  • Page 1 Operator’s Manual ® optris Infrared thermometer...
  • Page 2 Optris GmbH Ferdinand-Buisson-Str. 14 D – 13127 Berlin Germany Tel.: +49 30 500 197-0 Fax: +49 30 500 197-10 E-mail: info@optris.de Internet: www.optris.de...

  • Page 3: Table Of Contents

    Table of contents Table of contents General notes ............................7 Intended use ..........................7 Warranty ............................8 Scope of delivery .......................... 9 Maintenance ..........................9 1.4.1 Cleaning ..........................9 Technical Data ..........................11 Default settings ........................... 11 General specifications ........................ 14 Electrical specifications .......................
  • Page 4 Close focus optics ........................21 LED-Functions ..........................23 2.7.1 Automatic aiming support ....................23 2.7.2 Self-diagnostic ........................24 2.7.3 Temperature code indication ....................25 Installation ............................27 Mechanical Installation ....................... 27 3.1.1 Mounting accessories ......................28 3.1.2 Air purge collar ........................30 3.1.3 Other accessories .......................
  • Page 5 Table of contents 3.2.2 Open collector output ......................38 3.2.3 Direct connection to a RS232 on the computer ..............39 Schematic circuit diagrams for maintenance applications ............41 Software CompactConnect ......................45 Installation ........................... 45 Communication settings ......................47 5.2.1 Serial Interface ........................
  • Page 6 Appendix A – Table of emissivity for metals ..................57 Appendix B - Table of emissivity for non-metals .................. 59 Appendix C – Direct connection to a RS232 interface ................61 Appendix D – Smart averaging ....................... 63 Appendix E – CE Conformity ........................65...

  • Page 7: General Notes

    General notes 1 General notes 1.1 Intended use The sensors of the optris CS series are non-contact infrared temperature sensors. They calculate the surface temperature based on the emitted infrared energy of objects [►7 Basics of Infrared Thermometry The CS sensors are sensitive optical systems. Use the thread for mechanical installation only.

  • Page 8: Warranty

    Read the manual carefully before the initial start-up. The producer reserves the right to change the herein described specifications in case of technical advance of the product. ► All accessories can be ordered according to the referred part numbers in brackets [ ].

  • Page 9: Scope Of Delivery

    General notes Scope of delivery • CS incl. connection cable • Mounting nut and mounting bracket (fixed) • Operator‘s manual 1.4 Maintenance Never use cleaning compounds which contain solvents (neither for the lens nor for the housing). 1.4.1 Cleaning Blow off loose particles using clean compressed air. The lens surface can be cleaned with a soft, humid tissue moistened with water or a water based glass cleaner.

  • Page 11: Technical Data

    Technical Data 2 Technical Data 2.1 Default settings Smart Averaging means a dynamic average adaptation at high signal edges. [Activation via software only]. [► Appendix D The default settings can be changed with the optional USB kit (USB adapter cable + software).
  • Page 12 Smart averaging hysteresis 2 °C Ambient temperature source internal (head) Status-LED function Self-diagnostic Input (IN/ OUT/ green) inactive Output (OUT/ yellow) mV output Temperature range 0...350 °C Output voltage 0...3.5 V Thermocouple output Inactive Vcc adjust inactive Signal processing Hold mode: off Calibration Gain 1.000/ Offset 0.0 Failsafe...
  • Page 13 Technical Data For a usage of the CS for online maintenance applications (in electrical cabinets e.g.) the following recommend settings are already included in the factory default setting (but not active): At 3-state output the following settings are default: Pre-alarm difference: 2 °C No alarm level: Pre-alarm level:...

  • Page 14: General Specifications

    Difference mode: activated Alarm level Alarm value (IN/ OUT pin) 40 °C 11 V 45 °C 12 V 50 °C 13 V 55 °C 14 V 60 °C 15 V 65 °C 16 V 70 °C 17 V 75 °C 18 V 80 °C 19 V...
  • Page 15 Technical Data Dimensions 85 mm, M12x1 Weight 58 g Cable length 1 m (Standard), 3 m, 8 m, 15 m Cable diameter 4.3 mm Vibration IEC 60068-2-6 (sinus shape), IEC 60068-2-64 (broad band noise) Shock IEC 60068-2-27 (25 g and 50 g)

  • Page 16: Electrical Specifications

    2.3 Electrical specifications Used Pin Function IN/ OUT Analog 0-5 V or 0-10 V / scalable Alarm output voltage adjustable; N/O or N/C Alarm 3-state alarm output (three voltage level for no alarm, pre-alarm, alarm) Analog programmable open collector output [0-30 V DC/ 50 mA] Temp.
  • Page 17 Technical Data Status LED green LED with programmable functions: alarm indication (threshold independent from alarm outputs) • automatic aiming support • self-diagnostics • temperature code indication • Vcc adjust mode 10 adjustable emissivity and alarm values by variation of supply voltage/ Service mode for analog output Output impedances min.

