Operation
Section 4: Operation
In the stand alone mode the temperature or digital input status can be monitored by using a web
browser, the CBW Mobile app, and/or by sending text commands to an XML status/control page when
the internal web server is enabled.
4.1 Browser Operation
Once the XW11x is set up, users can access the Control Page using a web browser by typing the IP
address of the XW11x into the web browser address bar. For example, using the default IP address, the
user would enter http://192.168.1.2. If the IP address is changed from the default, the user must use the
new IP address. Note that if any port is used other than the default port 80, the port must also be
included in the request. For example, to access the device at port 8000 enter: http://192.168.1.2:8000.
4.1.1 XW-110 Temperature Sensor Display
4.1.2 XW-111 Digital Input Display
Page 24
XW110/XW111 WiFi™ Users Manual
Xytronix Research & Design, Inc.
