Table of Contents
1.
INSTRUCTIONS FOR SAFE AND PROPER USE________________ 4
2.
INSTALLATION __________________________________________ 6
3.
DESCRIPTION OF CONTROLS _____________________________ 9
4.
USE OF THE OVEN ______________________________________ 14
5.
AVAILABLE ACCESSORIES _______________________________ 15
6.
COOKING HINTS ________________________________________ 16
7.
CLEANING AND MAINTENANCE ___________________________ 21
8.
EXTRAORDINARY MAINTENANCE _________________________ 24
INSTRUCTIONS FOR THE INSTALLER: these are intended for the
qualified technician who must install the appliance, set it functioning
and carry out an inspection test.
INSTRUCTIONS FOR THE USER: these contain user advice,
description of the commands and the correct procedures for cleaning
and maintenance of the appliance.
Contents
3
Advertisement
Table of Contents
Related Manuals for Smeg FA166-5
Summary of Contents for Smeg FA166-5
-
Page 1: Table Of Contents
INSTRUCTIONS FOR SAFE AND PROPER USE________________ 4 INSTALLATION __________________________________________ 6 DESCRIPTION OF CONTROLS _____________________________ 9 USE OF THE OVEN ______________________________________ 14 AVAILABLE ACCESSORIES _______________________________ 15 COOKING HINTS ________________________________________ 16 CLEANING AND MAINTENANCE ___________________________ 21 EXTRAORDINARY MAINTENANCE _________________________ 24 INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified technician who must install the appliance, set it functioning and carry out an inspection test. -
Page 2: Instructions For Safe And Proper Use
Introduction 1. INSTRUCTIONS FOR SAFE AND PROPER USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE OVEN. WE ADVISE CAREFUL READING OF THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN BEFORE USING THE OVEN. - Page 3 Introduction NEVER PUT INFLAMMABLE OBJECTS IN THE OVEN: THEY COULD BE ACCIDENTALLY LIGHTED AND CAUSE FIRES. DURING USE THE APPLIANCE BECOMES VERY HOT. TAKE CARE NOT TO TOUCH THE HEATING ELEMENTS INSIDE THE OVEN. THE I.D. PLATE WITH TECHNICAL DATA, REGISTRATION NUMBER AND BRAND NAME IS POSITIONED VISIBLY ON THE OVEN DOOR FRAME.
-
Page 4: Installation
Instructions for the user 2. INSTALLATION 2.1 Electrical connection Check that mains voltage and power cable ratings are as per the indications provided on the label attached to the oven door frame. This label must never be removed. It is obligatory for the electrical system to be grounded according to the methods required by safety rules. - Page 5 Instructions for the user 2.2 Mounting the oven The oven is designed for mounting into any piece of furniture as long as heat-resistant. Proceed according to the dimensions shown in Figures 1, 2 and 3. For installing under a work top, follow the dimensions given in Figure 1-3.
- Page 6 Instructions for the user Never use the oven door to lever the oven into place when fitting. Avoid exerting too much pressure on the oven door when open.
-
Page 7: Description Of Controls
Instructions for the user 3. DESCRIPTION OF CONTROLS 3.1 Front control panel All the oven controls are grouped together on the front panel. FUNCTION SWITCH KNOB Rotate the knob in either direction to select desired function from the following: NO FUNCTION SET GRILL ELEMENT IN OPERATION ALTERNATING WITH BOTTOM HEATING... - Page 8 Instructions for the user Cooking temperature is selected by turning the knob clockwise to the desired setting, between 50° and 250°C. Lets you choose manual cooking or the timer with automatic turn-off of the oven when done. For manual control of cooking time, turn the knob anticlockwise to the symbol To set cooking time turn the knob clockwise.
- Page 9 Instructions for the user 3.2.1 Setting the time When the oven is used for the first time, or after a power blackout, the display flashes on and off at regular intervals. Press the seconds to stop the display flashing and start setting of the current time. Press the value modification keys one minute for each time a key is pressed.
- Page 10 Instructions for the user 3.2.3 Programming Cooking duration time: the 2 time. Before setting it, turn the thermostat to the cooking temperature of choice and the function selector knob to any setting. To set the cooking time, proceed as follows: Press the move to position 12 (Fig.
- Page 11 Instructions for the user Cooking start: as well as setting a cooking duration time, the user can also set the cooking start time (up to 12 hours after the current time). To set the cooking start/end time, proceed as follows. Set the cooking duration time as described in the previous point.
