WORKSHOP
MANUAL
SUPPLEMENT
FOREWORD
This manual outlines changes in servicing
procedures related to the chassis including
vehicle inspections and adjustments in the
newly added models. Use the following
manuals in combination with this manual as
required.
TECHNICAL INFORMATION MANUAL
WORKSHOP MANUAL
ENGINE GROUP
CHASSIS GROUP
PWJE9086-G(Supplement)
PWJE9086-H(Supplement)
ELECTRICAL WIRING PHJE9026(Basic)
PHJE9026-D(Supplement)
PHJE9026-E(Supplement)
PHJE9026-F(Supplement)
PHJE9026-G(Supplement)
PHJE9026-H(Supplement)
PARTS CATALOGUE
All information, illustrations and product
descriptions contained in this manual are
current as at the time of publication. We,
however, reserve the right to make changes
at any time without prior notice or obligation.
Mitsubishi Motors Corporation
E
PYJE9002
PWEE____
(Looseleaf edition)
PWJE9086(Basic)
PWJE9086-I(Supplement)
PHJE9026-I(Supplement)
B60356A2Aj
May 2001
General . . . . . . . . . . . . . . . . . . . . . . . .
Engine . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Lubrication . . . . . . . . . . . . .
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Cooling . . . . . . . . . . . . . . . .
Intake and Exhaust . . . . . . . . . . . . .
Engine Electrical . . . . . . . . . . . . . . .
Interior and Supplemental
Restraint System (SRS) . . . . . . . .
Chassis Electrical . . . . . . . . . . . . . .
00
11
12
13
14
15
16
17
52
54

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pajero 2001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mitsubishi MOTORS Pajero 2001

Summary of Contents for Mitsubishi MOTORS Pajero 2001

  • Page 1: Table Of Contents

    B60356A2Aj All information, illustrations and product descriptions contained in this manual are current as at the time of publication. We, however, reserve the right to make changes at any time without prior notice or obligation. Mitsubishi Motors Corporation May 2001...

  • Page 2: General

    00-1 GENERAL - How to Use This Manual/Vehicle Identification GROUP 00 GENERAL HOW TO USE THIS MANUAL INDICATION OF TIGHTENING TORQUE Tightening torques (units: N·m) are set to take into account the central value and the allowable tolerance. The central value is the target value, and the allowable tolerance provides the checking range for tightening torques.
  • Page 3 00-2 GENERAL - Vehicle Identification CHASSIS NUMBER The chassis number is stamped on the side wall of the frame near the right rear wheel. Items Contents Fixed figure Asia Distribution channel Japan channel Destination For Europe, left hand drive Body style 4 or 2-door with tailgate(back door) Transmission type 5-speed manual transmission...
  • Page 4 00-3 GENERAL - GENERAL - Major Specifications Major Specifications MAJOR SPECIFICATIONS 2-DOOR MODELS Items V24W NDGL6Y GNDGL6Y Vehicle Overall length 4,075 dimensions Overall width 1,695 1,785 Overall height (unladen) 1,835 1,845 Wheelbase 2,420 Track-front 1,420 1,465 Track-rear 1,435 1,480 Ground clearance (unladen) Overhang-front Overhang-rear...
  • Page 5 00-4 GENERAL - Major Specifications 4-DOOR MODELS Items V44W NDGL6Y GNDGL6Y Vehicle Overall length 4,655 dimensions Overall width 1,695 1,775 Overall height (unladen) 1,890 1,900 Wheelbase 2,725 Track-front 1,420 1,465 Track-rear 1,435 1,480 Ground clearance (unladen) Overhang-front Overhang-rear 1,280 Vehicle Kerb weight 1,875 1,930...
  • Page 6 00-5 GENERAL - Standard Part/Tightening-Torque Table STANDARD PART/TIGHTENING-TORQUE TABLE Each torque value in the table is a standard value The values in the table are not applicable: for tightening under the following conditions. (1) If toothed washers are inserted. (1) Bolts, nuts and washers are all made of steel (2) If plastic parts are fastened.
  • Page 7 NOTES...
  • Page 8 11-1 ENGINE CONTENTS ENGINE <4D5-Step III> ... . . ON-VEHICLE SERVICE ..... Injection Timing Check and Adjustment .

  • Page 9: Engine <4D5-Step Iii

    General/General Information/Service 11-2 ENGINE <4D5-Step III> - Specifications ENGINE <4D5-Step III> GENERAL OUTLINE OF CHANGES Some service procedures have been revised as the following changes have been made to comply to the Emission Regulation Step III. The injection timing check and adjustment procedure and the idle speed check procedure have been changed.

  • Page 10: Sealant

    11-3 ENGINE <4D5-Step III> - Sealant/Special Tools SEALANT Items Specified sealant Remarks Oil pan MITSUBISHI GENUINE PART Semi-drying sealant MD970389 or equivalent Semi-circular packing and rocker 3M ATD Part No. 8660 or equivalent cover seal, and cylinder head seal SPECIAL TOOLS Tools Number Name...

  • Page 11: On-Vehicle Service

    11-4 ENGINE <4D5-Step III> - On-vehicle Service ON-VEHICLE SERVICE INJECTION TIMING CHECK AND ADJUSTMENT The cold start device (wax type) has been discontinued as an electronically controlled injection pump has been used. The other inspection and adjustment procedures are the same as before.

