- Page 1 Traveler 1400MM User Manual FINWING TECHNOLOGY WWW FINWINGHOBBY COM PATENT OWNER FINWINGHOBBY inghobby Finwinghobby Like us Like us Facebook Page Facebook Page Subscribe WeiChat...
- Page 2 Please read through the manual before installation and flying This manual as introductions to user on how to build ing this RC plane. Please visit the finwinghobby com official website for more introductions. Warning: 1 This model airplane is not a toy not recommended for children under 14 years old 2.
- Page 3 Setting Forward Backward Hole Black White EPP and EPO Neutralize Elevator control surface first Plane levelly at a platform measure the stabilizer before ready to fly It s inaccurate measurement if building not completely done Center of Rear edge Center of Leading edge "...
- Page 4 Main Wings Building Left and right wing building is exactly the same Length is differently Long spar Short spar Glue to install spars to this wing first Install foam cover Install extension gluing to all contact surface Be sure metal part to be outward WWW finwinghobby com...
- Page 5 Main Wings Building Left and right wing building is exactly the same At last instll plywood and foam cover to extension wing Recommend wrapping tape filming along the joint line WWW finwinghobby com...
- Page 6 Fuselage Gluing Covers and Plywood Step Step 1 gluing Plywood gluing shoulder cover Step # 2 Gluing fuselage tail cover Important Note be sure let glue dry at least 12 hours before installing other parts Step Gluing Motor Mount plywood Be careful I m big hole Be careful I m big hole don t use that small hole one...
- Page 7 Fuselage Tail EPP EPO & Linkage Cut off For Metal linkage Φ2 0 Cut off For servo Horn Φ2 3 For Wing Lock Linkage Φ3 0 Note Black EPP White EPP and White EPO is the same Screw secure the lockers WWW finwinghobby com...
- Page 8 Fuselage EPP EPO Note Black EPP White EPP and White EPO is the same Use hobby knife cut a hole let ESC and Servo wire pass through ESC pass through the hole like this WWW finwinghobby com...
- Page 9 T Tail Tail Boom Gluing Cover and Carbon Strip #Vertical wing Gluing plywood and Carbon Strip Servo Horn Cut off Choose the hole or the second hole won t be big difference recommend try the top hole Now please let glue dry about hours before continuing the next step WWW finwinghobby com...
- Page 10 T Tail T Tail Glue vertical wing to the tail boom Put vertical wing inside immediately after gluing to all the contact surface irremovable dry at least 12 hours & Warning Reminder: Please must have to glue vertical wing to the tail firmly and irremovable dry at least 12 hours. this is the only way to secure stabilizers, there is a horizontal mark line on the vertical wing ,keep it parallel to the tail surface.
-
Page 11: Install Servos
Install servos Fuselage Main Wing Black EPP White EPP and White EPO is the same Enlarge the servo bay to have enough space for the servo arm moving freely WWW finwinghobby com... - Page 12 Install servos Use metal gear servo Black EPP White EPP and White EPO is the same Neutralize servo first Install servo as photos displayed...
- Page 13 Install servos Use Metal mear servo The bottom hole first hole The bottom hole first hole...
- Page 14 Motor ESC Propeller WWW finwinghobby com...
- Page 15 Motor ESC Propeller Black EPP White EPP and White EPO is the same Note Move the heat shrink tubing inside first Solder in parallel WWW finwinghobby com...
- Page 16 T Tail during my later testing I removed the rudder servo basically can t tell any difference without rudder till flying very good without rudder Use the short wire servos for rudder and elevator if you have Finwing Stock V2 ARF Combo 7 0CM WWW finwinghobby com...
- Page 17 Launch Cart Launch Cart is not must to everybody OPtions only Good to enjoying rolling take off and beginner < > not included by kits ARF Φ3 0 Φ4 0 Find out all the parts gluing the metal washers first Front wheel Rear wheel 4 0 Hole...
- Page 18 EVA Cushion What is this for ? Use it as cushion if you found the locker become loose WWW finwinghobby com...
