DESCRIPTION

CEL's MeshConnect™ Sub-G modules are built on the Si1000
and Si1002 highly integrated wireless SoC's from Silicon Labs.
Targeting dense operating environments, CEL's MeshConnect
Sub-G modules deliver superior range and performance. Their
low power consumption enables longer battery life and their link
budgets provide reliable transmission in non line of sight ap-
plications such as lighting control, industrial sensor networks,
serial wire replacement, metering, irrigation and more. At +13
and +20 dBm power outputs, the new Sub-G modules offer 868
MHz (Europe) and 915 MHz (Americas) ISM band options. As
certified and qualified modules, the MeshConnect Sub-G solu-
tions eliminate the need for costly certifications, reducing overall
system cost and accelerating time to market.

APPLICATIONS

• Lighting Control
• Irrigation
• Serial wire replacement
• Industrial Sensor Networks
• Wireless M-Bus Metering
• Home Automation & Smart Plugs
• Security
• And more...
The information in this document is subject to change without notice, please confirm data is current
Document No: 0009-00-07-00-000 (Issue ES)
Date Published: June 1
, 2011
st
PRELIMINARY DATA SHEET
MeshConnect™ Sub-G Module Series
868 / 900 MHz System-on-Chip (SoC) Based Modules
ZICM0868P0-KIT1-1 and ZICM0900P2-KIT1-1

FEATURES

• Frequency Range:
902- 928 MHz
868 MHz
• Link Budget up to -140 dB
(for +20 dBm module)
+20 dBm and +13 dBm available
output powers
• Max Output Power:
+ 13 dBm @ 3.5 V
+ 20 dBm @ 3.5 V
• Data Rate: 0.123 to 150 kbps
• General Purpose I/Os: 21
• High Speed 8051 MCU:
25 MHz - single cycle instruction execution
4kB RAM / 64 kB Flash
• 10-Bit ADC:
300 ksps, 18-ch inputs
• Serial Communication:
UARTs, SPI (Master/Slave)
SMBus, PCA
• Add 1MB additional Flash memory
to enable Over The Air (OTA)
programming
Development Kits Available:
MeshConnect
ZICM0868P0
• Long Range
• Low Power Consumption
• 868 and 900 MHz Frequency Ranges
• 1MB additional Flash Memory option enables
Over the Air (OTA) Programming
• Modulation:
FSK, GFSK, OOK
• RF Power Consumption
24 mA Receive
18 mA @ + 1 dBm transmit
42 mA @ + 13 dBm transmit
97 mA @ + 19 dBm transmit
• Sleep Current 1.2 µA TYP
(ZICM0868P0)
DC
• Up to 6 miles of range
(ZICM0900P2)
DC
(line of sight)
• Operating Temperature Range:
-40 to +85ºC
•Software Platforms:
Synapse SNAP Embedded Firmware
Wireless M-Bus (868 MHz Only)
CEL Application Programming
Interface (API)
Silicon Labs EZMac
• FCC, CE and IC certifications in
Progress
Multiple antenna options
FSK Modulation Only
• ROHS compliant
(Optional)
ZICM0868P0
ZICM0900P2
Sub-G Modules
ZICM0900P2
Page 1

Advertisement

Table of Contents
loading

Summary of Contents for CEL MeshConnect ZICM0868P0-1C

  • Page 1: Description

    DESCRIPTION MeshConnect Sub-G Modules ™ CEL's MeshConnect™ Sub-G modules are built on the Si1000 and Si1002 highly integrated wireless SoC's from Silicon Labs. Targeting dense operating environments, CEL’s MeshConnect Sub-G modules deliver superior range and performance. Their low power consumption enables longer battery life and their link...
  • Page 2: Ordering Information

    MeshConnect™ Sub-G Module Series ORDERING INFORMATION Part Number Order Number Description ZICM0868P0-1CU 868 MHz Module, +13dBm SoC with U.FL connector for external antenna MeshConnect™ ZICM0868P0-1CS 868 MHz Module, +13dBm SoC with RP-SMA connector for external antenna Sub-G Module (868 MHz) ZICM0868P0-1C 868 MHz Module, +13dBm SoC with 1/4 wave wire antenna ZICM0900P2-1CU...
  • Page 3: Module Block Diagram

    Optional DEVELOPMENT KIT MeshConnect ™ CEL's Development Kit assist users in both evaluation and Sub-G Module Development Kit development. As a stand-alone radio system, the kit allows users to place the modules into the target environment and evaluate performance on-site. The Development Kit also serves as an invaluable aid in application develop- ment.
  • Page 4: Table Of Contents

