- Page 1 Xanura home automation system ™ • Technical description • Functionalities Home automation for new and existing buildings • Application examples • Sales support • Installation tips • Ordering information Home automation...
-
Page 2: Table Of Contents
Contents Introduction Schematic summary: complete modular concept Functionalities Xanura Operation Product description • Switching actuators • Dimming actuators • Interfaces • RF components • Remaining components Practical examples Sales support Ordering information... -
Page 3: Introduction
• Can be used for lighting and various types of electrical appliances How is that possible? Simply because Xanura can be • Can optionally be operated via a PC with applied in existing lighting networks and be operated Xanura software with any type of switching device. -
Page 4: Schematic Summary: Complete Modular Concept
Complete modular concept In the schematic example below, a number of the most Xanura is a modular and very flexible house automation popular Xanura applications are illustrated. A concise system. As a result, it is possible to offer for each... - Page 5 TV, video, DVD, audio (infrared) and various Xanura applications. (Radio frequencies). • RF-Interface Xanura Receives RF signals from the remote control device and transposes these into Xanura commands that are then sent via the mains. • On/Off Interface Xanura Switch interface for mounting behind switches or pulse switches.
-
Page 6: Functionalities Xanura
Xanura functionalities What can a consumer actually do with Xanura? A simple question that is difficult to answer. Due to the flexible character of the Xanura system, it is impossible to describe all the specific application possibilities. With the computer interface and Xanura software, it is possible to perform with Xanura in a simple way, almost any switching operation that can be translated into conditions and actions (IF...AND/OR...THEN..). - Page 7 What can Xanura offer in the area of protection? With Xanura it is possible to create the impression that the home is being lived in, even when nobody is at home during short or longer periods. This is accomplished by switching on and off lighting and other appliances in accordance with preselected programmes.
-
Page 8: Operation
Operation Xanura is a system that is easy to apply. Because Invisable mounting use is made of the (existing) lighting network, Thanks to their compact design (45x45x16mm), investment of time and money for a special network Xanura modules can be mounted behind wall sockets is not necessary. - Page 9 The computer interface offers additional possibilities home. The computer interface is then connected to the for an Xanura installation, but is not an essential COM-port of the PC so that the requirements can be component. When a resident is only interested in programmed.
- Page 10 No demolition or chasing work Xanura can be applied in both new and existing homes. Installation tools No demolition or chasing work is necessary. To be able to install Xanura quickly and professionally,...
-
Page 11: Product Description
For remote control switching and dimming, each (switching) point to be automated requires an actuator. All these actuators are provided with an address. Xanura actuators can be mounted in the built-in junction boxes that are located behind the (switching) points. Depending on the application, actuators suitable for mounting behind wall sockets or switches are available. -
Page 12: Dimming Actuators
Prog. Operation wall socket can be energized or dimmed by remote DAX10 control. The DAX10 can be switched and dimmed by means of Xanura commands originating from Junction Characteristics Xanura interfaces or remote control devices. • 25-250 W Installation instructions •... -
Page 13: Interfaces
Depending on the application, various interfaces can be used. Apart from the modular built-in interfaces, other interfaces are also included in the Xanura package. The latter includes the computer interface that, amongst other things, adds time functions to the system. The most important interfaces are mentioned below. - Page 14 AIX12, which Adres Prog. points (or appliances) provided with switching actuators in turn sends an Xanura command. Xanura scenarios AIX12 and/or to start scenarios after a movement detector has can also be created by applying an AIX12 in operated.
- Page 15 3 or 4-way pulse switches. With this pulse can control, via the lighting network, 2 SAX1 modules switch, it is possible to send VIX10 Xanura commands that operate air-suction-ventilators installed in homes. to the switch actuators that feed the mechanical These ventilators have three operating positions.
- Page 16 Product description online with the computer interface. In the CIX, it is possible to store individual Xanura • 256 addresses that can immediately be switched scenarios that can be carried out in a home provided with or dimmed to any dimming position desired Xanura components.
- Page 17 The input connectors and switching output 5...24V a.c./d.c. electronic lock or heating system (24 V a.c.) to Xanura. connectors operate independently of each other. Send and receive addresses have to be...
- Page 18 The PIOX15 is an on/off interface in a module housing The input and output connectors 5...15Vdc for linking up Xanura to external systems such as health work independently of each other. Address 2 care alarms. Conventional (12V) alarm systems can also...
-
Page 19: Rf Components
RF-components By applying radio frequency Xanura components, it is possible to operate Xanura installations by remote control. A special characteristic of the RF components is that the signals can easily travel through walls and ceilings, so that the sender and receiver do not need to be in the same room. The most important RF components are mentioned below. -
Page 20: Remaining Components
Remaining components The Xanura assortment provides a range of other products: a description of those most applied is given below. SFX40 suppression filter 1- phase System 3- phase System DIN modular component 72 mm 3 x 72 mm L3 N... - Page 21 The ZAX is a sun blind actuator that can be applied The ZAX can be operated manually by means for operating rolling shutters and sun blinds. of the operating handle supplied. The ZAX can also be operated by means of Xanura commands Characteristics transmitted from other Xanura interfaces or •...
-
Page 22: Practical Examples
Practical examples To give an impression of the layout of a Xanura installation and the materials that are required, a comprehensive practical example is shown below. The desires with respect to the switching and dimming possibilities that are described in the left-hand column of the table below and on the following page, are depicted in the diagram by the modules and other Xanura components required. - Page 23 By providing the wall sockets with a SAX1 module, the wall socket junction box on the plugged in a wall socket either by remote control right-hand-side (f) can be switched by a Xanura command. The command can be given with and/or automatically via a scenario.
-
Page 24: Sales Support
Xanura, whereby the customer is assured of a satisfactory explanation by a well trained engineer who is able to install Xanura systems.The basis of a successful marketing approach is: simplicity, low threshold products, comprehensive... - Page 25 "Easy Living With Xanura." CD-Rom "Live in your own home longer" Customer brochure with limited technical Xanura is very suitable for application in the information. health care sector, in combination with specific products that have been developed for this area of application.
-
Page 26: Ordering Information
Ordering information Description Type Eaton/Holec No. Reference No. Switching actuator 16 A, built-in module SAX1 1807 505 31935 6 Switching actuator/switch interface 16 A, built-in module SAIX 1807 508 53346 2 On/off interface, built-in module 1807 523 74525 4 On/off interface 230 V, built-in module... - Page 27 Mains filter box with phase coupler, System 55 HIFS35/3 1769 922 85151 1 Programming unit 1807 524 82025 5 Due to its policy of continuous research and development, Eaton Holec reserves the right to change the design and specifications of its products without notice.
- Page 28 TV, video, DVD, audio (infrared) and various Xanura applications. (Radio frequencies). • RF-Interface Xanura Receives RF signals from the remote control device and transposes these into Xanura commands that are then sent via the mains. • On/Off Interface Xanura Switch interface for mounting behind switches or pulse switches.
- Page 29 Type ASVX, Eaton Holec No. 1807 594, Reference No. 634510 Complete package for operation of 3-position air suction ventilators in homes by means of Xanura. By applying more VIX10 interfaces, the 3-position ventilator can be operated from various locations in the home.