  • Page 18: Measurement Specifications

    Power supply [white] Analog output/ TxD (5 V)/ Alarm output [yellow] Analog input/ RxD (5 V)/ Open collector output [green] Ground (⊥) [brown] Thermocouple output type K (+) [green] Thermocouple output type K (-) [white] Shield [black] The t/c wires are indicated with an additional cable marker to avoid wrong connections due to the identical cable colours of other wires (white, green).
  • Page 19 Technical Data Temperature coefficient ±0.05 K/ K or ±0.05 %/ K (whichever is greater) Temperature resolution (NETD) 0.1 K Response time 25 ms (95 % Signal/ adjustable to 999 s via Software) Warm-up time 10 min Emissivity/ Gain 0,100...1,100 (adjustable via 0-10 VDC input or software) Transmissivity 0,100...1,000 (adjustable via software) Interface (optional)

  • Page 20: Optical Charts

    2.5 Optical charts • The size of the measuring object and the optical resolution of the infrared thermometer determine the maximum distance between sensing head and measuring object. • In order to prevent measuring errors the object should fill out the field of view of the optics completely.

  • Page 21: Close Focus Optics

    Technical Data Figure 2: Optical chart CS (15:1) with CF-lens (0.8 mm@ 10 mm) 2.6 Close focus optics • If the CF-lens is used, the transmission has to be set to 0.78. To change this value the optional USB-Kit (including software) is necessary. •...
  • Page 22 Figure 3: CF-lens [Order-No.: ACCTCF] Figure 4: Laminar air purge with integrated CF-lens [Order-No.: ACCTAPLCF]...

  • Page 23: Led-Functions

    Technical Data 2.7 LED-Functions The green LED can be programmed for the following functions. For the programming the USB adapter cable incl. software (option) is necessary. The factory default setting for the LED is self-diagnostic. LED Alarm LED lights up if the object temperature exceeds or deceeds an alarm threshold Automatic aiming support Sighting feature for an accurate aiming of the CS to hot or cold objects Self-diagnostic...

  • Page 24: Self-Diagnostic

    2.7.2 Self-diagnostic At a supply voltage (Vcc) ≥ 12 V it takes about 5 minutes until the sensor works in a stable mode. Therefore, after switching on the unit, the LED will show a not stable state for up to 5 minutes. With this function the current status of the sensor will be indicated by different flash modes of the LED.

  • Page 25: Temperature Code Indication

    Technical Data Sensor overheated The internal temperature probes have detected an invalid high internal temperature of the CS. Out of meas. range The object temperature is out of measuring range. Not stable The internal temperature probes have detected an unequally internal temperature of the CS. Alarm fault Current through the switching transistor of the open-collector output is too high.
  • Page 26 Examples 87 °C 8-times long flashing indicates and afterwards 7-times short flashing indicates 31 °C 3-times long flashing indicates and afterwards 1-time short flashing indicates 8 °C 10-times long flashing indicates and afterwards 8-times short flashing indicates 20 °C 2-times long flashing indicates and afterwards 10-times short flashing indicates...

  • Page 27: Installation

    Installation 3 Installation 3.1 Mechanical Installation The CS is equipped with a metric M12x1 thread and can be installed either directly via the sensor thread or with the help of the both hex nuts (standard) to the mounting bracket available. Figure 6: Dimensions CS For an exact aiming of the sensor to an object the LED function ►...

  • Page 28: Mounting Accessories

    3.1.1 Mounting accessories The Mounting fork can be combined with the Mounting bracket [Order No.: ACCTFB] using the M12x1 thread. Figure 7: Mounting bracket, adjustable in one axis [Order No.: ACCTFB]...
  • Page 29 Installation Figure 8: Mounting bolt with M12x1 thread, adjustable in one axis [Order No.: ACCTMB] Figure 9: Mounting fork with M12x1 thread, adjustable in 2 axes [Order No.: ACCTMG]...

