VivoLink VL120026 User Manual

6-input seamless scaler switcher & hdbaset receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual
VL120026
6-input Seamless Scaler Switcher &
HDBaseT Receiver

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VL120026 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VivoLink VL120026

Summary of Contents for VivoLink VL120026

  • Page 1 User Manual VL120026 6-input Seamless Scaler Switcher & HDBaseT Receiver...
  • Page 2 All product function is valid till 2017-5-3. Trademarks Product model, VivoLink are trademarks of EET Europarts A/S. Any other trademarks mentioned in this manual are acknowledged as the properties of the trademark owner. No part of this publication may be copied or reproduced without the prior written consent of EET Europarts A/S.
  • Page 3 6-input Seamless Scaler Switcher & HDBaseT Receiver SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference.  Unpack the equipment carefully and save the original box and packing material for possible future shipment ...

  • Page 4: Table Of Contents

    6-input Seamless Scaler Switcher & HDBaseT Receiver Contents 1. Introduction ......................... 1 1.1 Brief Introduction ....................1 1.2 Features ......................1 1.3 Package List ...................... 2 2. Panel Description ......................3 2.1 Seamless Scaler Switcher ................. 3 2.2 HDBaseT Receiver .................... 5 3.
  • Page 5 6-input Seamless Scaler Switcher & HDBaseT Receiver 6.3.8 CEC Input Commands ................24 6.3.9 CEC Output Commands ................ 24 6.3.10 EDID Configuration ................25 6.3.11 HDCP Compliance ................26 6.3.12 Device Setup ..................26 7. OSD Menu Control ....................28 7.1 OPTIONS ......................

  • Page 6: Introduction

    6-input Seamless Scaler Switcher & HDBaseT Receiver 1. Introduction 1.1 Brief Introduction This product is a professional Scaler Switcher Kit consists of multi-format Seamless Scaler Switcher and HDBaseT Receiver. The Scaler Switcher scales HDMI/DP/VGA video signals to an HDMI and HDBaseT output simultaneously.

  • Page 7: Package List

    6-input Seamless Scaler Switcher & HDBaseT Receiver 1.3 Package List  1 x Seamless Scaler Switcher  2 x Mounting Ears with 4 Screws  2 x Long Mounting Ears with 6 Screws (Optional)  1 x Power Adapter (24VDC,2.71A) ...

  • Page 8: Panel Description

    6-input Seamless Scaler Switcher & HDBaseT Receiver 2. Panel Description 2.1 Seamless Scaler Switcher  Front Panel 1-HDMI/MHL 2-HDMI 3-HDMI 4-HDMI 5-DP 6-VGA AUTO SOURCE ENTER MENU/3s RES RESET/3s VOLUME ① Built-in IR Receiver. ② Power Indicator- RED when the device is in standby, GREEN when device is powered on and no indicator when there is no power to device.
  • Page 9 6-input Seamless Scaler Switcher & HDBaseT Receiver  Rear Panel AUDIO IN CONTROL AUDIO OUT POWER 1-AUDIO 2-AUDIO IR IN IR OUT IR EYE RS232 TCP/IP DC 24V HDBT 1-HDMI/MHL 2-HDMI 3-HDMI 4-HDMI 5-DP 6-VGA HDMI INPUTS OUTPUTS ① INPUTS - Video input ports: 1 HDMI/MHL, 3 HDMI inputs, 1 DP and 1 VGA.

  • Page 10: Hdbaset Receiver

    6-input Seamless Scaler Switcher & HDBaseT Receiver 2.2 HDBaseT Receiver  Front Panel UPDATE B UPDATE A LINK HDCP CTRL ① RS232 Mode switcher  CTRL: RS232 pass-through control mode;  UPDATE A: Update Valens IC program, connect a PC to the RS232 port, and then double-click the update file (.bat).
  • Page 11 6-input Seamless Scaler Switcher & HDBaseT Receiver ⑤ AUDIO OUT -3.5mm stereo audio jack, connect to analog stereo audio device. ⑥ COAX OUT - Coaxial audio connector, connect to digital audio device. ⑦ OPTICAL OUT - Optical audio connector, connect to optical audio devices. ⑧...

