Rolls RM316 Quick Start Manual

REMOTE
REMOTE
OUTPUT
WIPER
-
+
+15V GND
+15V
CHANNEL 2
The remote volume section on the rear panel of the RM316 allows the installer to place remote vol-
ume controls in any or all of the zones connected to the RM316. Wiring information is silk screened
above each remote volume connector.
Q: Does the remote volume wire carry audio signal?
A: No, the remote volume wire only carries a DC control voltage that varies according to the posi-
tion of the remote volume pot (10-100K Ohm linear potentiometer recommended). Use of the remote
volume feature will not introduce any noise or cause any signal loss.
Q: What is the maximum length that I can run a remote volume wire?
A: Wire size can affect the maximum length. You can run up to 200 feet reliably, and with high quality
wire up to 1000 feet.
Below is a diagram of how to connect the pots to the remote volume Phoenix connectors.
REMOTE PAD: 5 pin Phoenix connector for connection to a remote potentiometer for remote volume
control. A 100K Ohm potentiometer is recommended (others will work).
+15: Connection to potentiometer.
WIPER: Connection to potentiometers wiper (middle pin).
COMM: Common Ground for connection to pots.
As a note: If the potentiometer pad is working opposite of what you intended just reverse the wires
going to that potentiometer.
1/4" BAL:
OUTPUT
TIP +
- -
WIPER RING
+
SLEVE GND
GND
MUSIC ON HOLD OUT (SOURCE 1)
CHANNEL 1
REMOTE OUTPUT
-
WIPER
+
+15V GND

Connection to output

ROLLS CORPORATION
SALT LAKE CITY, UTAH
3
1/4" UN BAL:
TIP +
RING NOT USED
SLEVE GND
MIC 1
1
MADE IN USA
www.rolls.com
XLR:
PIN 1 GND
PIN 2 +
PIN 3 -
POWER

SPECIFICATIONS

Input Impedance:
Output Impedance:
Max Input Level:
Phantom Power:
Input Connectors:
Outputs:
Max Gain:
S/N Ratio:
THD:
IMD (SMPTE):
CMRR:
Frequency Response:
Power Adapter:
Weight:
Size:
01/19
2 1
RM316
3 Zone Mixer
MIC 2 MIC 3 SOURCE 1
ZONE ZONE ZONE ZONE
2 3 1 2 3 1 2 3 1 2 3
3 2
1/4" BAL: 1/4" UN BAL:
REMOTE OUTPUT REMOTE REMOTE OUTPUT
TIP + TIP +
- OUTPUT - -
WIPER + WIPER - WIPER + RING RING NOT USED
+
+15V GND +15V GND +15V GND SLEVE GND SLEVE GND
CHANNEL 3 CHANNEL 2 MUSIC ON HOLD OUT (SOURCE 1)
CHANNEL 1
Mic:
Source:
OFF=UP
ON=DOWN
TALK OVER ZONE ASSIGNMENT
1 2 3
3
PHANTOM POWER
MASTER VOLUME
SOURCE 2 SOURCE 3
ZONE 1 ZONE 2 ZONE 3
ZONE ZONE
1 2 3 1 2 3 RM316
3 Zone Mixer
1/8"
IN
1 MIC 3 MIC 2
MIC 1
OFF=UP
ON=DOWN
TALK OVER ZONE ASSIGNMENT
1 2 3
MIC/LINE MIC/LINE
MIC/LINE
INPUT LEVEL MIC
3
LINE
PHANTOM POWER
10K Ohms balanced Line
600 Ohms balanced Mic
10K Ohms unbalanced RCA
50 Ohms balanced
-30 dB
+22 dB
+15 Volts DC
XLR and RCA
3 ea. Phoenix connector
60 dB mic
30 dB line
>75 dB
< .3%
< .3%
60 dB
20Hz to 20kHz +/- 0 dB
15VDC
7 lbs (3KG)
19" x 1.75" x 6.5"
(48cm x 4.5cm x 17cm)

Quick Start Guide

MIC/LI
