  • Page 1 INSTRUCTION MANUAL...
  • Page 2 This user-friendly manual will provide answers to all your questions about use of the dishwasher. For any other information about use and maintenance of the dishwasher, read the enclosed manual carefully. USER INSTRUCTIONS: useful information is provided for the use of the...

  • Page 3: Description Of The Controls

    User instructions 1. Description of the controls 1.1 Front panel All the dishwasher controls are grouped on the front panel. ON/OFF BUTTON SELECTION PROGRAM BUTTONS (P1…P5) 3/1 OPTION BUTTON DELAY PROGRAM BUTTON START/STOP BUTTON POWER ON LIGHT PROGRAM PHASE INDICATOR LIGHTS...
  • Page 4 (***) Cold rinse Rinse at 68°C Prewash at 45°C Wash at 70°C 2 cold rinses (**) Rinse at 70°C (**) See display. 60-70" program is selected, the dishwasher recognises CONSUMPTION WATER POWER LITRES (1) KWh (2) 0,02 0,70 1,01 (***)
  • Page 5 The dishwasher door is securely closed. LIGHTING Pressing the ON/OFF button (1) will start the dishwasher and will lit up the dishwasher pilot light (6). After approximately 3 second from this operation the DISPLAY (8) will be turned on with a visualization that will depend upon the state of the dishwasher.

  • Page 6: Start Program

    “End” visual notification on DISPLAY (8). By pressing one of the buttons, the “End” visual signal will vanish from the display and the dishwasher is ready to continue a new cycle, the same thing happens when closing or opening the door or by switching on-off the machine.

  • Page 7: Interrupting A Program

    In case that the tub temperature is higher than 50°C the program will start about 30 seconds later. The washing cycle will not take place if the dishwasher door is left open or not properly closed. ”);...
  • Page 8 The PROGRAM DELAY button (4) can be pressed to delay the start of the program by up to 12 hours. This means that the dishwasher can be operated at the time of day of your choice. The first time the PROGRAM DELAY button (4) is pressed the display will show 12 hours, the maximum delay time before the program will start.

  • Page 9: Removing The Dishes

    “3 in 1” or “triple action” products; in this case the dishwasher will use the product in an optimal way avoiding salt and rinse-aid consumption, which could already be found in the dishwasher.

  • Page 10: Additional Functions

    User instructions ADDITIONAL FUNCTIONS (available in all programs except the soak program) The electronic control system allows personalizing the machine use directly through a programming procedure not directly accessible that allows: regulate water hardness level. Depending on model, the setting may be made electronically or by means of a selector switch.

  • Page 11: Switch Setting

    User instructions SWITCH SETTING The dishwasher is equipped with an device for the user to adjust the water softening system according to the hardness of the water supply. The setting switch is inside the plastic locking ring located on the right- hand side, inside the dishwasher.

  • Page 12: Troubleshooting

    The system which limits the water level inside the dishwasher has been tripped. Interrupt the program and switch off the dishwasher. Switch the dishwasher back on, program it again and start the washing cycle. If the problem persists, contact the after-sales service.
  • Page 13 The appliance is not able to "measure" the amount of water loaded accurately. Interrupt the program and switch off the dishwasher. Switch the dishwasher back on, program it again and start the washing cycle. If the problem persists, contact the after-sales service.
  • Page 14 INSTRUCTION MANUAL...

  • Page 15: Table Of Contents

    Following the cleaning instructions provided here will keep your dishwasher's performance at peak levels in the long term. This user-friendly manual will provide answers to all your questions about use of the dishwasher. INSTALLATION INSTRUCTIONS: these are intended for the qualified technician who must carry out the installation, hook-up and testing of the appliance.

  • Page 16: Safety Instructions

    THIS MANUAL FORMS AN INTEGRAL PART OF THE APPLIANCE: IT MUST ALWAYS BE KEPT INTACT TOGETHER WITH THE DISHWASHER. BEFORE USING THE APPLIANCE, CAREFULLY READ ALL THE INSTRUCTIONS CONTAINED IN THIS MANUAL. INSTALLATION MUST BE PERFORMED BY A QUALIFIED TECHNICIAN, IN COMPLIANCE WITH THE REGULATIONS IN FORCE.
  • Page 17 LEANING OR SITTING ON THE DISHWASHER DOOR WHEN OPEN MAY CAUSE THE APPLIANCE TO OVERTURN, PUTING PEOPLE AT RISK. DO NOT DRINK THE WATER RESIDUES WHICH MAY BE PRESENT INSIDE THE DISHES OR DISHWASHER AT THE END OF THE WASHING PROGRAM AND BEFORE THE DRYING CYCLE.

