1080p60 Video Server ANT-35000A
H.264 Encoder
User Manual
Support can be found at :

https://antrica.freshdesk.com/support/home
!
ver.3. 0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANT-35000A and is the answer not in the manual?

Questions and answers

Related Manuals for Antrica ANT-35000A

Summary of Contents for Antrica ANT-35000A

  • Page 1
 1080p60 Video Server ANT-35000A H.264 Encoder User Manual ver.3. 0 Support can be found at :
 https://antrica.freshdesk.com/support/home...
  • Page 2 ANT-35000A User Manual Safety Precaution We appreciate your purchasing video server. Before installing the product, please read the following with care ◇ Make sure to turn off the power before installing video server. ◇ Do not install under the direct sunlight or in dusty areas.

  • Page 3: Table Of Contents

    ANT-35000A User Manual Table of Content 1. Introduction ........................... About this manual ........................ Features ..........................Product and Accessories ...................... System Connections ......................2. Installation ........................... 3. System Operation ......................... ● Remote Video Monitoring ....................re-initialisation of IP Address ....................1. Remote Configuration ....................

  • Page 4: Introduction

    ANT-35000A User Manual 1. Introduction About this manual This User Manual provides information on installation setup and operation of the video server, as well as troubleshooting tips. . Features Video server is a video and audio transmission system that provides broadcast quality audio and video, based on an IP network through LAN and ADSL/VDSL.

  • Page 5: Product And Accessories

    ANT-35000A User Manual Connection to internal or external USB storage for remote access, recording and playback User Interface Diagnose and upgrade through dedicated program called True Manager System configuration using Internet Explorer High Reliability Reliable embedded system System recovery by dual watch-dog functions Product and Accessories
...
  • Page 6 ANT-35000A User Manual ● Part Names and Functions Front View Parts Function ① Display system status Audio Input Audio Input ② ③ Audio Output Audio Output ④ HDMI Input HDMI Video & Audio Input ⑤ HDMI Output HDMI Video & Audio Output USB Port USB 2.0...
  • Page 7 ANT-35000A User Manual Rear View Part Function Power DC +12V power input RS-422/485 Serial port for PTZ control and etc ② ③ RS-232 Serial port for PTZ control and etc ④ Composite In/ Output Composite Video Input / Output ⑤...

  • Page 8: System Connections

    ANT-35000A User Manual System Connections Video server operates as one mode; Encoder. Video server systems can be connected in either 1-to-1 fashion where one encoder is connected one decoder or 1-to-many fashion where one encoder connected to many decoders. Following chart shows data status of video, audio and serial data.
  • Page 9 ANT-35000A User Manual In this configuration, a site can be monitored from many remote center locations. Maximum connections would be limited by the network bandwidth. Functionally, the VMS (Video Management System) software can replace the decoder. Multicast Mode In the network supporting multicast mode, if Multicast is setup as a system protocol, you can use bandwidth efficiently regardless of the number of decoders.

  • Page 10: Installation

    ANT-35000A User Manual 2. Installation Connecting Video PC Encoder System Connect PC video output line to the encoder (video server) video input port. Connecting with Megapixel Camera Connect a camera which supports HDMI or 3G/HD-SDI output to the HDMI or 3G/HD-SDI Input port of video server accordingly.
  • Page 11 ANT-35000A User Manual Software provided in the support site (Cloud) called True Manager allows you to check the IP address and other network details of the server. Please refer to the True Manager manual for instructions on how to find the IP address of the server and if required changing it.
  • Page 12 ANT-35000A User Manual Description of LED System status can be monitored with LED display State Description Power off Power on Green Normally operating blinking STATUS System failure: Needs diagnostics No connection to remote system Green Connected to a remote system...

  • Page 13: System Operation

    ANT-35000A User Manual 3. System Operation ●Remote Video Monitoring There are two ways to monitor video when the centre system and server are connected. In order for a proper operation, an IP address must be set accordingly. Please refer to True Manager Manual for further details.
...
  • Page 14 ANT-35000A User Manual ◆ Video Select Select the Video stream to be viewed : Primary, Secondary, tertiary or quartic streaming. This camera is capable of Quad streaming; primary streaming and secondary streaming Video will be displayed according to the resolution set on video configuration. If dual streaming (“Use
...
  • Page 15 ANT-35000A User Manual Set preset position and move to the specific preset position. Goto Move to the selected preset entry if the preset entry is set. Set the current position to the selected preset entry. Clear Delete the selected preset entry.

  • Page 16: Re-Initialisation Of Ip Address

    ANT-35000A User Manual Video Monitoring with Decoder System Once camera’s IP address is set in the remote IP address section of the decoder, the decoder system will connect to camera and start receiving the video images. Normally, a monitor connected to the decoder...

