INSTALLATION
MANUAL
CONTENTS
GENERAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
REFERENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
RENEWAL PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
See the following page for a complete Table of Contents.
NOTES, CAUTIONS AND WARNINGS
Installer should pay particular attention to the words:
NOTE, CAUTION, and WARNING. Notes are intended to
clarify or make the installation easier. Cautions are given
to prevent equipment damage. Warnings are given to
alert installer that personal injury and/or equipment dam-
age may result if installation procedure is not handled
properly.
CAUTION:
READ ALL SAFETY GUIDES BEFORE YOU
BEGIN TO INSTALL YOUR UNIT.
SAVE THIS MANUAL
SPLIT-SYSTEM
CONDENSING UNIT
(AIR COOLED)
MODELS: H5CE150, 180 & 240
(WORLD 50 HZ)
292424-XIM-A-0307
Advertisement
Table of Contents
Related Manuals for York H5CE150A50
Summary of Contents for York H5CE150A50
- Page 1 INSTALLATION SPLIT-SYSTEM CONDENSING UNIT MANUAL (AIR COOLED) MODELS: H5CE150, 180 & 240 CONTENTS (WORLD 50 HZ) GENERAL........3 REFERENCE .
-
Page 2: Table Of Contents
292424-XIM-A-0307 TABLE OF CONTENTS GENERAL ....... . . 3 LIST OF FIGURES REFERENCE . -
Page 3: General
GENERAL RENEWAL PARTS ® These condensing units are designed for outdoor installation Contact your local York parts distribution center for autho- on a roof or at ground level. Every unit is completely piped rized replacement parts for this equipment. and wired at the factory and is shipped ready for immediate INSPECTION installation. -
Page 4: Location
292424-XIM-A-0307 GROUND LEVEL LOCATIONS TABLE 1: UNIT APPLICATION DATA The units must be installed on a one-piece level concrete MODEL 150, 180 & 240 Mbh slab with a minimum thickness of 4 inches (102mm). The length and width should be at least 6 inches (153mm) greater Voltage Variation 380/415-3-50 342 /456 V... -
Page 5: Rigging And Handling
292424-XIM-A-0307 RIGGING AND HANDLING Exercise care when moving the unit. Do not remove any packaging until the unit is near the place of installation. LENGTH OF FORKS MUST BE A MINIMUM OF 54" (1372mm) (when lifting from the compressor Rig the unit by attaching chain or cable slings with hooks to end of the unit) and a MINIMUM OF 42"... -
Page 6: Control Wiring
Motor rotation is counterclockwise when viewing the lead end, which is opposite the shaft end. Holding charge is the amount in the unit as shipped from the factory. Operating refrigerant charge is for the condensing unit and the matching York air handler, but does not include the charge in the interconnecting piping. -
Page 7: Typical Field Wiring Diagram
292424-XIM-A-0307 OUTDOOR INDOOR THERMOSTAT POS1 LIMIT 24/120 VAC OUTPUTS PO 1 PO 2 Y1-OUT Y1-ECON HPS2 LPS2 HPS1 SPLIT SYSTEM CONNECTION LPS1 LOW AMB DIAGRAM FAN OVER FIGURE 1 - TYPICAL FIELD WIRING DIAGRAM TABLE 4: ELECTRICAL DATA Compressor Condenser Fan Motor Unit Unit Power Min. -
Page 8: Unit Dimensions And Clearances
292424-XIM-A-0307 C O M P R E S S O R A N D F A N M O T O R A C C E S S E X T E R N A L P R E S S U R E A I R F A N M O T O R A I R... -
Page 9: Compressor Crankcase Heater
292424-XIM-A-0307 REFRIGERANT PIPING GENERAL GUIDELINES Many service problems can be avoided by taking adequate precautions to provide an internally clean and dry system and by using procedures and materials that conform with estab- lished standards. Use hard drawn copper tubing where no appreciable amount of bending around pipes or other obstructions is necessary. -
Page 10: Service Valves
292424-XIM-A-0307 TABLE 8: CONDENSING UNIT ONLY COOLING CAPACITIES AND POWER REQUIREMENTS Compressor Suction Ambient Temp. Entering Condenser Coil (°C) Model Pressure Saturated (KPA) Temp. (°C) (thermal) (input) (thermal) (input) (thermal) (input) (thermal) (input) (thermal) (input) (thermal) (input) (thermal) (input) 10.8 11.7 12.8 15.4... -
Page 11: Start-Up
292424-XIM-A-0307 SERVI E PORTS IN SHIPPING POSITION OPPER UNIT WALL 2 S REWS OPPER TUBE ORNER POST UNIT WALL SIDE VIEW SERVI E PORTS IN INSTALLED POSITION LOOSEN S REWS OPPER 2 S REWS ORNER SIDE VIEW POST (AS SHIPPED) UNIT PUSH SERVI E WALL... -
Page 12: Initial Start-Up
292424-XIM-A-0307 Is the control circuit transformer set for the proper volt- SAFETY CONTROLS age? The Simplicity™ control board incorporates features to moni - Have the fuses, disconnect switch and power wire been tor safety circuits as well as minimize compressor wear and sized properly? damage. -
Page 13: Continuous Blower
292424-XIM-A-0307 third compressor stage is called for by the thermostat. As When the thermostat calls for the second stage of cooling, such, it’s a “Pump Out On Start Up” design. A normally closed the low-voltage control circuit from “R” to “Y2” is completed. solenoid valve (POS1) is placed in the liquid line. -
Page 14: Unit Control Board
292424-XIM-A-0307 TABLE 9: UNIT CONTROL BOARD FLASH CODES GREEN FLASH CODE DESCRIPTION On Steady This is a Control Failure 1 Flash Not Applicable 2 Flashes Flashing Control waiting ASCD 3 Flashes HPS1 Compressor Lockout 4 Flashes Not Applicable 5 Flashes LPS1 Compressor Lockout 6 Flashes Not Applicable... -
Page 15: Condenser Fan Operation
292424-XIM-A-0307 CONDENSER FAN OPERATION The secondary of every transformer is grounded. Every unit is protected by high and low-pressure con- These condensing units are factory equipped with a fan trols. cycling switch to regulate system head pressure. When out- door ambient conditions are cool, the head pressure of any SECURE OWNER'S APPROVAL air conditioning system may drop too low for optimal perfor- mance. - Page 16 292424-XIM-A-0307 Subject to change without notice. Printed in U.S.A. Copyright © by Unitary Products Group 2007. All rights reserved. Supersedes: 66303/035-17263-002-A-0701 Unitary 5005 Norman Products York Group Drive 73069...
