Instruction Manual
1. Description of the Device:
Polymerization of any commercial material can be carried out with the universal light polymerization
device Speed Labolight. Overheating in case of long term operation is prevented by a cooling device on
the back of Speed Labolight. The polymerization temperature of 40 °C will not be exceeded. Eight
lamps, arranged around the turntables, as well as a halogen lamp transport the polymerization light to
every spot of the object. These lamps belong to the standard equipment and make emission of ultra-
violet rays and white light possible, thus covering the range of all photo active materials between
320 – 550 nm. The lamps have to be replaced after 1,000 working hours. A meter indicates the total
working time. The control unit on the front desk controls the polymerization time from 1 second to
99 minutes. A continuous acoustic signal (30 seconds) indicates the end of the polymerization process.
2. Installation and Start:
Speed Labolight has to be set up on a plain surface in such a way that the cooling grid on the back does
not obstruct the device. The distance between Speed Labolight and walls or other equipments should
be min. 15 cm in order to guarantee a sufficient ventilation. Remove the cover between the halogen
lamp and the disc. The lamps T 1 (white light) and T8 S (black light) are plugged alternately T1 - T8 -
T1 - T8, etc. (s. picture 1). Use the halogen lamp according to picture 2. Put the refractory disc in the
special ring onto the turntable. First, connect the safety plug of the feed line to the device, then plug it
in. Adjust the main switch to "1".
1
(1) Main switch
(2) Button START: by pushing it when the device is ON, the polymerization process starts. By pushing
it during the process the cycle starts to a halt.
(3) Button MENU: by pushing it, you can change the process parameters, that is: the time (in minutes)
of the polymerization process, the time of the final cooling, the possibility to perform a polymeri-
zation process either with or without the HALOGEN LAMP.
(4) These buttons are used to modify the values during the polymerization process setting.
(5) Display LCD
2
2
3
4
5
