MicaSense RedEdge-M Integration Manual

Dji matrice 100
Hide thumbs Also See for RedEdge-M:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
by
RedEdge-M
/ DJI Matrice 100
TM
I N T E G R A T I O N G U I D E
P/N: 900-00009
Rev 01 - Nov 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RedEdge-M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MicaSense RedEdge-M

Summary of Contents for MicaSense RedEdge-M

  • Page 1 RedEdge-M / DJI Matrice 100 I N T E G R A T I O N G U I D E P/N: 900-00009 Rev 01 - Nov 2017...

  • Page 2: Table Of Contents

    Table of Contents Thank you for your purchase! What’s inside? What’s Required? Let’s get started! Attaching the RedEdge and the RedEdge Mount Attaching DLS/GPS mast assembly Powering the RedEdge-M Support...

  • Page 3: Thank You For Your Purchase

    Thank you for your purchase! These instructions show how to integrate the MicaSense RedEdge-M with a DJI Matrice 100. This will cover attaching mounting brackets included in the kit, powering the camera from the host system, and placement of the Downwelling Light Sensor (DLS) and GPS puck.

  • Page 4: What's Required

    *NOTE: These instructions assume that the Matrice 100 has a battery bay installed on the bottom of the aircraft main body. The RedEdge-M mount attaches to the bottom of the battery bay. 1. Locate the M3 screws, M3 flat washers, M3 lock washers, and RedEdge-M mount. 2. Attach the mount to the back of the RedEdge-M.

  • Page 5: Attaching Dls/Gps Mast Assembly

    Attaching DLS/GPS mast assembly 1. Locate and remove the DJI mast kit from its packaging. 2. Insert the longest carbon rod into the base mount. 3. Secure the base mount with the included M2 screw 4. Place the top cap on the other side of the carbon rod 5.
  • Page 6 14. Using scissors or similar, trim the zip ties. Warning: Failure to properly secure loose wires may lead to interference with the aircraft propellers. This may damage the Matrice 100, RedEdge-M, or both. DLS and GPS attached to mounting plate.

  • Page 7: Powering The Rededge-M

    XT30 connector plugged into distribution board 2. Connect the RedEdge-M (3 pin DF13) connector into the power port of the camera. 3. Using VHB tape, secure the BEC to the Matrice 100 frame and secure any loose wires with the provided zip ties.
  • Page 8 LOST PROFITS, OR REPLACEMENT PRODUCT COSTS ARISING OUT OF THE PURCHASE, USE, OR PERFORMANCE OF THE MICASENSE ACCESSORIES, UNDER ANY THEORY OF LIABILITY, EVEN IF MICASENSE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. MICASENSE DISCLAIMS ANY IMPLIED WARRANTY...
  • Page 9 Have multiple UAVs? RedEdge-M quickly inte- grates with many different drone platforms. PROCESS With RedEdge-M, you own your data. You’re not limited to a particular process- ing platform. You can choose whichever platform is best for you, your customer, or your project.
  • Page 10 Located in Seattle, Washington, MicaSense delivers integrated solutions for data gathering, processing, and analytics across the global agriculture market. With decades of expertise in widely varied UAV applications, the MicaSense team is redefining remote sensing technology and pioneering new ways to collect and analyze information.
