DESCRIPTION
CEL's MeshConnect™ Module Series provides high performance
and low cost Sub-G modules for a broad range of wireless net-
works. The MeshConnect certified and qualified modules enable
customers to accelerate time to market by greatly reducing design
and certification phases of development.
CEL's MeshConnect™ Sub-G modules (868/900MHz) are based
on the Silicon Labs SoC ICs (single-chip solutions). Each IC con-
sists of an RF transceiver with baseband modem, a hard-wired
MAC and an embedded 8051 microcontroller with internal RAM
(4kB) and Flash (64kB) memory. The device provides numer-
ous general-purpose I/O pins and peripheral functions such as
timers and UARTs.
The MeshConnect Sub-G modules have 2 different output powers
(+12dBm and +19dBm). They provide a reliable transmission, to
reduce the number of nodes in a network. They are especially
useful for open outdoor applications where the nodes are physi-
cally far apart. The higher power Modules have an outstanding
118dB link budget ensuring high quality connections even in
harsh environments.
APPLICATIONS
• Metering
• RFID
• Remote Keyless Entry
• Home Automation
The information in this document is subject to change without notice, please confirm data is current
Document No: 0009-00-07-00-000 (Issue ES)
Date Published: December 7, 2010
PRELIMINARY DATA SHEET
MeshConnect™ Sub-G Module Series
868 / 900 MHz Transceiver Based Modules
ZICM0868P2-KIT1-1 and ZICM0900P2-KIT1-1
• Security
• Irrigation
• Weather Stations
• And more...
Development Kits Available:
MeshConnect
ZICM0868Px
Best Reliable Performance
• Good sensitivity providing longer range for Non-line-of-site
aplications
• Low operating (receive) current
FEATURES
• Frequency Range:
902- 928 MHz
868 MHz
• Sensitivity: -99 dBm
• Max Output Power:
+ 12 dBm @ 3.6 V
(ZICM0xxxP0)
DC
+ 19 dBm @ 3.6 V
(ZICM0xxxP2)
DC
• Data Rate: 0.123 to 150 kbps
• Up to 21 GPIO Pins
• High Speed 8051 MCU:
30 MHz
4kB RAM / 64 kB Flash
• 10-Bit ADC:
300 ksps, 18-ch inputs
• Serial Communication:
UARTs, SPI (Master/Slave)
SMBus, PCA
• Modulation:
FSK
ZICM0868Px
ZICM0900Px
Sub-G Modules
™
ZICM0900Px
• RF Power Consumption
24 mA Receive
18 mA @ + 1 dBm transmit
30 mA @ + 12 dBm transmit
90 mA @ + 19 dBm transmit
• Auto-Frequency Calibration (AFC)
• Frequency Hopping Capability
• Up to 12 miles of range
• Operating Temperature Range:
-40 to +85ºC
•Software Support:
Synapse SNAP Embedded Firmware
Wireless M-Bus (868MHz Only)
Silicon Labs EZMac
CEL Protocol
• FCC, CE and IC certifications in
Progress
• ROHS compliant
Page 1
Advertisement
Table of Contents
Related Manuals for CEL ZICM0868P Series
Summary of Contents for CEL ZICM0868P Series
-
Page 1: Description
MeshConnect Sub-G Modules ™ CEL's MeshConnect™ Module Series provides high performance and low cost Sub-G modules for a broad range of wireless net- works. The MeshConnect certified and qualified modules enable customers to accelerate time to market by greatly reducing design and certification phases of development. -
Page 2: Ordering Information
MeshConnect™ Sub-G Module Series ORDERING INFORMATION Part Number Order Number Description ZICM0868P0-1CU 868 MHz Module, +12dBm output power with U.FL connector for external antenna ZICM0868P2-1CU 868 MHz Module, +19dBm output power with U.FL connector for external antenna ZICM0868P0-1CS 868 MHz Module, +12dBm output power with RP-SMA connector for external antenna ZICM0868P2-1CS 868 MHz Module, +19dBm output power with RP-SMA connector for external antenna 868 MHz Module, +12dBm output power with a connection for 1/4 wave wire antenna... -
Page 3: Module Block Diagram
Optional DEVELOPMENT KIT MeshConnect ™ CEL's Development Kit assist users in both evaluation and Sub-G Module Development Kit development. As a stand-alone radio system, the kit allows users to place the modules into the target environment and evaluate performance on-site. The Development Kit also serves as an invaluable aid in application develop- ment. -
Page 4: Table Of Contents