  • Page 12: System Connection

    6-input Seamless Scaler Switcher & HDBaseT Receiver 3. System Connection 3.1 Usage Precautions  System should be installed in a clean environment and has a prop temperature and humidity.  All of the power switches, plugs, sockets and power cords should be insulated and safe.
  • Page 13 6-input Seamless Scaler Switcher & HDBaseT Receiver Step4. Connect audio source device to the audio input port with audio cable. Step5. Connect a HDMI display device to HDMI output port with HDMI cable. Step6. Connect HDBaseT Receiver to HDBT output port with twisted pair. Step7.

  • Page 14: Button Control

    6-input Seamless Scaler Switcher & HDBaseT Receiver 4. Button Control Front panel buttons can be used for switching operations and volume adjusting. 4.1 Manual-Switching Press 1-HDMI/MHL, 2-HDMI, 3-HDMI, 4-HDMI, 5-DP, 6-VGA on front panel to select the corresponding input source. 4.2 Auto-Switching Press AUTO to enter in auto-switching mode, and the auto-switching mode abides by the following principles:...

  • Page 15: Ir Control

    6-input Seamless Scaler Switcher & HDBaseT Receiver 5. IR Control 5.1 IR Remote Connect IR receiver to IR EYE port, the Scaler Switcher cans be controlled by using the including IR Remote. As CEC function, it is able to use the IR Remote to turn on/off the HDMI source or Display.

  • Page 16: Control Far-End Display Device

    6-input Seamless Scaler Switcher & HDBaseT Receiver 5.2 Control Far-end Display Device Connect an IR Receiver to IR IN port on the Scaler Switcher and connect IR Emitter to the IR OUT port on the HDBaseT Receiver, the far-end device(such as Projector) can be control by its IR Remote.

  • Page 17: Cec Function

    6-input Seamless Scaler Switcher & HDBaseT Receiver HDMI: HDBaseT: IR Control: AUDIO IN CONTROL AUDIO OUT POWER 1-AUDIO 2-AUDIO IR IN IR OUT IR EYE RS232 TCP/IP DC 24V HDBT 1-HDMI/MHL 2-HDMI 3-HDMI 4-HDMI 5-DP 6-VGA HDMI INPUTS OUTPUTS IR Emitter HDBaseT Receiver DVD Remote IR Receiver...
  • Page 18 6-input Seamless Scaler Switcher & HDBaseT Receiver Scaler Switcher Remote IR Receiver HDMI: HDBaseT: IR Control: AUDIO IN CONTROL AUDIO OUT POWER 1-AUDIO 2-AUDIO IR IN IR OUT IR EYE RS232 TCP/IP DC 24V HDBT 1-HDMI/MHL 2-HDMI 3-HDMI 4-HDMI 5-DP 6-VGA HDMI INPUTS...

  • Page 19: Rs232 Control

    6-input Seamless Scaler Switcher & HDBaseT Receiver 6. RS232 Control As RS232 can be transmitted bi-directionally between the Scaler Switcher and HDBaseT Receiver, so it is able to control a third-party device from local or control the Scaler Switcher from remote. The baud rate support 2400, 4800, 9600(default), 19200, 38400, 57600 or 115200.

  • Page 20: Installation/Uninstallation Of Rs232 Control Software

    6-input Seamless Scaler Switcher & HDBaseT Receiver ② Control Scaler Switcher or Third-party Device form Remote Firstly, according the following connection diagram to connect all devices as needed. Secondly, send command 50788% via RS232 communication software. Lastly, send the right command to control the Scaler Switcher: RS232: HDBaseT: Third-party device...
  • Page 21 6-input Seamless Scaler Switcher & HDBaseT Receiver The interface of the control software is showed as below: Parameter Configuration area Monitoring area, indicates if the command sent works. Command Sending area Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit correctly, and then you are able to send command in Command Sending Area.

  • Page 22: Rs232 Communication Commands

    6-input Seamless Scaler Switcher & HDBaseT Receiver 6.3 RS232 Communication Commands Communication protocol: RS232 Communication Protocol Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none 6.3.1 RS232 Control Mode Switching Command Function Feedback Example Enable RS232 control mode 1: Control RS232 Mode RS232...

