- Page 1 SERIES 5A AND 5B VALVE STATUS MONITOR Installation, Operation and Maintenance Manual BRAY.COM THE HIGH PERFORMANCE COMPANY...
-
Page 2: Table Of Contents
Exploded View - S5B........15 FOR MORE INFORMATION ON THIS PRODUCT AND OTHER BRAY PRODUCTS... -
Page 3: Safety Instructions - Definition Of Terms
Series 5A and Series 5B Valve Status Monitor Installation, Operation and Maintenance Manual Read and Follow These Instructions Save These Instructions 1. Safety Instructions - Definition of Terms Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. -
Page 4: Part Numbering System Reference Chart
Series 5A and Series 5B Valve Status Monitor Installation, Operation and Maintenance Manual 4. Part Numbering System Reference Chart Series Housing Product Switch Configuration Trim -126 5X – Designates Housing Size Type 4,4x, IP 66/67, Max 2 switches Type 4,4x, IP 66/67, Max 6 switches H –... -
Page 5: Introduction
5. Introduction 8. Mounting The Bray Series 5A and 5B Valve Status Monitors All Bray Series 5A and 5B VSMs are suitable for (VSM) provide visual and electrical indication of mounting to VDI/VDE 3845 compliant quarter- position of any VDI/VDE 3845 compliant quarter- turn devices using standard mounting hardware. -
Page 6: Fixed Bracket
Installation, Operation and Maintenance Manual 8.2 Fixed Bracket 6. Place lock washers on foot plate mounting bolts. Bray's single piece bracket is used for NAMUR 7. Attach two mounting bracket foot plates to pattern 30 x 80. Installation is as follows: the quarter-turn device. -
Page 7: Cover Removal
• The conduit connections must be properly sealed to maintain the weatherproof integrity of the VSM enclosure. Bray Series 5A and 5B VSMs should be wired as follows: 1. Remove the cover of the VSM. 2. Remove the conduit plug(s). -
Page 8: Reversal Of Visual Indication
NOTICE Ensure that open and close cams are properly set after any modification to visual indication. Bray Series 5A and 5B VSM visual indication can be reversed as follows: 90° 1. Remove all four Indicator dome bolts with lock washers. -
Page 9: Position Adjustment
Series 5A and Series 5B Valve Status Monitor Installation, Operation and Maintenance Manual 12. Position Adjustment Open Travel Indication Adjustment 1. Operate the quarter turn device until it reaches A single lobed or doubled lobed cam is provided the desired open position. for every independent/main switch. -
Page 10: Switch Ratings And Certifications
Series 5A and Series 5B Valve Status Monitor Installation, Operation and Maintenance Manual 13. Switch Ratings and Certifications Most Bray Series 5A and 5B VSMs hold cULus certification under UL file E152613. See lists below for switch ratings and approval status. Mechanical Switches... -
Page 11: 2-Wire Inductive Proximity Switches
Series 5A and Series 5B Valve Status Monitor Installation, Operation and Maintenance Manual 2-Wire Inductive Proximity Switches 2-Wire Proximity Switches 140V N.O. 250V N.O. Switch Option Operating Voltage 20-140V AC 20-250V AC 10-140V DC 10-300V DC Load Current 5-200 mA ≤... -
Page 12: Mounting Kits
Series 5A and Series 5B Valve Status Monitor Installation, Operation and Maintenance Manual 14. Mounting Kits Bracket NAMUR Actuator Actuator VSM / Actuator Std. Part No. Type Pattern Series Size Imperial / Imperial 5B0000-22600534 92 / 93 063 - 128 Metric / Metric 5B0000-22650534 Single Piece 30 x 80... -
Page 13: Troubleshooting Chart
Series 5A and Series 5B Valve Status Monitor Installation, Operation and Maintenance Manual 16. Troubleshooting Chart Problem Possible Cause Solutions Wiring is not connected inside Rewire field wiring and check applied torque to terminal block Cams are set outside of actuator Adjust cam position Signal is not received range... -
Page 14: Exploded Views
Series 5A and Series 5B Valve Status Monitor Installation, Operation and Maintenance Manual 17. Exploded Views Exploded View S5A... -
Page 15: Exploded View - S5B
Series 5A and Series 5B Valve Status Monitor Installation, Operation and Maintenance Manual Exploded View - S5B... - Page 16 Chennai HEADQUARTERS All statements, technical information, and recommendations in this bulletin are for general use only. Consult Bray representatives Bray International, Inc. or factory for the specific requirements and material selection for your intended application. The right to change or modify 13333 Westland East Blvd.