  • Page 30: Air Purge Collar

    Figure 10: Mounting bracket, adjustable in two axes [Order No.: ACCTAB] 3.1.2 Air purge collar • Use oil-free, technically clean air only. • The needed amount of air (approx. 2...10 l/ min.) depends on the application and the installation conditions on-site. The lens must be kept clean at all times from dust, smoke, fumes and other contaminants in order to avoid reading errors.
  • Page 31 Installation Figure 11: Standard air purge collar; fits to the mounting bracket; hose connection: 3x5 mm [Order No.: ACCSAP] Figure 12: Laminar air purge collar – the side air outlet prevents a cooling down of the object in short distances; hose connection: 3x5 mm [Order No.: ACCTAPL]...

  • Page 32: Other Accessories

    Figure 13: A combination of the laminar air purge collar with the bottom section of the mounting fork allows an adjustment in two axes. [Order No.: ACCTAPL+ACCTMG] 3.1.3 Other accessories If the protective window is used, the transmission has to be set to 0.83. To change this value the optional USB-Kit (including CompactConnect software) is necessary.
  • Page 33 Installation Figure 14: Right angle mirror enables measurement with 90° angle [Order No.: ACCTRAM] Figure 15: Protective window same mechanical size as CF lens [Order No.: ACCTPW]...

  • Page 34: Tilt Assembly

    Figure 16: USB adapter cable incl. terminal block and software CD [Order No.: ACCSUSBK] 3.1.4 Tilt assembly With this mounting accessory a fine adjustment of the CS with an off-axis angle +/- 6.5° is possible. Figure 17: Tilt assembly [Order No.: ACCTTAS]...

  • Page 35: Electrical Installation

    Installation 3.2 Electrical Installation Use a separate, stabilized power supply unit with an output voltage in the range of 5– 30 VDC which can supply 100 mA. The residual ripple should be max 200 mV. • Use shielded cables only. The sensor shield has to be grounded. •...
  • Page 36 Figure 18: Analog device (mV output at OUT pin) Analog device (Thermocouple typ K at OUT t/c K pins) The output impedance must be ≥ 20 Ω. Figure 19: Analog device (Thermocouple typ K at OUT t/c K pins)

  • Page 37: Digital Communication

    Installation You can choose between an mV output (0-5 or 0-10 V; scalable via software) and a thermocouple output type K. Therefor the optional software is needed. The factory default setting is mV output. ► Factory default settings The thermocouple output supplies a voltage according to the t/c characteristic curve type K. If you want to extend this output you have to use a suitable thermocouple extension cable (NiCr-Ni).

  • Page 38: Open Collector Output

    The sensor is offering two ways of digital communication: • bidirectional communication (sending and receiving data) • unidirectional communication (burst mode – the sensor is sending data only) Figure 21: Digital communication 3.2.2 Open collector output In case of long lines there is a drop voltage at the ground wire and the mV-output is distorted.

  • Page 39: Direct Connection To A Rs232 On The Computer

    Installation Figure 22: Open collector output as additional alarm output The open collector output is an additional alarm output on the CS and can control an external relay e.g. In addition the analogue output can be used simultaneously. 3.2.3 Direct connection to a RS232 on the computer For a bidirectional RS232 connection of the sensor the following interface circuit can be used: MAX3381E (manufacturer: Maxim) ►...

  • Page 41: Schematic Circuit Diagrams For Maintenance Applications

    Prinzipschaltbilder 4 Schematic circuit diagrams for maintenance applications Figure 23: Open collector output for direct 24V DC signal lamp control...
  • Page 42 Figure 24: Common power supply voltage change to adjust simultaneously alarm levels and emissivity values [Vcc adjust mode]...
  • Page 43 Prinzipschaltbilder Figure 25: Simple common alarm and pre-alarm generation...

  • Page 45: Software Compactconnect

    Software CompactConnect 5 Software CompactConnect Minimum system requirements: • Windows Vista, Windows 7, Windows 8 • USB interface • Hard disc with at least 30 MByte of free space • At least 128 MByte RAM • CD-ROM drive A detailed description is provided in the software manual on the software CD. 5.1 Installation 1.
  • Page 46 The installation wizard will place a launch icon on the desktop and in the start menu: Start\Programs\CompactConnect To uninstall the software from your system use the uninstall icon in the start menu. Figure 26: Software CompactConnect...

  • Page 47: Communication Settings

    Software CompactConnect Main functions: • Graphic display for temperature trends and automatic data logging for analysis and documentation • Complete sensor setup and remote controlling • Adjustment of signal processing functions • Programming of outputs and functional inputs 5.2 Communication settings For further information see protocol and command description on the software CD CompactConnect in the directory: \Commands.