  • Page 23: Audio Adjusting

    6-input Seamless Scaler Switcher & HDBaseT Receiver HDMI2/ HDMI3/ HDMI4/ DP/VGA/ YPbPr/ AV) 50785% Enable auto-switching. Auto Switch 50786% Disable auto-switching. Manual Switch 6.3.3 Audio Adjusting Command Function Feedback Example 50600% Mute source audio. Source Mute 50601% Unmute source audio. Source Unmute 50751% Get the Source mute status.
  • Page 24 6-input Seamless Scaler Switcher & HDBaseT Receiver Unmute 50660% Disable 1-HDMI audio. HDMI1 Audio Mute 50661% Enable 1-HDMI audio. HDMI1 Audio Unmute 50662% Disable 2-HDMI audio. HDMI2 Audio Mute 50663% Enable 2-HDMI audio. HDMI2 Audio Unmute 50664% Disable 3-HDMI audio. HDMI3 Audio Mute 50665% Enable 3-HDMI audio.

  • Page 25: Vga Scaling Configuration

    6-input Seamless Scaler Switcher & HDBaseT Receiver Embedded Audio Output: 50648% Enable HDMI embedded audio output. enable Embedded Audio Output: 50649% Disable HDMI embedded audio output. disable 6.3.4 VGA Scaling Configuration The default output resolution for VGA is 1920x1080. Below is a list of the output resolutions the built-in scaler can output.
  • Page 26 6-input Seamless Scaler Switcher & HDBaseT Receiver 503xx% Set the contrast to xx. Contrast: xx (xx=00~99) 50637% Get the contrast. Contrast: xx (xx=00~99) 504xx% Set the saturation to xx. Saturation: xx (xx=00~99) 50638% Get the saturation. Saturation: xx (xx=00~99) 505xx% Set the sharpness to xx.

  • Page 27: Auto Power-Off Setup

    6-input Seamless Scaler Switcher & HDBaseT Receiver Icon: disable Freeze Icon: enable/Freeze Icon: disable 50651% Get Volume Icon display status. Volume Icon: xxxx Auto-adjust the input parameter(VGA 50606% VGA Input Auto only) 50678% Enable screen output adjusting. Enter Output Position Adjust 50679% Disable screen output adjusting.

  • Page 28: Osd Menu Control

    6-input Seamless Scaler Switcher & HDBaseT Receiver Auto Switch Mode: Set the auto power-off 50715% Auto power off: 1min time to 1 minute when No signal input. Auto Switch Mode: Set the auto power-off 50716% Auto power off: 2min time to 2 minute when No signal input. Auto Switch Mode: Set the auto power-off 50717% Auto power off: 5min...

  • Page 29: Cec Input Commands

    6-input Seamless Scaler Switcher & HDBaseT Receiver 6.3.8 CEC Input Commands Command Function Feedback Example 50686% Enable CEC Input. HDMI CEC ON 50687% Disable CEC Input. HDMI CEC OFF 50901% Play & pause. CEC cmd: play&pause 50902% Stop. CEC cmd: stop 50903% Menu.

  • Page 30: Edid Configuration

    6-input Seamless Scaler Switcher & HDBaseT Receiver 50922% Power on output display device. Display Power On 50923% Power off output display device. Display Power Off 6.3.10 EDID Configuration Command Function Feedback Example 50731% Set 1-HDMI/MHL EDID to 720P. HDMI1 EDID:720P 50732% Set 1-HDMI/MHL EDID to 1080P.

  • Page 31: Hdcp Compliance

    6-input Seamless Scaler Switcher & HDBaseT Receiver 6.3.11 HDCP Compliance Command Function Feedback Example 50791% HDCP Active mode. HDCP Active. 50792% HDCP Manual mode. HDCP Manual. 50793% Enable HDCP output. HDCP ON 50794% Disable HDCP output. HDCP OFF HDCP Active/HDCP Manual 50795% Get HDCP status.
  • Page 32 6-input Seamless Scaler Switcher & HDBaseT Receiver Auto Switch/Manual Switch VGA Mute/Unmute...

  • Page 33: Osd Menu Control

    6-input Seamless Scaler Switcher & HDBaseT Receiver 7. OSD Menu Control The Scaler Switcher provides a powerful OSD operation menu, including 3 parts: optional settings, picture settings, and system setup. There are three ways to enter OSD menu: ① Long-press the button MENU/3s on front panel 2 seconds or more. ②...

  • Page 34: Picture

    6-input Seamless Scaler Switcher & HDBaseT Receiver and output setting (HDMI on/off and HDBT on/off). Input Selection: Select video source format for VGA input, includes AV 1 (C-video signal), VGA 1 (VGA signal) and YPbPr 1 (Component video signal). Baud rate: Set the baud rate for RS232 control, and it support 2400、 4800、 9600、 19200、 38400、57600、115200.

