Summary of Contents for Blade Scimitar LRX
- Page 1 Instruction Manual Manuel d’utilisation...
- Page 2 NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit www.horizonhobby.com and click on the support tab for this product. Meaning of Special Language The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious injury OR create a high probability of superficial injury. CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of serious injury. NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of injury. WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly can result in damage to the product, personal property and cause serious injury. This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to the product or other property. This product is not intended for use by children without direct adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury. Age Recommendation: Not for children under 14 years. This is not a toy. Safety Precautions and Warnings • Always keep a safe distance in all directions around your model • Never place any portion of the model in your mouth as it could to avoid collisions or injury. This model is controlled by a radio...
-
Page 3: Table Of Contents
Table of Contents First Flight Preparation ............4 Flight Mode and Rate Selection ..........8 Flying Checklist ..............4 Flying the Scimitar LRX Quadcopter ........8 Installing the Propellers............4 Post-Flight Inspection and Maintenance Checklist ....8 Transmitter Setup ..............4 Troubleshooting Guide ............9 Installing the Flight Battery ..........5 Parts Explosion ..............10 Transmitter and Receiver Binding ......... 5 Parts Listings ..............10 Understanding the Primary Flight Controls ......6 Limited Warranty ............... 11 Adjusting the FPV Camera Angle .......... -
Page 4: First Flight Preparation
❏ Always turn the transmitter off last • Bind your transmitter • Familiarize yourself with the controls • Find a suitable area for flying Installing the Propellers 1. Refer to the illustration for the proper motor rotation and propeller location. 2. The propellers have “CW” or “CCW” marked on one blade to show proper location and rotation. Match the propeller location to the illustration. 3. Secure the propellers using the provided lock nuts. Do not overtighten the nuts as damage to the propellers or motors may result. Transmitter Setup DX6, DX6e, DX7 (Gen 2), DX8 (Gen 2), DX9, iX12, DX18, DX20 SETUP LIST FUNCTION LIST... -
Page 5: Installing The Flight Battery
Installing the Flight Battery 1. Set the motor arm switch to OFF (position 1). CAUTION: Connecting the battery to the aircraft 2. Lower the throttle. power lead with reversed polarity will cause 3. Power on the transmitter. damage to the power distribution board, ESCs and the 4. Attach hook material to the quadcopter frame and loop battery. Damage caused by incorrectly connecting the material to the battery. battery is not covered under warranty. 5. Install the flight battery on the quadcopter frame and secure it with the hook and loop strap. 7. The quadcopter motors will emit initialization tones, 6. Connect the battery cable to the aircraft power lead, indicating the ESC is armed. noting correct polarity. Do not move the quadcopter until the receiver initializes. CAUTION: Always disconnect the Li-Po battery from the quadcopter when not flying to avoid over-discharging the battery. Batteries discharged to a voltage lower than the lowest approved voltage may become damaged, resulting in loss of performance and potential fire when batteries are charged. Transmitter and Receiver Binding To bind or re-bind your quadcopter to your chosen transmitter, follow the directions below. Binding Procedure 1. Select the correct model in your transmitter. -
Page 6: Understanding The Primary Flight Controls
Understanding the Primary Flight Controls If you are not familiar with the controls of your quadcopter, take a few minutes to familiarize yourself with them before attempting your first flight. Throttle Left Side View Left Side View Descend Climb Throttle down Throttle up Rudder Top Down Driver’s Side Rear Top Down Driver’s Side Rudder left Rudder right Nose Yaws Nose Yaws Left Right Elevator Rear Top Down Rear Driver’s Side Top Down Left Side View Left Side View... -
Page 7: Connecting An Antenna
