sensitivity
Note: The values in the table above are valid at the RF connectors of the Q26
Elite into a 50 Ohm load.
The Q26 Elite Wireless CPU
These paths are separate internally and must be provide via the respective
antenna ports.

2.1.6 Environmental

•
RoHs Compliance
•
Lead Free Compliance

2.1.7 CDMA Antenna Specifications

A dual-band, tri-band or quad-band antenna may be used, depending on
customer applications. The antenna must have the following characteristics:
Characteristics
Frequency (MHz)
Impedance
1
For antenna diagnostic feature
© Confidential
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior
written agreement.
WI_DEV_Q26EL_UGD_002-002

Table 3: RF Parametrics

(Power Class III)
+24 (+2/-1)
® has two antenna connections; CDMA and GPS.

Table 4: CDMA Antenna Characteristics

US Cellular (BC0)
TX 824-849
RX 869-894
RF 50 Ohm
DC 1 10 kOhm
BC0
(Power Class II)
+24 (+2/-1)
-104 -104
Q26 Elite User Manual
BC1
Units
dBm
dBm
US PCS (BC1)
1850-1910
1930-1990
Page: 10 / 18
April 17, 2009