-
Page 12: Use Of The Oven
Instructions for the user 4. USE OF THE OVEN 3 operations are required to switch the oven on: 1st: make sure that the timer is turned to “ 2nd: turn the thermostat; 3rd: turn the function selector to any function (the “lamp” setting does not switch on any heating elements). -
Page 13: Available Accessories
Instructions for the user 5. AVAILABLE ACCESSORIES The oven features 4 support positions for plates and racks of different height. Some models do not feature all accessories. Grill: useful for holding cooking vessels. Plate grill: for placing above plate for cooking foods that might drip. -
Page 14: Cooking Hints
Instructions for the user 6. COOKING HINTS In fan-assisted mode preheating should be carried out at 30/40°C above the cooking temperature. This considerably shortens cooking times and reduces power consumption, as well as giving better cooking results. Keep the oven door closed during cooking 6.1 Traditional cooking FUNCTION SWITCH THERMOSTAT SWITCH... - Page 15 Multiple cooking is possible as long as the cooking temperature of the different foods is the same. 6.3 Grill cooking FUNCTION SWITCH THERMOSTAT SWITCH Permits rapid browning of foods. You are advised to place the pan in the highest guide. For short-term cooking of small quantities, place the grid in the fourth guide from the bottom.
- Page 16 Instructions for the user 6.5 Defrosting FUNCTION SWITCH THERMOSTAT SWITCH IN POSITION The flow of air produced by the fan ensures quicker defrosting. The air circulating inside the oven is at room temperature. The advantage of defrosting at room temperature is that it does not alter the taste and appearance of the food.
-
Page 17: Recommended Cooking Table
6.6 Recommended cooking table Cooking times, especially meat, vary according to the thickness and quality of the food and to consumer taste. TRADITIONAL COOKING FIRST COURSES LASAGNE OVEN-BAKED PASTA MEAT ROAST VEAL ROAST BEEF ROAST PORK CHICKEN DUCK GOOSE - TURKEY RABBIT LEG OF LAMB FISH... - Page 18 Instructions for the user FIRST COURSES LASAGNE OVEN-BAKED PASTA CREOLE RICE MEAT ROAST VEAL ROAST PORK ROASTED BEEF FILLET OF BEEF ROAST LAMB ROAST BEEF ROAST CHICKEN ROAST DUCK ROAST TURKEY ROAST RABBIT ROAST HARE ROAST PIGEON FISH PIZZA BREAD TOAST DESSERTS CIAMBELLA...
-
Page 19: Cleaning And Maintenance
Instructions for the user 7. CLEANING AND MAINTENANCE Before performing any operations requiring access to powered parts, switch off the power supply to the machine. 7.1 Cleaning stainless steel To keep stainless steel in good condition it should be cleaned regularly after use. - Page 20 Instructions for the user 7.2 Cleaning of the oven (without self-cleaning panels) For best oven upkeep clean regularly after having allowed to cool. Take out all removable parts. • DO NOT USE A STEAM JET FOR CLEANING THE INSIDE OF THE OVEN.
- Page 21 Instructions for the user 7.2.1 Self-cleaning liners (only on some models) The oven is equipped with continuous self-cleaning enamelled liners. These liners make the oven easier to clean and ensure its efficiency over time. 7.2.2 Using the self-cleaning liners Periodically, to prevent food residues and unpleasant smells from accumulating inside the oven, the appliance should be operated empty at temperatures of not less than 200°C for a time varying from 30 to 60 minutes, in order to allow the self-cleaning liners to oxidise the residues...
-
Page 22: Extraordinary Maintenance
Instructions for the user 8. EXTRAORDINARY MAINTENANCE The oven may require extraordinary maintenance or replacement of parts subject to wear such as seals, bulbs, and so on. The following instructions describe how to carry out these minor maintenance operations. Before any intervention, disconnect the power supply of the device. 8.1 Replacement of light bulb Remove the bulb protector A by turning anticlockwise and change bulb B (in the 8-function model with front glass panel change the halogen bulb... - Page 23 Instructions for the user 8.2 Removing Hold the door on both sides with both hands near hinges A and raise levers B. Lift up the door forming an angle of about 45° and remove. To refit, slide the hinges A in the grooves, drop the door and release levers B. 8.3 Oven door seal To permit thorough cleaning of the oven, the seal may be removed.
- Page 24 914772118/ D...