    MeshConnect™ Sub-G Module Series TABLE OF CONTENTS Introduction and Overview Description......................................Features........................................Applications......................................Ordering Information..................................... Module Block Diagram................................... Development Kit..................................... System Level Function Transceiver IC......................................Antenna........................................Additional Flash Memory..................................Electrical Specification Absolute Maximum Ratings................................... Recommended (Operating Condition)..............................DC Characteristics....................................RF Characteristics....................................Pin Signal & Interfaces Pin Signals I/O Configuration................................
  • Page 5: Transceiver Ic

    For more information about the Silicon Labs ICs, visit http://www.silabs.com. ANTENNA The MeshConnect Sub-G modules include RF connectors for external antenna options only (There is no trace antenna option). The following options are supported by CEL: • U.FL connector to support cabled antenna •...
  • Page 6: Absolute Maximum Ratings

    MeshConnect™ Sub-G Module Series ABSOLUTE MAXIMUM RATINGS MeshConnect™ Sub-G Module Description Unit Power Supply Voltage (V -0.3 Voltage on any I/O Line -0.3 + 0.3 RF Input Power – Storage Temperature Range °C Reflow Soldering Temperature – °C Note: Module has built in T disabling feature when VCC = 3.6VDC.
  • Page 7 MeshConnect™ Sub-G Module Series RF CHARACTERISTICS = 3.5V, ZICM0868P0) (@ 25°C, V MeshConnect™ Sub-G Module Description Unit General Characteristics RF Frequency Range – Transmitter Maximum Output Power – – Minimum Output Power – – FSK Error – – Deviation – –...
  • Page 8: Pin Signals I/O Configuration

    CNVSTR P0.5/RXD Module's Internal UART RXD P0.4/TXD Module's UART TXD Write Protect Pin of Memory Chip on Module P0.3 Used as Chip Select for Memory IC on the CEL Module P0.2 Memory IC MISO signal pin P0.1 Connected to NIRQ P0.0...
  • Page 9: Software/Firmware

    Radio Shutdown (Active High); Internally connected to P0.7 Note: The CEL Sub G module has internal connections between Castellation Pins 12 & 49 and 25 & 48 to allow stand alone operation with both SNAP and CEL firmware images.
  • Page 10: Module Dimensions

    MeshConnect™ Sub-G Module Series SOFTWARE/FIRMWARE (Continued) • Self Healing (Orphan handling) • Point-to-Point network formation • Point-to-Multipoint (Star) network formation • Mesh network formation* • • Wakeup Modes (Si100X) • Frequency Hopping • Unicast Addressing using 16-bit device IDs • Broadcast Addressing •...
  • Page 11: Module Footprint

    0.050 PITCH 0.065 0.050 0.000 TOP VIEW EVALUATION BOARD CEL provides an Evaluation board to allow easy testing of the Module. The Evaluation board provides power via: • AA cell batteries • • AC Adapter regulated down to 3.3VDC •...
  • Page 12: Processing

    MeshConnect™ Sub-G Module Series PROCESSING Recommended Reflow Profile Parameters Values Ramp up rate (from Tsoakmax to Tpeak) 3º/sec max Minimum Soak Temperature 150ºC Maximum Soak Temperature 200ºC Soak Time 60-120 sec TLiquidus 217ºC Time above TL 60-150 sec Tpeak 250ºC Time within 5º of Tpeak 20-30 sec Time from 25º...
  • Page 13: Agency Certifications

    2. This device must accept any interference received, including interference that may cause undesired operation. Warning (Part 15.21) Changes or modifications not expressly approved by CEL could void the user's authority to operate the equipment. 20 cm Separation Distance To comply with FCC/IC RF exposure limits for general population / uncontrolled exposure, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 14 MeshConnect™ Sub-G Module Series AGENCY CERTIFICATIONS (Continued) IC Certification — Industry Canada Statement The term "IC" before the certification / registration number only signifies that the Industry Canada technical specifications were met. This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two con- ditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 15: Shipment, Storage & Handling

    CEL conducts 100% RF and DC factory testing on all production parts and also conducts sample testing on all device lots. CEL’s builds the quality into our products giving our customers the confidence when integrating our products into their systems. Page 15...
  • Page 16: References & Revision History

    • CEL does not assume any liability for infringement of patents, copyrights or other intellectual property rights of third parties by or arising from the use of CEL products listed in this document or any other liability arising from the use of such products.
