Page 1: User Manual
P73889-A-F5U221-man.qxd 4/25/02 3:34 PM Page 1 Belkin 4-Port USB 2.0 Hub User Manual F5U221 P73889-A... - Page 2 P73889-A-F5U221-man.qxd 4/25/02 3:34 PM Page 2...
- Page 3 4-Port USB 2.0 Hub and/or to the connected devices. Congratulations and thank you for purchasing the Belkin 4-Port USB 2.0 Hub (the Hub). The Hub provides four downstream USB ports that are compatible with both USB 1.1 (low- and full-speed) devices, as well as with USB 2.0...
-
Page 4: Package Contents
P73889-A-F5U221-man.qxd 4/25/02 Features • Compliant with Universal Serial Bus specification 2.0 (data rate 1.5/12/480Mbps) • Backward-compatible with Universal Serial Bus Specification 1.1 (data rate 1.5/12Mbps) • Compatible with Windows • Approved by USB Implementers Forum (USB-IF) • Supports Plug-and-Play specifications •... -
Page 5: Technical Specifications
P73889-A-F5U221-man.qxd 4/25/02 Technical Specifications Upstream Ports: Downstream Ports: Per-Port Voltage: Per-Port Current: Power Mode: Operation Temperature: Storage Temperature: Enclosure: Power Supply: 3:34 PM Page 3 DC +5V 500mA (max.) Self-powered 5°C~40°C -20°C~60°C Plastic Input: 120V AC Output: DC 6V 2.5A Plug Size: 5.5mm (outer) - Page 6 P73889-A-F5U221-man.qxd 4/25/02 Technical Specifications (continued) Main Power LED ColorDefinitions: Steady Red Port-Status LED Color Definitions: Amber Steady Green Blinking Off/Green Blinking Off/Amber 3:34 PM Page 4 Not operational Operational Not operational Error condition Fully operational Software attention Hardware attention...
-
Page 7: Product Detail
P73889-A-F5U221-man.qxd 4/25/02 3:34 PM Page 5 Product Detail Figure 1 Power LED Per-Port Status LED Upstream Port Downstream DC 6V 2.5A Ports Power Jack... -
Page 8: Hardware Installation
P73889-A-F5U221-man.qxd 4/25/02 Hardware Installation 1. Plug the AC adapter into a wall outlet or surge suppressor. Plug the DC connector into the DC power jack found on the back of the Hub (See Figure 1). 2. Plug the USB-A cable connector into the downstream port of your computer, or downstream port of another hub. - Page 9 P73889-A-F5U221-man.qxd 4/25/02 3:34 PM Page 7 Hardware Installation (continued) USB-A Connector USB-B Connector Figure 2 Figure 3 Port 1 Port 2 Upstream Port Port 3 Port 4 Figure 4...
-
Page 10: Electromagnetic Compatibility
Belkin Components warrants this product against defects in materials and workmanship for its lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product. - Page 11 7 Bowen Cresent • West Gosford NSW 2250 • Australia Tel: +61 (2) 4372 8600 Fax: +61 (2) 4325 4277 © 2002 Belkin Components. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. 3:34 PM Page 9...
- Page 12 P73889-A-F5U221-man.qxd 4/25/02 3:34 PM Page 10...
