SPEED LABOLIGHT
®
Instruction Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the SPEED LABOLIGHT and is the answer not in the manual?

Questions and answers

Related Manuals for HAGER WERKEN SPEED LABOLIGHT

Summary of Contents for HAGER WERKEN SPEED LABOLIGHT

  • Page 1 SPEED LABOLIGHT ® Instruction Manual...

  • Page 2: Installation And Start

    2. Installation and Start: Speed Labolight has to be set up on a plain surface in such a way that the cooling grid on the back does not obstruct the device. The distance between Speed Labolight and walls or other equipments should be min.
  • Page 3 3.a Putting into Operation: • Adjust main switch to position 1 (on). • Open the device by lifting the door. • P lace the object to be polymerized onto the turntable. If necessary, use special holder. Make sure that the object is set up vertically near the lamps. • Close the door. • Push button 3 (MENU) and select: 1: the polymerization time in minutes. To modify the selected value, push buttons 4. When the chosen value is visualized, push button 3 (MENU) again to confirm and move on to the follow- ing phase.

  • Page 4: Warranty

    4. The Lifetime of the Lamps and Replacement 1. The lifetime of the lamps is about 1,000 working hours. The device is provided with a time meter, which calculates and adds the hours and minutes of work. To visualize the time meter and to check the total of working hours, proceed as follows: • Switch off the device • S witch on the device, keeping the “+” button pushed: the total amount of the working time of the...
  • Page 5 7. Technical Data: Current consumption: 225 W Current supply: 230 V, 50 Hz Fuse: 1 x 2.5 A Lamps: 8 x White light: 4 x Black light: Osram Dulux S 9 W/71 Osram Dulux S 9 W/78 or optionally: or optionally: Philips PLS –...
  • Page 6 9. Examples for Polymerization Time: Polymerization times for Vita VM LC: In order to achieve hardening appropriate for the material involved, the object to be polymerized on the 40 mm special rings on the slide has to be placed in the center of the turntable within the light cone of the halogen lamp.
  • Page 7 2,5 approx. 1 LICUPLAST Stain Colors ≤ 0,2 approx. 1 NOTE! When working with SOLIDEX and LICUPLAST, the SPEED LAbOLIghT has to be equipped with 8 Oxram Dulux S 9W/71 lamps and 1 Osram hLX 15V/150W lamp.
  • Page 8 401 125 WEEE­Reg.Nr.: DE 21760541 As of: September 2017 HAGER & WERKEN GmbH & Co. KG Ackerstraße 1 47269 Duisburg, Germany T +49 (203) 99 26 9-0 F +49 (203) 29 92 83 www.hagerwerken.de...