  • Page 18: Installation Instructions

    2. Installation and hook-up Remove the polystyrene basket retainers. Position the appliance in the desired place of installation. The back or sides of the dishwasher may be placed up against walls or other furniture units. If the dishwasher is installed near a heat source, fit the special insulating panel to prevent overheating and malfunction of the appliance.

  • Page 19: Drain Connection

    Installation instructions The dishwasher can also be connected to a hot water supply not exceeding 60°C. Supplying the appliance with hot water cuts down the washing time by approximately 20 minutes, but slightly reduces its effectiveness. Make the connection to the domestic hot water supply using the same procedure described for connecting to the cold water supply.

  • Page 20: Operating Instructions

    • When using the dishwasher for the first time, in addition to the salt it is also necessary to add one litre of water to the container. Each time the salt container is refilled, make sure that the cap is securely closed. The •...

  • Page 21: Using The Rinse Aid And Detergent Dispensers

    ADJUSTING THE RINSE AID DISPENSER SETTING The dishwasher is factory set for medium water hardness. However it possible to change the setting by turning the dispenser’s selector to the desired position: the amount of rinse aid dispensed is proportional to the selector position.

  • Page 22: Adding The Detergent

    • Do not use detergents formulated for washing dishes by hand, because they produce a great deal of foam and may negatively affect the operation of the dishwasher. • Add the correct amount of detergent. An insufficient amount of detergent will result in a partial removal of dirt from the dishes, whereas an excessive amount is wasteful and does not improve the washing results.

  • Page 23: General Warnings And Recommendations

    User instructions General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading. There are generally no constraints on the washing of domestic dishes, but in certain cases it is necessary to take their characteristics into account.

  • Page 24: Using The Baskets

    User instructions Using the baskets The dishwasher has a capacity of 10 place-settings, including serving dishes. EN 50242 STANDARD LOADS FOR CERTIFICATION BODIES LOWER BASKET UPPER BASKET LOWER BASKET The lower basket receives the full force of the lower spray arm, and should therefore be used for the “toughest”...

  • Page 25: Cutlery Basket

    User instructions CUTLERY BASKET The cutlery should be arranged in an orderly manner inside the basket, with the handles pointing downwards. Take care during loading to avoid injury from the knife blades. The basket is suitable for all types of cutlery, except those long enough to interfere with the upper spray arm.

  • Page 26: Loading The Upper Basket

    LOADING THE UPPER BASKET Load plates facing forward; cups, bowls etc. must always be facing downwards. The left side of the basket can be loaded with cups and glasses on two levels. On the right plates and saucers can be slotted verticalli into the forks.

  • Page 27: Cleaning And Maintenance

    General warnings and recommendations Avoid the use of acidic or abrasive detergents. Clean the outer surfaces and door-lining of the dishwasher regularly using a soft cloth moistened with water or with a normal detergent suitable for painted surfaces. Clean the door gaskets with a damp sponge.

  • Page 28: Cleaning The Filter Unit

    The filters should be cleaned under running water using a stiff brush. It is essential to thoroughly clean the filters according to the above instructions: the • dishwasher cannot function if the filters are clogged. Carefully replace the filters in their seats, to avoid damaging the wash pump. •...
  • Page 29 TROUBLESHOOTING MINOR PROBLEMS In some cases it is possible to remedy minor problems by referring to the following instructions: If the program fails to start, check that: the dishwasher is connected to the electrical power supply; • there is no power failure;...

  • Page 30: Technical Data

    TECHNICAL DATA Width Depth measured flush with the outer edge of the control panel Height Capacity Water supply pressure Electrical characteristics User instructions 447 ÷ 449 mm Free standing: 600 mm Semi-integrated: 590 mm - Fully integrated: 570 mm Free standing from 850 mm to 870 mm Semi-integrated and fully integrated: from 820 mm to 870 mm 10 Standard place settings Min.