  • Page 17: Remote Configuration

    ANT-35000A User Manual 4. Remote Configuration ●Using the Web Browser Remote setting is available by using web browser. Enter IP address of camera and then a live view screen appears as below. Press Setup button located in the upper right area of the monitoring screen to go to the server setup.

  • Page 18: Video & Audio

    ANT-35000A User Manual ●Video & Audio Information The information provides current information regarding the settings for video and Audio 18 68 Page 7 of 7...
  • Page 19 ANT-35000A User Manual Encode Performance Calculation Shows the performance usage rate according to the value set at ‘Encode’ mode underneath. Input Format Choose the input format from the list. Video Input Auto Detect Choose the Auto Detect mode. If it is Full Auto Mode, it will be displayed automatically.
  • Page 20 ANT-35000A User Manual Resolution Select video encoding solution. Scaling option is used when encoding resolution is different from input resolution. Without Scaling option, input video will be cut according to encoding resolution. On the other hand, if Scaling is selected, input video will be adjusted according to encoding resolution.
  • Page 21 ANT-35000A User Manual H.264 Profile Select H.264 Profile : High Profile or Baseline Profile The standard defines various sets of capabilities which are referred to as profiles, targeting specific classes of application. High Profile The Primary profile for broadcast and disc storage applications, particularly for high-definition television application.
  • Page 22 ANT-35000A User Manual Audio Audio Source Select the audio source: Embedded or Analog stereo Algorithm Select the audio algorithm: G.711 or AAC G.711 and AAC from client to server direction are supported. Thus, bidirectional audio communication is supported. Samplerate The sampling rate defines the number of samples per unit of time taken from a continuous signal to make a discrete signal.

  • Page 23: Image

    ANT-35000A User Manual Output Output Format Select the format of output when Enable Preview is selected. ●Image 23 68 Page 7 of 7...
  • Page 24 ANT-35000A User Manual Composite It works when it connects only composite input source l Brightness Controls input video brightness by selecting values between 0 and 255. l Contrast Controls input video contrast by selecting values between 0 and 255. l Hue...
  • Page 25 ANT-35000A User Manual 3DNR Mode: This camera performs 3D noise reduction by estimating the noise level of current and previous input video. It effectively suppresses artifacts such as ghost-tail, etc., by using the motion adaptive method which reduces noise to a lesser extent in motion area where...

  • Page 26: Network

    ANT-35000A User Manual ●Network IP & Port Local Select the IP mode: Fixed IP or DHCP Depending on the selected mode, further configuration items comes as follows, IP Mode Selection Description Local IP Fixed IP address Fixed IP LocalGateway Gateway IP address...
  • Page 27 ANT-35000A User Manual Local Subnet Subnet mask DHCP Please ask IP address information from ISP provider or network manager. Obtain DNS server address automatically ➢ Get DNS server address automatically when IP mode is DHCP. Use the following DNS server address ➢...
  • Page 28 ANT-35000A User Manual Discovery UPNP By the setting UPNP to ON, it allows the discovery by the clients according to UPNP (Universal Plug and Play) protocol. Zeroconf By setting Zerodonf to ON, it allows the discovery by the clients according to zeroconf protocol.
  • Page 29 ANT-35000A User Manual One-way This IP camera provides two kinds of one-way (unidirectional) streaming based on UTP to clients; RTSP and MPEG-TS. Both are a kind of broadcasting where traffic from clients to a server is not generated at all.
  • Page 30 ANT-35000A User Manual MPEG-TS is a standard format for transmission and storage of audio, video, and data,[7] and is used in broadcast systems such as DVB and ATSC. Transport Stream is specified in MPEG-2 Part 1, Systems (formally known as ISO/IEC standard 13818-1 or ITU-T Rec. H.222.0). Transport stream specifies a container format encapsulating packetized elementary streams, with error correction and stream synchronization features for maintaining transmission integrity when the signal is degraded.
  • Page 31 ANT-35000A User Manual SNMP Trap Destination IP Set the SNMP Trap Destination IP. SNMP Trap Destination Port (0, 162, 1025 ~ 65535) Set the SNMP Trap Destination Port. SNMP is not used by setting 0 value. Simple Network Management Protocol (SNMP) is used by network management systems to communicate with network elements.
  • Page 32 ANT-35000A User Manual DynDNS Dyn DNS service is used in this mode. Refer to www.dyndns.org for details. ID, Password and Domain name are needed when DYN DNS is set. Dynamic DNS is a method, protocol, or network service that provides the capability for a networked...
  • Page 33 ANT-35000A User Manual IP filtering IP filtering is simply a mechanism that decides which types of IP datagrams will be processed normally and which will be discarded. 33 68 Page 7 of 7...
  • Page 34 ANT-35000A User Manual E-mail E-mail Specify the information to send event information, when E-mail is selected as an event action. Server Address ➢ Enter an address of mail (SMTP) server Port ➢ Specify a port for SMTP operation (Port 25 is the default port in SMTP operation. If a different port is configured in the SMTP server, this ports needs to be changed accordingly.)
  • Page 35 ANT-35000A User Manual E-mail Test ➢ E-mail sending can be tested with this button. Please note that configured settings should be saved first by pressing Apply button before using E-mail Test function. One of the following messages will come as a result of the test.
  • Page 36 ANT-35000A User Manual Specify the information to upload event information, when FTP is selected as an event action. Server Address ➢ Enter an address of an RTP server to receive video files Port ➢ Specify a port for FTP operation (port 21 is the default port in FTP operation. If a different port is configured in the FTP server, this port needs to be changed accordingly.)
  • Page 37 ANT-35000A User Manual %ss : second %EVENT : event type (Sensor1, Motion, ...) %ADDR : address of the server (Domain name when DDNS is used. Otherwise IP address) “.avi” or “.jpg” will be added automatically at the end of the filename depending on the type of video file.
  • Page 38 ANT-35000A User Manual Upload Duration ➢ Specify recording duration of a video clip to be transmitted. (max 300 sec.) Upload Interval ➢ Specify transmission interval. (max 3600 sec.) Upload duration is not included in upload interval. For example, if upload interval is 60 sec. and upload duration is 20 sec, a video clip for 20 sec is transmitted every 80 sec.
  • Page 39 ANT-35000A User Manual Select the interval of captured frame. SSL Enable ➢ SSL-VPN function will be enabled User ID ➢ User ID on VPN Client Password ➢ User Password on VPN client VPN IP Address ➢ Set IP address on VPN VPN Port ➢...
  • Page 40 ANT-35000A User Manual Connecting Client IP Addresses that are currently connected to system are listed. (1) Indicates 40 68 Page 7 of 7...

