INSTALLATION AND
OPERATION MANUAL
Solahart300BLK • Solahart305BLK • Solahart310BLK • Solahart315BLK
Valid for Australia and New Zealand

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Solahart300BLK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Solahart Solahart300BLK

  • Page 1 INSTALLATION AND OPERATION MANUAL Solahart300BLK • Solahart305BLK • Solahart310BLK • Solahart315BLK Valid for Australia and New Zealand...
  • Page 2: Table Of Contents

    Danger: Risk of fatal injury 2 PLANNING friendly solar electricity. • Attention: Risk of serious injury In order to ensure the maximum performance of your Solahart or damage to property Technical specifications solar modules, please read the following instructions care- •...
  • Page 3: Introduction

    INTRODUCTION PLANNING 2.1 Technical specifications Validity For additional information see the relevant datasheet of the module provided at www.solahart.com.au. These instructions are only valid for crystalline solar modules from the company Solahart. Solahart assumes PRODUCT LINE Solahart300BLK Solahart305BLK Solahart310BLK Solahart315BLK...
  • Page 4: Requirements

    • Compliant with local snow and wind loads. Fig. 2: Installation options for crystalline Solahart modules. All dimensions are given in mm. Also observe the allowed static loads and clamping range as specified on the following page. • Properly fastened to the ground, the roof, or the façade.
  • Page 5: Electrical Layout

    Ensure that the maximum reverse current load capacity Ä Ä [PA] [PA] class. indicated in the data sheet is met. SOLAHART300BLK CL1 / CL3 250 - 450 In order to limit reverse currents that may occur, we SOLAHART305BLK Safety Factor recommend using the following safety options:...
  • Page 6: Installation

    INSTALLATION 3.1 Safety and transport INSTALLATION 3.1 Safety and transport ! Risk of fatal injury due to electric ! Module damage may occur! Ä Ensure that all personnel are aware of DANGER NOTE NOTE ! Module damage may occur! shock! and adhere to accident-prevention and Ä...
  • Page 7: Preparation Of Installation 12 Ä

    INSTALLATION 3.2 Preparation of installation INSTALLATION 3.3 Module installation ! Risk of fatal injury due to electric ! Risk of injury due to falling mod- Option 1: DANGER WARNING Ä Maintain an interval of at least 10 mm shock! ules! Ä...
  • Page 8: Electrical Connection

    ELECTRICAL CONNECTION 4.1 Safety ELECTRICAL CONNECTION 4.2 Electrical installation safety DANGER! ! Risk of fatal injury due to electric ! Risk of fatal injury due to electric ! Risk of fatal injury due to electric DANGER DANGER DANGER Risk of fatal injury due to electric shock! shock! shock! shock!
  • Page 9: After Installation

    ELECTRICAL CONNECTION ELECTRICAL CONNECTION 4.4 After installation 4.3 Connection of modules ! Module damage may occur! Ä Use solar cables for the connection at NOTE ! Module damage may occur! Ä Ensure that all necessary safety and NOTE the junction box outlet. functional tests have been carried out Ä...
  • Page 10: Faults And Defects

    GROUNDING FAULTS AND DEFECTS MAINTENANCE AND CLEANING Protective Grounding DANGER! Solahart solar modules are known for a long operating ! Module damage may occur! NOTE Ä The modules must be grounded in accordance with Risk of fatal injury due to electric shock! life and minimal maintenance effort and expense.
  • Page 11 LICENSE HOLDER AND IMPORTER: SOLAHART INDUSTRIES PTY LTD., 1 Alan St. Rydalmere, NSW 2116, Australia MANUFACTURER: HANWHA Q CELLS KOREA CORP., #1329 Daegum-ro, Geumwang-Eup, Eumseong-gun, ChungCheongbuk-do, Korea 369-901 Subject to change without notice. © Hanwha Q CELLS Installation Manual SolahartXXXBLK_2018-10_Rev01_AU...