  • Page 35: Setup

    6-input Seamless Scaler Switcher & HDBaseT Receiver  Aspect Ratio: Include Native, 4:3, 16:9, Zoom1, Zoom2, Just Scan, and Panorama. VGA format only supports 4:3, 16:9 and Panorama. 7.3 SETUP Including OSD language, restore factory default, HDMI CEC and version inquiry. ...

  • Page 36: Web-Based Gui Control

    6-input Seamless Scaler Switcher & HDBaseT Receiver 8. Web-based GUI Control In addition to control the Scaler Switcher via front panel button, IR remote and RS232 communication software. The Scaler Switcher can be controlled via web-based GUI. It allows users to interact with the Scaler Switcher through graphical icons and visual indicators.
  • Page 37 6-input Seamless Scaler Switcher & HDBaseT Receiver  Sources: Click the corresponding button (1-HDMI/MHL, 2-HDMI, 3-HDMI, 4-HDMI, 5-DP and 6-VGA) to select video input source.  AUTO: Click this button to enter auto-switching mode.  Adjust: Click this button to adjust the position of VGA video output image to make sure the best visual effect.

  • Page 38: Configuration Menu

    6-input Seamless Scaler Switcher & HDBaseT Receiver 8.2 Configuration Menu ① Setting Click on control menu to enter configuration menu shown as below:  Output Resolution: Select the output resolution.  Update: Insert the USB flash disk with EDID file/software updating file to the FIRMWARE port, and then click EDID/Firmware to start update procedure.
  • Page 39 6-input Seamless Scaler Switcher & HDBaseT Receiver ③ Source Click Source Label to enter the below menu to rename the input selection buttons.

  • Page 40: Rs232 Control Menu

    6-input Seamless Scaler Switcher & HDBaseT Receiver 8.3 RS232 Control Menu Click RS232 Control on the top of interface to enter the below menu to send commands to control the Scaler Switcher or far-end third-party device.  Port: Local refers to the RS232 port of the Scaler Switcher, and HDBT refers to the RS232 port of HDBaseT Receiver.

  • Page 41: Password Menu

    6-input Seamless Scaler Switcher & HDBaseT Receiver 8.4 Password Menu Click Password on the top of interface to enter the below menu to reset the username and password. 8.5 Web-based GUI Update Web-based GUI for the Scaler Switcher supports online update in http://192.168.0.178:100.

  • Page 42: Specification

    6-input Seamless Scaler Switcher & HDBaseT Receiver 9. Specification 9.1 Seamless Scaler Switcher Video (1) HDMI/MHL; (3) HDMI; (1) DP; (1) VGA Video Input (4) Female HDMI; (1) DisplayPort; (1) Female VGA Video Input Connector (15-pin) Input Video Signal HDMI, DP, YPbPr, C-video, VGA (1) HDMI;...

  • Page 43: Hdbaset Receiver

    6-input Seamless Scaler Switcher & HDBaseT Receiver 9.2 HDBaseT Receiver Video& Audio (1) HDBT IN Input (1) HDMI OUT; (1) AUDIO OUT; (1) COAX OUT; (1) Output OPTICAL OUT (1) IR IN, (1) IR OUT, (1) RS232 Control Ports General Transmission Mode &...

  • Page 44: Panel Drawing

    6-input Seamless Scaler Switcher & HDBaseT Receiver 10. Panel Drawing AUDIO IN CONTROL AUDIO OUT POWER 1-AUDIO 2-AUDIO IR IN IR OUT IR EYE RS232 TCP/IP DC 24V HDBT 1-HDMI/MHL 2-HDMI 3-HDMI 4-HDMI 5-DP 6-VGA HDMI INPUTS OUTPUTS 6-input Seamless Scaler Switcher with HDBaseT 6-input Seamless Scaler Switcher with HDBaseT 250 mm 1-HDMI/MHL...

  • Page 45: Troubleshooting & Maintenance

    6-input Seamless Scaler Switcher & HDBaseT Receiver 11. Troubleshooting & Maintenance Problems Causes Solutions quality Try another high quality connecting cable cable. Output image with snowflake Make sure the connection Fail or loose connection is good Check with oscilloscope or No signal at the input / multimeter if there is any output end...

  • Page 46: After-Sales Service

    6-input Seamless Scaler Switcher & HDBaseT Receiver 12. After-sales Service If there appear some problems when running this product, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty. ①...