  • Page 12: Oil Pan And Oil Screen

    11-5 ENGINE <4D5-Step III> - Oil Pan and Oil Screen OIL PAN AND OIL SCREEN REMOVAL AND INSTALLATION Pre-removal and Post-installation Operation Skid Plate and Under Cover Removal and Installation. Engine Oil Draining and Supplying. Front Exhaust Pipe Removal and Installation (Refer to GROUP 15 - Exhaust Pipe and Muffler.) 4 mm 19 ±...
  • Page 13 11-6 ENGINE <4D5-Step III> - Oil Pan and Oil Screen REMOVAL SERVICE POINT MD998727 MD998727 AA" OIL PAN REMOVAL INSTALLATION SERVICE POINTS "AA OIL PAN INSTALLATION 1. Remove sealant from oil pan and cylinder block mating surfaces. 2. Degrease the sealant-coated surface and the engine mating surface.

  • Page 14: Timing Belt And Timing Belt B

    11-7 ENGINE <4D5-Step III> - Timing Belt and Timing B TIMING BELT AND TIMING BELT B REMOVAL AND INSTALLATION Pre-removal and Post-installation Operation Intercooler Removal and Installation (Refer to GROUP 15.) Cooling Fan Removal and Installation. 26 ± 3 N·m 26 ±...
  • Page 15 11-8 ENGINE <4D5-Step III> - Timing Belt and Timing B REMOVAL SERVICE POINTS Timing marks AA" CRANKSHAFT PULLEY REMOVAL 1. Turn the crankshaft clockwise, align the timing marks to set No.1 cylinder to TDC of its compression stroke. Caution Never turn the crankshaft anticlockwise. 2.
  • Page 16 11-9 ENGINE <4D5-Step III> - ENGINE <4D5-Step III> - Timing Belt and Timing Belt B Timing Belt and Timing Belt B INSTALLATION SERVICE POINTS "AA TIMING BELT B INSTALLATION Timing mark 1. Align the timing marks of the 3 sprockets. 2.
  • Page 17 11-10 ENGINE <4D5-Step III> - ENGINE <4D5-Step III> - Timing Belt and Timing Belt B Timing Belt and Timing Belt B 5. Turn the crankshaft clockwise and stop at the second lobe of the camshaft sprocket. Camshaft sprocket Caution (1) When turning the crankshaft in item (5), strictly observe the specified amount of rotation (2 teeth on the camshaft sprocket) in order to apply a 2 teeth...

  • Page 18: Cylinder Head Gasket

    11-11 ENGINE <4D5-Step III> - Cylinder Head Gasket CYLINDER HEAD GASKET REMOVAL AND INSTALLATION Pre-removal Operation Post-installation Operation Intake and Exhaust Manifold Removal Timing Belt Installation (Refer to P.11-4.) (Refer to GROUP 15.) Intake and Exhaust Manifold Installation Timing Belt Removal (Refer to P.11-4.) (Refer to GROUP 15.) Engine Coolant Draining.
  • Page 19 11-12 ENGINE <4D5-Step III> - Cylinder Head Gasket REMOVAL SERVICE POINTS AA" RADIATOR UPPER HOSE DISCONNECTION After making mating marks on the radiator upper hose and the hose clamp, disconnect the radiator upper hose. AB" FUEL INJECTION PIPE REMOVAL When loosening nuts at both ends of injection pipe, hold Delivery holder the delivery holder (for pump side) and the injection nozzle assembly (for nozzle side) with wrench and loosen nut.
  • Page 20 11-13 ENGINE <4D5-Step III> - Cylinder Head Gasket INSTALLATION SERVICE POINTS "AA CYLINDER HEAD GASKET INSTALLATION When replacing the cylinder head gasket only, confirm the gasket identification mark, and then select a replacement part according to the table below: Spec Identification mark (size) Parts num-...
  • Page 21 11-14 ENGINE <4D5-Step III> - Cylinder Head Gasket 5. Tighten the cylinder head bolts according to the following procedure (angle-tightening procedure.) (1) Use the special tool to tighten the cylinder head bolts in the order of the illustrated numbers to 29 ± 2 N·m. MD998051 Front of engine (2) Place the special tool in a wrench to tighten the...
  • Page 22 12-1 LUBRICATION - General/Lubricant GROUP 12 LUBRICATION GENERAL OUTLINE OF CHANGE The engine oil quantity has been changed as variable geometry (VG) turbocharger has been used. LUBRICANT 4D5-Step III 4D5-Step III Items Items Engine oil quantity L Oil filter Oil cooler Total...
  • Page 23 NOTES...
  • Page 24 13-1 FUEL CONTENTS FUEL SYSTEM <4D5-step III> ..Control Relay Continuity Check ....Accelerator Pedal Position Sensor (APS) GENERAL .

  • Page 25: Fuel System <4D5-Step Iii

    13-2 FUEL SYSTEM <4D5-step III> - General/General Information FUEL SYSTEM <4D5-step III> GENERAL OUTLINE OF CHANGES Some service procedures have been established as the following changes have been made due to the compliance with the Emission Regulation Step III. An electronic-controlled fuel injection pump has been used. A crankshaft position sensor has been used as the electronic-controlled fuel injection pump has been used.