  • Page 41: Event

    ANT-35000A User Manual ● Event Notification Local When a decoder instead of a PC client is connected to an IP camera, one system becomes a Local system and the other a Remote system (Generally a system which is being used by the user is called as Local system).
  • Page 42 ANT-35000A User Manual Sensor1 / Sensor2 Configure the actions when the sensor is activated. Multiple actions can be set for a single event. On Video Loss Configure the actions when video input signal is lost. Multiple actions can be set for a single event.
  • Page 43 ANT-35000A User Manual Sensor Sensor Type There are two sensor input ports on video server. Each of the sensor ports can be configured to the followings; Function Operation Not used NO (Normally Open) The port is normally open and activated when closed.
  • Page 44 ANT-35000A User Manual Alarm Set the duration of alarm or beep activation in case of an event. If it is set to continuous, it will be in active state until the operator resets it manually. 44 68 Page 7 of 7...

  • Page 45: Record

    ANT-35000A User Manual ● Record General Use record Off : Recording function will not be used when “OFF” is selected. ➢ Use Disk : Use disk function will follow the setting of Schedule table which set as record off as a ➢...
  • Page 46 ANT-35000A User Manual FTP Base Directory Specify the name of the directory to be created in the FTP server. It is valid only when Use Record is set to Use FTP. Checking status of recording Recording status can be checked on the main view page.
  • Page 47 ANT-35000A User Manual Schedule Event Type Three recording modes are supported: Continuous, Event, Disconnect. In case of Event recording, event types can be selected among several events. Selected event type is used for configuring the schedule table. Up to 4 event types can be configured and each event type can be a combination of sensor, video loss and motion event.
  • Page 48 ANT-35000A User Manual Disk Information SD memory can be used, and at least 1GB size is recommended. Either EXT3 or FAT32 file system can be used. A disk with either EXT3 or FAT32 file system can be read in Linux PC. However, only disk with FAT32 file system can be read in Windows PC.
  • Page 49 ANT-35000A User Manual Search Page Recorded video and audio data can be saved as AVI format in the disk. In general, one AVI file is created for an event in case of event-based recording. However, it is possible that recorded data by serious of events happening continuously can be merged to a single AVI file depending on pre/post event time setting.
  • Page 50 ANT-35000A User Manual Playback 1. Selecting an AVI file will show a dialog for opening or saving the fil 2. Pressing Save button, the file will be stored in the PC. The AVI file can be played with Windows Media Player.

  • Page 51: Device

    ANT-35000A User Manual ● Device Information The information provides current serial communication status Serial Serial Protocol : There are two serial ports, RS-232, RS-422/485 in video server. Select RS-422 or RS-485 in RS-422/485 port Serial Port Configuration: The serial ports can be configured as follows.