  • Page 48: Serial Interface

    5.2.1 Serial Interface Baud rate: 9,6...115,2 kBaud (adjustable on the unit or via software) Data bits: Parity: none Stop bits: Flow control 5.2.2 Protocol All sensors of the CTlaser series are using a binary protocol. Alternatively they can be switched to an ASCII protocol.

  • Page 49: Digital Command Set

    Digital command set Digital command set Commands CS/ CSmicro/ CX Decimal Binary/ ASCII Command Data Answer Result Unit 0x01 binary READ Temp - Target byte1 byte2 = (byte1 x 256 + byte2 - 1000) / 10 °C 0x02 binary READ Temp - Head byte1 byte2 = (byte1 x 256 + byte2 - 1000) / 10 °C...

  • Page 51: Basics Of Infrared Thermometry

    Basics of Infrared Thermometry Basics of Infrared Thermometry Depending on the temperature each object emits a certain amount of infrared radiation. A change in the temperature of the object is accompanied by a change in the intensity of the radiation. For the measurement of “thermal radiation”...
  • Page 52 The specifications of the lens decisively determine the optical path of the infrared thermometer, which is characterized by the ratio Distance to Spot size. The spectral filter selects the wavelength range, which is relevant for the temperature measurement. The detector in cooperation with the processing electronics transforms the emitted infrared radiation into electrical signals.

  • Page 53: Emissivity

    Emissivity 8 Emissivity 8.1 Definition The intensity of infrared radiation, which is emitted by each body, depends on the temperature as well as on the radiation features of the surface material of the measuring object. The emissivity (ε – Epsilon) is used as a material constant factor to describe the ability of the body to emit infrared energy.
  • Page 54 ► If you monitor temperatures of up to 380°C you may place a special plastic sticker (emissivity dots – Order No.: ACLSED) onto the measuring object, which covers it completely. 1. Set the emissivity to 0.95 and take the temperature of the sticker. 2.

  • Page 55: Characteristic Emissivity

    Emissivity 8.3 Characteristic emissivity In case none of the methods mentioned above help to determine the emissivity you may use the emissivity table ► Appendix A and Appendix B. These are average values, only. The actual emissivity of a material depends on the following factors: •...

  • Page 57: Appendix A - Table Of Emissivity For Metals

    Emissivity metals Appendix A – Table of emissivity for metals typical typical Material Material Emissivity Emissivity Aluminium non oxidized 0,02-0,1 Lead roughened polished 0,02-0,1 oxidized 0,2-0,6 roughened 0,1-0,3 Magnesium 0,02-0,1 oxidized 0,2-0,4 Mercury 0,05-0,15 Brass polished 0,01-0,05 Molybdenum non oxidized roughened oxidized 0,2-0,6...

  • Page 59: Appendix B - Table Of Emissivity For Non-Metals

    Emissivity non-metals Appendix B - Table of emissivity for non-metals Material typical Emissivity Spectral response 1,0 µm 2,2 µm 5,1 µm 8-14 µm Asbestos 0,95 Asphalt 0,95 0,95 Basalt Carbon non oxidized 0,8-0,9 0,8-0,9 0,8-0,9 graphite 0,8-0,9 0,7-0,9 0,7-0,8 Carborundum 0,95 Ceramic 0,8-0,95...

  • Page 61: Appendix C - Direct Connection To A Rs232 Interface

    RS232 Interface Appendix A – Direct connection to a RS232 interface For a bidirectional RS232 connection of the sensor we recommend the interface circuit from Maxim, e.g. MAX3381E.
  • Page 62 Model CSv1/ CSMv1 CSv2 CSMv2 CSM2W/ CX UART voltage (RxD) 3,3 V 3,3 V 3,3 V UART voltage (TxD) 2,5 V 2,5 V 2,5 V Previous sensor versions: CS/ version 1 (→ 12/2010) CSv1 CSmicro/ version 1 (→ 09/2011) CSMv1 CS connections: TxD (yellow) an T1IN RxD (green) an R1OUT...

  • Page 63: Appendix D - Smart Averaging

    Smart averaging Appendix B – Smart averaging The average function is generally used to smoothen the output signal. With the adjustable parameter time this function can be optimal adjusted to the respective application. One disadvantage of the average function is that fast temperature peaks which are caused by dynamic events are subjected to the same averaging time.

  • Page 65: Appendix E - Ce Conformity

    CE Conformity Appendix E – CE Conformity...
