Page 1: User Guide
HDMIE55 HDMI Extender over CAT5e/6 User Guide... - Page 2 Thank you for purchasing this Antiference HDMI over CAT extender product. Please read the following instructions carefully and retain this manual for future reference. Important Safety Notice Please read the below safety instructions carefully before installation and operation: 1. Do not mix up the transmitter unit (TX) and the receiver unit (RX), IR blaster extension cable and IR receiver extention cable before installation.
-
Page 3: Package Contents
The advanced power design (PoC) means only the transmitter requires power so only a single power supply unit is supplied. In addition, the HDMIE55 supports bi-directional IR control enabling control of the source from the remote location or control of a TV or device from the source location. -
Page 4: Panel Description
Panel Description Transmitter (TX) 1) CAT OUT: RJ45 connector with green & yellow indicators. Connect to receiver over CAT6 cable. The green indicator lights up when powered on. The yellow indicator lights up when transmitter and receiver are linked sucessfully. 2) IR IN: Connect the IR receiver. -
Page 5: Specifications
Specifications Transmitter Receiver Input (1) HDMI (1) CAT6 Input Connector (1) 19-pin type-A female (1) RJ45 HDMI Output (1) HDMI; (1) CAT6 (1) HDMI Output Connector (1) 19-pin type-A female (1) 19-pin type-A female HDMI; (1) RJ45 HDMI Control (1) IR IN; (1) IR OUT (1) IR IN;... - Page 6 Connection Diagram...
-
Page 7: Declaration Of Conformity
Declaration of Conformity We, ANTIFERENCE LIMITED herewith declare that the HDMI extender kit complies with all essential requirements and any other applicable conditions set forth on directive 1999/05/CE. According to the WEEE (Waste Electrical and Electronic Equipment) EU Directive, do not dispose of this product as household waste or commercial waste.