  • Page 52: Ptz

    ANT-35000A User Manual ● PTZ General PTZ Type ➢ Select the type of PTZ camera or receiver. PTZ ID ➢ Since it is possible to control multiple PTZ cameras or receivers over a single control line, each camera or receiver will be assigned with unique ID. Enter PTZ ID of a camera or receiver for control.
  • Page 53 ANT-35000A User Manual Preset Max 128 preset positions can be defined. Select Preset Number: Select an entry in the list to be assigned to current camera position. Focus Mode: Select the focus mode after preset Goto is executed. Do not change: current focus mode is not changed.
  • Page 54 ANT-35000A User Manual Group This function is that the camera memorizes the combination of Presets, Pattern and/or Swings sequentially and runs Presets, Pattern and/or Swings repetitively on activation. Max 8 groups are programmable. Each group can have max 20 actions which are the combinations of Preset, Pattern and Swing.
  • Page 55 ANT-35000A User Manual 1. Select one of the entries of Group 2. Press Modify Group button. The following window will appear. 3. Set Action, Dwell Time and Option and click Enable squares 4. Press Apply button and the Group can be used on the Live View Page...

  • Page 56: User

    ANT-35000A User Manual ON: If pattern, swing or group was running before rebooting, the action is resumed. ➢ If it was in stopped state, it moves to the last position. Off: Moves to the initial position after rebooting. ➢ Auto Parking Auto parking is a function to return to the previous preset position or to resume operation such as Pattern, Swing or Group when a specified time expires after user stopped PTZ control.
  • Page 57 ANT-35000A User Manual Enter User ID and password (Up to 15 characters) and select Privilege Level. Delete User Select the User to be deleted and press Delete button. Change Password Press Modify Password button. The following window will appear. Enter the current password and then set a new password.

  • Page 58: System

    ANT-35000A User Manual Login Policy Login Policy Skip Login provides for convenient access to the server when authentication is not required. When Skip Login is set to Enable, login step is skipped. The privilege level after login in this way is determined by the setting of Privilege Level After Login Skipped.
  • Page 59 ANT-35000A User Manual Mac Address ➢ Display the MAC address of the camera. In case the camera is registered at DDNS server, the MAC address is used in DDNS registration. Set Current Time ➢ Display Current date and time Current Domain ➢...
  • Page 60 ANT-35000A User Manual Maintenance - Firmware Version : Display the current firmware version ➢ Upgrade: To upgrade firmware; 1. Press Browse button to select a firmware file from PC. 2. Press Firmware Upgrade button to start upgrading. 3. A message for showing status (downloading / upgrading) will be displayed.
  • Page 61 ANT-35000A User Manual - Reboot Reboot the camera ➢ Do not press the Reboot button unless the server needs a reboot. - Factory Reset All settings including user accounts and logs are cleared - Factory Reset Except Network Settings All settings except for current network settings are changed to the default values.
  • Page 62 ANT-35000A User Manual Automatically synchronized with NTP server ➢ Synchronize the camera time with an NTP server using NTP (network time protocol). Name of the NTP server should be registered on NTP server Name. The Network Time Protocol (NTP) is a protocol for synchronizing the clocks of computer systems over packet-switched, variable-latency data networks.
  • Page 63 ANT-35000A User Manual Information Display System ID and/or server time can be display over the video window in Internet Explorer. Each item can be turn on or off separately, and position also can be configured. This information is displayed after the video is decompressed.
  • Page 64 ANT-35000A User Manual Language Language Select the language to be used for web-based configuration. 64 68 Page 7 of 7...
  • Page 65 ANT-35000A User Manual Appendix A : Sensor and Alarm Port Sensor Port ● Terminal Type Voltage Rating: 150VAC Current Rating : 2A Color : Red ● Sensor Signal Input Type NO Contact Signals Connection to External Device ● 65 68...
  • Page 66 ANT-35000A User Manual Alarm Port ● Terminal Type Voltage Rating: 150VAC Current Rating : 2A ● Relay Type Contact Rating : 1A 30VDC Switching Power : Max 30W 62.5VA Switching Voltage : Max 60VDC ● Alarm Signal Output Type NO/NC Contact Signals Connection to External Device ●...
  • Page 67 ANT-35000A User Manual Appendix B : Serial Port RS-232 Port Port Type ● 3 PIN Pin Arrangement Pin Description Pin NO Pin Name Description RS232 TX(Transmit) RS232 RX(Receive) Ground RS-422/485 Port ● Port Type 4 PIN Pin Diagram Pin Description Pin No.
  • Page 68 ANT-35000A User Manual 68 68 Page 7 of 7...