5765 5745 5725 Race Band 5658 5695 5732 5769 5806 5843 5880 5917 Band B 5733 5752 5771 5790 5809 5828 5847 5866 Preparing the Scimitar LRX Quadcopter for Flight 1. Before each flight, ALWAYS power on the transmitter before connecting the flight battery to the quadcopter. After each flight, disconnect the flight battery from the quadcopter before powering off the transmitter. NOTICE: Connecting the flight battery before powering on the transmitter can start the binding process. Please see the Transmitter and Receiver Binding section of this manual for more information. 2. When the ESC beeps, the flight controller is initialized and ready for flight. The flight controller will not arm the motors until the throttle stick is in the lowest possible position. -
Page 8: Flight Mode And Rate Selection
Flight Mode and Rate Selection • In angle mode (switch position 0), the quadcopter will self-level and has a bank angle limit of approximately 60 degrees. • In air mode (switch position 1), the quadcopter will not self-level and does not have a bank angle limit. At low throttle, the flight controller will continue to stabilize the quadcopter to hold whatever attitude was last commanded. This mode is use- ful for flying smooth aerobatic maneuvers at both high and low throttle settings. • In acro mode (switch position 2 ), the quadcopter will not self-level and does not have a bank angle limit. At low throttle, the flight controller will not stabilize the quadcopter. The pilot must actively control the quadcopter to maintain a desired at- titude. This mode is most preferred when immediate changes in altitude are desired, such as in racing. Use rates and expo to tune the performance according to your flying style. Refer to the Transmitter Setup for transmitter switch selection and specific setup information. Flying the Scimitar LRX Quadcopter Takeoff When you are prepared to fly, start the motors by activating the motor arm switch (switch H), as programmed in the transmitter setup section. Increase the throttle until the model is approximately 2 ft. (600mm) off the ground and check the trim so the model flies as desired. Once the trim is adjusted, begin flying the model. Flight times for the included battery will vary according to how aggressively the throttle is used. Low Voltage Cutoff (LVC) LVC decreases the power to the motors when the battery voltage gets low. When the motor power decreases, land the aircraft immediately and recharge the flight battery. LVC does not prevent the battery from over-discharge during storage. -
Page 9: Troubleshooting Guide
Troubleshooting Guide WARNING: Remove the propellers from the motors prior to performing any troubleshooting or maintenance. Failure to do so may cause serious injury if the motors start unexpetedly. Problem Possible Cause Solution Disconnect the flight battery, center the control trim and Quadcopter not initialized on a level surface Quadcopter control response is re-initialize the quadcopter inconsistent or requires extra Adjust battery position so quadcopter balances in the trim to neutralize movement Battery not correctly placed center of the frame Motor arm switch is in the OFF position Set the motor arm switch to the ON position... -
Page 10: Parts Explosion
Parts Explosion Parts Listings Part # Description Part # Description 1 BLH02555 Carbon Plate Set: LRX 7 BLH02551 2408-1400Kv Motor: LRX 2 BLH02554 Replacement Arm: LRX 8 BLH02552 4-in-1 ESC: LRX 3 BLH02556 Aluminum Standoff Set: LRX 9 BLH02553 Flight Controller: LRX 4 BLH02557 7-Inch Props (4): LRX 10 SPMVC602... -
Page 11: Limited Warranty
Limited Warranty What this Warranty Covers please visit our website at www.horizonhobby.com, submit a Product Support Inquiry, or call the toll free telephone number referenced in Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the the Warranty and Service Contact Information section to speak with a product purchased (the “Product”) will be free from defects in materials Product Support representative. -
Page 12: Warranty And Service Contact Information
800-338-4639 FCC Information FCC ID: BRWAR4649T IC: 6157A-AR4649T FCC Information: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This product contains a radio transmitter with wireless technology which has been tested and found to be compliant with the applicable regulations governing a radio transmitter in the 2.400GHz to 2.4835GHz frequency range. Supplier’s Declaration of Conformity Blade Scimitar LRX BNF Basic | BLH02550 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. - Page 13 ©2018 Horizon Hobby, LLC. Blade, the Blade logo, Scimitar, DSM, DSM2, DSMX, Bind-N-Fly, BNF, the BNF logo, ModelMatch, and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc.
