INTRODUCTION
The MX22s is a two-channel mixer for mixing a 1/8" line
signal such as a wireless microphone, and a stereo RCA
signal such as a CD player. The MX22s has enough output
to drive a power amplifi er directly and is ideal for audio/video
applications.
WARRANTY
For complete information on the Rolls 1 Year Warranty, and
to register this product, see our website at www.rolls.com.
DESCRIPTION
CH 1 Input: 1/8" stereo jack for receiving line or instrument
level signals.
CH 2 Input: Stereo RCA input for receiving line level signals.
These signals are mixed to mono.
Line 1 Volume: Controls the level of the signal from Channel
1.
Line 2 Volume: Controls the level of the signal from Channel
2.
Line Outputs: Dual mono RCA and 1/8" jacks for connection
to a line input device such as a mixer.
Power Input: For connection to the power supply Rolls
PS27.
STEREO/MONO SWITCH: For switching the MX22s from
stereo in/out to mono in/out. Units are shipped from the fac-
tory in stereo mode.
SCHEMATIC
4
6
4
1
3
2
8
3
1
6
4
5
and
inch
1/8
a
mix
MIXER
MiniMix
MiniMix
MiniMix
MX22s 2 Channel
Stereo/Mono Mixer
- Mixes 1/8" line level signals with stereo
RCA signals
- Individual controls for each signal
- AC adapter included
The MX22s mixes a 1/8" line signal such as a wireless mi-
crophone or other line level signal, with a stereo RCA signal
like a CD or cassette player. The unit has enough output to
drive a power amplifi er directly and is ideal for audio visual
applications as well.
SPECIFICATIONS
CH1 Max Gain:
CH2 Max Gain:
CH1 Input Impedance:
CH2 Input Impedance:
Output Impedance:
Power:
Size:
Weight:
Rolls Corporation
Salt Lake City, UT
02/10
together.
signal
RCA
to
need
you
anywhere
Broadcast
Install
Studio
MINI
MX22s
MX22s
MX22s
MX22s
32 dB
20 dB
10K Ohms
20K Ohms
50 Ohms
Rolls PS27 @ 12 VDC 200mA
2.75" x 2.35" x 1.5"
(7 x 6 x 3.8 cm)
1lb (.45Kg)
...
-
-
-
