Microsensor Earth1006 Operation Manual page 7

Wake-up mode: magnetic activation/timing/alarm wake-up
Sampling interval: 1,5,10,30,60,360,720,1440 minutes optional,
alarms are given at the intervals, and maximum 3 times warning can
be sent over each interval to ensure longer battery life.
Transmission interval: 1,5,10,30,60,360,720,1440 minutes optional
Image interval: 30,60,720,1440 minutes optional
Upload information: sensor data, battery information, network status,
self-check information
Data storage
Local storage: Flash 4MB (more than 200,000 history data)
Configuration
Configuration mode: local/remote configuration
Display
Segment LCD, with backlight
Environmental condition
Working temperature: -20℃~70℃
Storage temperature: -40℃~85℃
Others
Protection: IP68 (work normally for 72 hours at 1m below the water)
Housing material: PA6+30%GF
Installation method: wall-mounting, hoop-mounting
Outline dimension: 147×262.5×105.5mm
3