MeshConnect™ Sub-G Module Series TABLE OF CONTENTS Introduction and Overview Description......................................Features........................................Applications......................................Ordering Information..................................... Module Block Diagram................................... Development Kit..................................... System Level Function Transceiver IC......................................Antenna....................................Additional Flash Memory..................................Electrical Specification Absolute Maximum Ratings................................... Recommended (Operating Condition)..............................DC Characteristics....................................RF Characteristics....................................Pin Signal &... -
Page 5: Transceiver Ic
For more information about the Silicon Labs ICs, visit http://www.silabs.com. ANTENNA The MeshConnect Sub-G modules include RF connectors for external antenna options only (There is no trace antenna option). The following options are supported by CEL: • U.FL connector •... -
Page 6: Absolute Maximum Ratings
MeshConnect™ Sub-G Module Series ABSOLUTE MAXIMUM RATINGS MeshConnect™ Sub-G Module Description Unit Power Supply Voltage (V -0.3 Voltage on any I/O Line -0.3 + 0.3 RF Input Power – Storage Temperature Range °C Reflow Soldering Temperature – °C Note: Exceeding the maximum ratings may cause permanent damage to the module or devices. RECOMMENDED (OPERATING CONDITIONS) MeshConnect™... -
Page 7: Rf Characteristics
MeshConnect™ Sub-G Module Series RF CHARACTERISTICS (@ 25°C, V = 3.6V, ZICM0xxxP2) MeshConnect™ Sub-G Module Description Unit General Characteristics RF Frequency Range – Transmitter Maximum Output Power – – Minimum Output Power – – FSK Error – Carrier Offset – Deviation –... -
Page 8: Pin Signals I/O Configuration
P0.5/RXD UART TXD P0.4/TXD UART RXD Write Protect Pin of Memory Chip on Module P0.3 Used as Chip Select for Memory IC on the CEL Module P0.2 Memory IC MISO signal pin P0.1 Must be connected to NIRQ for SNAP firmware P0.0... -
Page 9: Software/Firmware
Name Notes P2.2 GPIO connected to LED2 on CEL Eval board P2.1 GPIO connected to Switch 1 on CEL Eval Board P2.0 GPIO connected to LED1 on CEL Eval board P1.7 GPIO connected to Switch 0 on CEL Eval Board P1.6... -
Page 10: Module Dimensions
MeshConnect™ Sub-G Module Series SOFTWARE/FIRMWARE (Continued) • Self Healing (Orphan handling) • Point-to-Point network formation • Point-to-Multipoint (Star) network formation • Self Healing (Orphan handling) • Point-to-Point network formation • Point-to-Multipoint (Star) network formation • • Wakeup Modes (Si100X) – most likely software will just use one of the wakeup modes •... -
Page 11: Module Footprint
MeshConnect™ Sub-G Module Series MODULE LAND FOOTPRINT Note: Unless otherwise specified. Dimensions are in Inches [mm]. EVALUATION BOARD CEL provides an Evaluation board to allow easy testing of the Module. The Evaluation board provides power via: • AA cell batteries • •... -
Page 12: Processing
MeshConnect™ Sub-G Module Series PROCESSING Recommended Reflow Profile Parameters Values Ramp up rate (from Tsoakmax to Tpeak) 3º/sec max Minimum Soak Temperature 150ºC Maximum Soak Temperature 200ºC Soak Time 60-120 sec TLiquidus 217ºC Time above TL 60-150 sec Tpeak 250ºC Time within 5º... -
Page 13: Agency Certifications
2. This device must accept any interference received, including interference that may cause undesired operation. Warning (Part 15.21) Changes or modifications not expressly approved by CEL could void the user's authority to operate the equipment. 20 cm Separation Distance To comply with FCC/IC RF exposure limits for general population / uncontrolled exposure, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. -
Page 14: Shipment, Storage & Handling
MeshConnect™ Sub-G Module Series AGENCY CERTIFICATIONS (Continued) IC Certification — Industry Canada Statement The term "IC" before the certification / registration number only signifies that the Industry Canada technical specifications were met. Section 14 of RSS-210 The installer of this radio equipment must ensure that the antenna is located or pointed such that it does not emit RF field in excess of Health Canada limits for the general population. -
Page 15: References & Revision History
• CEL does not assume any liability for infringement of patents, copyrights or other intellectual property rights of third parties by or arising from the use of CEL products listed in this document or any other liability arising from the use of such products.
