- Page 1 RTL8188CE miniCard User’s Manual Rev. 1.0 03 Dec 2009...
- Page 2 TRENDnet provides this document “as is”, without warranty of any kind, neither expressed nor implied, including, but not limited to, the particular purpose. TRENDnet may make improvements and/or changes in this document or in the product described in this document at any time. This document could include technical inaccuracies or typographical errors.
-
Page 3: Table Of Contents
4.5.1 Federal Communication Commission Interference Statement..................6 4.5.2 Industry Canada Statement............................8 4.5.3 NCC警語..................................9 List of Tables PCI E ..........................4 ABLE XPRESS SSIGNMENT ............................5 ABLE UNCTIONAL PECIFICATIONS List of Figures RTL8188CE ......................3 IGURE MINI PPLICATION IAGRAM RTL8188CE ....................5 IGURE MINI ECHANICAL PECIFICATION... -
Page 4: General Description
Power saving mechanisms such as U-APSD, and APSD, reduces power wasted during idle time, and compensates for the extra power required to transmit OFDM. The RTL8188CE provides simple legacy and 20MHz/40MHz co-existence mechanisms to ensure backward and network compatibility. -
Page 5: Features
2. Features RTL8188CE to assume multiple MAC identities when used as a wireless bridge General Supports Wake-On-WLAN via Magic Packet and Wake-up frame 48-pin QFN Transmit Opportunity (TXOP) Short CMOS MAC, Baseband PHY and RF in a Inter-Frame Space (SIFS) bursting for single chip for IEEE 802.11b/g/n... -
Page 6: Block Diagram
3. Block Diagram Figure 1. RTL8188CE miniCard Application Diagram Rev.1.0... -
Page 7: Product Specifications
4. Product specifications 4.1. Mini PCI Express Pin Assignment Table 1. Mini PCI Express Pin Assignment PIN# Pin Name PIN# Pin Name WAKE# 3.3Vaux COEX1 COEX2 1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET UIM_VPP RESERVED RESERVED W_DISABLE# PERST# PERn0 +3.3Vaux PERp0 +1.5V... -
Page 8: Mechanical
4.2. Mechanical Figure 2. RTL8188CE miniCard Mechanical Specification 4.3. Environmental 4.3.1. Operating Operating Temperature: 0 to 70 °C Relative Humidity: 5-90% (non-condensing) 4.3.2. Storage Temperature: -55 to 125 °C Relevant Humidity: 5-95% (non-condensing) 4.4. Functional Specifications Table 2. Functional Specifications 3.3Vdc±0.3Vdc , 365mA from host equipment... -
Page 9: Warning
Transfer rate 802.11b: 11 / 5.5 / 2 / 1Mbps 802.11g: 54 / 48 / 36 / 24 / 18 / 12 / 9 / 6Mbps Draft 802.11n (20MHz, 800ns GI): 65 / 58.5 / 52 / 39 / 26 / 19.5 / 13 / 6.5Mbps Draft 802.11n (40MHz, 800ns GI): 135 / 121.5 / 108 / 81 / 54 / 40.5 / 27 / 13.5Mbps... - Page 10 This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through 11. This device is intended only for OEM integrators under the following conditions: The antenna must be installed such that 20 cm is maintained between the antenna and users, and The transmitter module may not be co-located with any other transmitter or antenna, For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band by supplied...
-
Page 11: Industry Canada Statement
IMPORTANT NOTE: IC Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. 4.5.2 Industry Canada Statement This device complies with RSS-210 of the Industry Canada Rules. -
Page 12: Ncc警語
End Product Labeling The final end product must be labeled in a visible area with the following: “Contains IC : 6317A-RTL8188CE”. Manual Information That Must be Included The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove.
